NISSAN LATIO 2010  Service Repair Manual INSTRUMENT PANEL ASSEMBLYIP-17
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
5. Insert a remover into upper space of instrument mask. : Pawl
6. Disengage pawls, and then remove instrument side

Page 2802 of 3745

NISSAN LATIO 2010  Service Repair Manual IP-18
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
13. Remove screws from instrument upper panel right side.
14. Lift the instrument upper panel up, disengage metal clips.: Metal clip
: Clip
15. Pu

Page 2803 of 3745

NISSAN LATIO 2010  Service Repair Manual INSTRUMENT PANEL ASSEMBLYIP-19
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
1. Pull instrument finisher E backward by approximately 30 degrees while disengaging the metal clips and pawl.
: Me

Page 2804 of 3745

NISSAN LATIO 2010  Service Repair Manual IP-20
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
9. Insert suitable tool into the bottom gap of side ventilator assem-bly after removing the instrument side mask, push against A and
B as shown to

Page 2805 of 3745

NISSAN LATIO 2010  Service Repair Manual INSTRUMENT PANEL ASSEMBLYIP-21
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
17. Remove screws (A) and metal clip (B), and remove combination meter.
Installation
Installation is in the reverse

Page 2806 of 3745

NISSAN LATIO 2010  Service Repair Manual IP-22
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
1. Insert a suitable tool into front side space of console mask, anddisengage metal clips.
: Metal clip
2. Disconnect harness connector, and then

Page 2807 of 3745

NISSAN LATIO 2010  Service Repair Manual INSTRUMENT PANEL ASSEMBLYIP-23
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
13. Disengage rear cup holder metal clips and pawls (without arm- rest).
: Metal clip
: Pawl
14. Remover rear cup h

Page 2808 of 3745

NISSAN LATIO 2010  Service Repair Manual IP-24
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
Disassembly
1. Remove screws of damper, and then remove damper.
2. Remove screws of glove box striker, and then remove glove box striker.
3. Remov
