TROUBLE DIAGNOSIS
: Vehicle front
1. Air fuel ratio (A/F) sensor 1 2. Three way catalyst (Manifold) 3. Heated oxygen sensor 2
4. Three way catalyst (Under floor) 5. Muffler 6. Air fuel ratio (A/F) sensor 1 harness
connector
7. Heated oxygen sensor 2 harness connector
BBIA0726E
Revision: January 20102010 Versa
Page 1866 of 3745
TROUBLE DIAGNOSISEC-601
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
1. Stop lamp switch
2. ASCD brake switch 3. ASCD clutch switch
4. Clutch pedal 5. ASCD steering switch 6. MAIN switch
7. CANCEL switch 8. SET/COAST switch 9. RESUME/ACCELERATOR switch
10. EVAP control system pressure sen- sor 11. EVAP canister
12. EVAP canister vent control valve
BBIA0728E
Revision: January 20102010 Versa
Page 1867 of 3745
EC-602
< SERVICE INFORMATION >[MR18DE]
TROUBLE DIAGNOSIS
Vacuum Hose Drawing
INFOID:0000000005532417
Refer to EC-516, "Schematic" for Vacuum Control System.
: Vehicle front : From EVAP canister
1. Intake manifold 2. EVAP canister purge volume control
solenoid valve 3. EVAP service port
4. EVAP purge resonator
NOTE:
Do not use soapy water or any type of solven t while installing vacuum hoses or purge hoses.
PBIB3330E
Revision: January 20102010 Versa
Page 1868 of 3745
TROUBLE DIAGNOSISEC-603
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Circuit DiagramINFOID:0000000005532418
ABBWA0359GB
Revision: January 20102010 Versa
Page 1869 of 3745
EC-604
< SERVICE INFORMATION >[MR18DE]
TROUBLE DIAGNOSIS
AWBWA0033GB
Revision: January 20102010 Versa
Page 1870 of 3745
![NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSISEC-605
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ECM Harness Connector Terminal LayoutINFOID:0000000005532419
ECM Terminal and Reference ValueINFOID:00000000055 NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSISEC-605
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ECM Harness Connector Terminal LayoutINFOID:0000000005532419
ECM Terminal and Reference ValueINFOID:00000000055](/manual-img/5/57358/w960_57358-1869.png)
TROUBLE DIAGNOSISEC-605
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ECM Harness Connector Terminal LayoutINFOID:0000000005532419
ECM Terminal and Reference ValueINFOID:0000000005532420
