STOP LAMP
Wiring Diagram - STOP/L
INFOID:0000000005394954
SEDAN
Bulb Replacement for High-Mounted Stop LampINFOID:0000000005394955
HATCHBACK
The LED element is not serviced separately, the hi gh-mounted stop lamp must be replaced as an assembly.
Refer to LT-71, "
Removal and Installation of High-Mounted Stop Lamp".
ABLWA0667GB
Revision: January 20102010 Versa
Page 3066 of 3745

STOP LAMPLT-71
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
LT
N
O P
SEDAN - WITH REAR AIR SPOILER
The LED element is not serviced separately, the hi gh-mounted stop lamp must be replaced as an assembly.
Refer to LT-71, "
Removal and Installation of High-Mounted Stop Lamp".
1. Installation is in the reverse order of removal.
SEDAN - WITHOUT REAR AIR SPOILER
Removal
1. Remove the high-mounted stop lamp bulb socket (1) and remove the high-mounted stop lamp (2).
Installation
Installation is in the reverse order of removal.
Bulb Replacement for Rear Co mbination Lamp for Stop LampINFOID:0000000005394956
Refer to LT-88, "Bulb Replacement".
Removal and Installation of High-Mounted Stop LampINFOID:0000000005394957
HATCHBACK
Removal
1. Remove the rear hatch finish panel. Refer to EI-54.
2. Disconnect the high-mounted stop lamp connector.
3. Remove the nuts and remove the high-mounted stop lamp from rear hatch.
Installation
Installation is in the reverse order of removal.
CAUTION:
Properly seal the high-mounted stop lamp base to the rear hatch to prevent water leaks.
SEDAN - WITH REAR AIR SPOILER
Removal
1. Remove the rear air spoiler. Refer to EI-32, "Removal and Installation".
PKIC1021E
SKIB7594E
Revision: January 20102010 Versa
Page 3067 of 3745

LT-72
< SERVICE INFORMATION >
STOP LAMP
2. Remove the high-mounted stop lamp screws (A), then removethe high-mounted stop lamp finisher (2).
⇐: Vehicle front
3. Release the high-mounted stop lamp (3), then remove wire har- ness (1) from the rear air spoiler.
NOTE:
Attach a long string to electrical connector of wire harness for
assembly routing purposes.
Installation
Installation is in the reverse order of removal.
SEDAN - WITHOUT REAR AIR SPOILER
Removal
1. Remove the rear parcel shelf finisher. Refer to EI-45, "Removal and Installation".
2. Remove the high-mounted stop lamp assembly screws (A), then remove high-mounted stop lamp assembly (1) from rear parcel
shelf finisher.
3. Remove high-mounted stop lamp finisher screws (A), then remove the high-mounted stop lamp finisher (1) from high-
mounted stop lamp.
Installation
Installation is in the reverse order of removal.
Removal and Installation of Rear Combination Lamp for Stop LampINFOID:0000000005394958
Refer to LT-89, "Removal and Installation".
ALLIA0830ZZ
PKIC1022E
PKIC1023E
Revision: January 20102010 Versa
Page 3068 of 3745
BACK-UP LAMPLT-73
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
LT
N
O P
BACK-UP LAMP
Wiring Diagram - BACK/L -INFOID:0000000005394960
Bulb ReplacementINFOID:0000000005394961
Refer to LT-88, "Bulb Replacement" .
ABLWA0680GB
Revision: January 20102010 Versa
Page 3069 of 3745
LT-74
< SERVICE INFORMATION >
BACK-UP LAMP
Removal and Installation
INFOID:0000000005394962
Refer to LT-89, "Removal and Installation" .
Revision: January 20102010 Versa
Page 3070 of 3745

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-75
< SERVICE INFORMATION >
C
D E
F
G H
I
J
L
M A
B
LT
N
O P
PARKING, LICENSE PLATE AND TAIL LAMPS
Component Parts and Har ness Connector LocationINFOID:0000000005394963
System DescriptionINFOID:0000000005394964
The control of the parking, license plate and tail lamp operation is dependent upon the position of lighting
switch. When the lighting switch is placed in the 1ST position, the BCM (body control module) receives input
signal requesting the parking, license plate and tail lamps to illuminate. This input signal is communicated to
the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU
(central processing unit) located in the IPDM E/R contro ls the tail lamp relay coil. This relay, when energized,
directs power to parking, license plate and tail lamps, which then illuminate.
Power is supplied at all times
• to ignition relay located in IPDM E/R,
• to tail lamp relay located in IPDM E/R,
• through 15A fuse (No. 52, located in IPDM E/R) and
• through 20A fuse (No. 53, located in IPDM E/R)
• to the CPU located in the IPDM E/R,
• through 40A fusible link (letter g , located in fuse and fusible link block)
• to BCM terminal 70,
• through 10A fuse [No. 8, located in fuse block (J/B)],
• to BCM terminal 57.
With the ignition switch in the ON or START position, power is supplied
• through 10A fuse [No. 6, located in fuse block (J/B)]
• to BCM terminal 38,
• to ignition relay located in IPDM E/R and
• through the ignition relay
• to the CPU of the IPDM E/R.
With the ignition switch in the ACC or ON position, power is supplied
• through 10A fuse [No. 20, located in fuse block (J/B)]
• to BCM terminal 11.
Ground is supplied
• to BCM terminal 67
• through grounds M20 and M61,
• to IPDM E/R terminals 59 and 39
• through grounds E15 and E24.
OPERATION BY LIGHTING SWITCH
With the lighting switch in the 1ST or 2ND positi on, the BCM receives an input signal requesting parking,
license plate and tail lamps to illuminate. This input si gnal is communicated to the IPDM E/R via the CAN com-
munication lines. The CPU, located in the IPDM E/R, c ontrols the tail lamp relay coil. When energized, the tail
lamp relay directs power
• through 10A fuse (No. 37, located in IPDM E/R),
• through IPDM E/R terminal 26
• to front combination lamp LH terminal 6, and
• through IPDM E/R terminal 27
1. IPDM E/R E45, E46 and E48 2. BCM M18 and M20 (view with glove
box removed)3. Combination switch (lighting switch)
M28
WKIA5554E
Revision: January 20102010 Versa
Page 3071 of 3745

LT-76
< SERVICE INFORMATION >
PARKING, LICENSE PLATE AND TAIL LAMPS
• to front combination lamp RH terminal 6,
• through IPDM E/R terminal 28
• to rear combination lamp LH terminal 4 and
• to license plate lamp LH and RH terminal 1,
• through IPDM E/R terminal 29
• to rear combination lamp RH terminal 4.
Ground is supplied
• to front combination lamp LH and RH terminal 7
• through grounds E15 and E24,
• to rear combination lamp LH terminal 1 and
• to license plate lamp LH and RH terminal 2
• through grounds B7 and B19, and
• to rear combination lamp RH terminal 1
• through grounds B117, B132 (all models) and D402 (with hatchback).
With power and ground supplied, parking, license plate and tail lamps illuminate.
COMBINATION SWITCH READING FUNCTION
Refer to BCS-4, "System Description" .
EXTERIOR LAMP BATTERY SAVER CONTROL
When the combination switch (lighting switch) is in the 1ST (or 2ND) position and the ignition switch is turned
from ON or ACC to OFF, the battery saver control feature is activated.
Under this condition, the parking, license and tail la mps remain illuminated for 5 minutes, then the parking,
license plate and tail lamps are turned off.
Exterior lamp battery saver control mode can be changed by the function setting of CONSULT-III.
CAN Communication System DescriptionINFOID:0000000005394965
Refer to LAN-7, "System Description" .
Revision: January 20102010 Versa
Page 3072 of 3745
PARKING, LICENSE PLATE AND TAIL LAMPS
LT-77
< SERVICE INFORMATION >
C
D E
F
G H
I
J
L
M A
B
LT
N
O P
SchematicINFOID:0000000005394966
WKWA4975E
