Page 1001 of 3745

NISSAN LATIO 2010 Service Repair Manual COOLING FANCO-19 < ON-VEHICLE REPAIR > [HR16DE] C D E F G H I J K L M A CO NP O COOLING FAN Component (Models with A/C)INFOID:0000000005398189 Component (Models without A/C)INFOID:0000000005398190 1.

Page 1002 of 3745

NISSAN LATIO 2010 Service Repair Manual CO-20 < ON-VEHICLE REPAIR >[HR16DE] COOLING FAN Removal and Installation INFOID:0000000005398191 REMOVAL 1. Partially drain engine coolant from radiator. Refer to CO-12, "Changing Engine Coolant". CA

Page 1003 of 3745

NISSAN LATIO 2010 Service Repair Manual WATER PUMPCO-21 < ON-VEHICLE REPAIR > [HR16DE] C D E F G H I J K L M A CO NP O WATER PUMP Exploded ViewINFOID:0000000005398192 Removal and InstallationINFOID:0000000005398193 REMOVAL 1. Drain engine c

Page 1004 of 3745

NISSAN LATIO 2010 Service Repair Manual CO-22 < ON-VEHICLE REPAIR >[HR16DE] WATER PUMP • Tighten bolts in numerical order as shown. Water pump pulley. CAUTION: Never install mounting bolts (A) to oblong holes (B). • Water pump pulley (

Page 1005 of 3745

NISSAN LATIO 2010 Service Repair Manual THERMOSTATCO-23 < ON-VEHICLE REPAIR > [HR16DE] C D E F G H I J K L M A CO NP O THERMOSTAT Exploded ViewINFOID:0000000005398195 Removal and InstallationINFOID:0000000005398196 REMOVAL 1. Drain engine c

Page 1006 of 3745

NISSAN LATIO 2010 Service Repair Manual CO-24 < ON-VEHICLE REPAIR >[HR16DE] THERMOSTAT • Install thermostat (2) into the cylinder block (1) with jiggle valve (A) facing upwards. Water Inlet. After installation, fix water inlet clip (A) o

Page 1007 of 3745

NISSAN LATIO 2010 Service Repair Manual WATER OUTLETCO-25 < ON-VEHICLE REPAIR > [HR16DE] C D E F G H I J K L M A CO NP O WATER OUTLET Exploded ViewINFOID:0000000005398198 Removal and InstallationINFOID:0000000005398199 REMOVAL 1. Drain engi

Page 1008 of 3745

NISSAN LATIO 2010 Service Repair Manual CO-26 < ON-VEHICLE REPAIR >[HR16DE] WATER OUTLET 10. Remove engine coolant temperature sens or from water outlet, if necessary. CAUTION: • Handle carefully to avoid any shock to engine coolant temp
