Page 3577 of 3745

NISSAN LATIO 2010 Service Repair Manual FRONT SEATSE-11 < SERVICE INFORMATION > C DE F G H J K L M A B SE N O P FRONT SEAT Driver SeatINFOID:0000000005396868 1. Headrest 2. Headrest holder (locked)3. Headrest holder (free) 4. Seat assembly

Page 3578 of 3745

NISSAN LATIO 2010 Service Repair Manual SE-12 < SERVICE INFORMATION > FRONT SEAT Passenger Seat INFOID:0000000005396869 Removal and InstallationINFOID:0000000005396870 CAUTION: • When removing and installing, use shop cloths to protect p

Page 3579 of 3745

NISSAN LATIO 2010 Service Repair Manual FRONT SEATSE-13 < SERVICE INFORMATION > C DE F G H J K L M A B SE N O P 1. Disconnect the negative and positive battery term inals, then wait at least three minutes. 2. Remove the rear leg covers. 3.

Page 3580 of 3745

NISSAN LATIO 2010 Service Repair Manual SE-14 < SERVICE INFORMATION > FRONT SEAT 4. Remove the seat cushion finisher B in the order as shown. 5. Remove the front seat belt buckle. Assembly Assembly is the reverse order of removal. SEAT CUSH

Page 3581 of 3745

NISSAN LATIO 2010 Service Repair Manual REAR SEATSE-15 < SERVICE INFORMATION > C DE F G H J K L M A B SE N O P REAR SEAT Component Parts DrawingINFOID:0000000005396872 60:40 SPLIT FOLD DOWN SEAT - HATCHBACK WIIA1231E 1. Seat cushion trim 2.

Page 3582 of 3745

NISSAN LATIO 2010 Service Repair Manual SE-16 < SERVICE INFORMATION > REAR SEAT Removal and Installation INFOID:0000000005396873 CAUTION: When removing and in stalling, use shop cloths to protect parts from damage. 60:40 SPLIT FOLD DOWN SEA

Page 3583 of 3745

NISSAN LATIO 2010 Service Repair Manual REAR SEATSE-17 < SERVICE INFORMATION > C DE F G H J K L M A B SE N O P 4. Remove the seatback mounting bolts from the left rear seat back brackets. CAUTION: Tighten seatback mounting bolts in the orde

Page 3584 of 3745

NISSAN LATIO 2010 Service Repair Manual SE-18 < SERVICE INFORMATION > REAR SEAT • When installing the rear seatback side bracket perform the following procedure. 1. Install the rear seatback side bracket in the vehicle. 2. Temporarily tig
