Page 3081 of 3745

NISSAN LATIO 2010 Service Repair Manual LT-86 < SERVICE INFORMATION > PARKING, LICENSE PLATE AND TAIL LAMPS 2. Remove the license plate lamp bulb socket (1) and remove thelicense plate lamp bulb (2). 3. Installation is in the reverse order

Page 3082 of 3745

NISSAN LATIO 2010 Service Repair Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-87 < SERVICE INFORMATION > C D E F G H I J L M A B LT N O P 2. Remove the license plate lamp assembly (1). Installation Installation is in the reverse order of

Page 3083 of 3745

NISSAN LATIO 2010 Service Repair Manual LT-88 < SERVICE INFORMATION > REAR COMBINATION LAMP REAR COMBINATION LAMP ComponentINFOID:0000000005394978 Hatchback Bulb ReplacementINFOID:0000000005394979 HATCHBACK CAUTION: It is not necessary to r

Page 3084 of 3745

NISSAN LATIO 2010 Service Repair Manual REAR COMBINATION LAMPLT-89 < SERVICE INFORMATION > C DE F G H I J L M A B LT N O P 2. Turn bulb socket counterclockwise and unlock it. 3. Remove the stop/tail lamp bulb (1), turn signal lamp bulb (2),

Page 3085 of 3745

NISSAN LATIO 2010 Service Repair Manual LT-90 < SERVICE INFORMATION > REAR COMBINATION LAMP 2. Remove the bulbs from the rear combination lamp harness, as necessary. 3. Remove the bumper stay (hatchback only). 4. Remove the rear combination

Page 3086 of 3745

NISSAN LATIO 2010 Service Repair Manual INTERIOR LAMPLT-91 < SERVICE INFORMATION > C DE F G H I J L M A B LT N O P INTERIOR LAMP Map LampINFOID:0000000005394982 BULB REPLACEMENT 1. Remove the map lamp lens (1). 2. Remove the bulb from lamp.

Page 3087 of 3745

NISSAN LATIO 2010 Service Repair Manual LT-92 < SERVICE INFORMATION > INTERIOR LAMP 1. Remove luggage compartment lamp from the luggage side finisher LH. 2. Remove luggage compartment lamp cover. 3. Press tab A and remove the bulb. 4. Insta

Page 3088 of 3745

NISSAN LATIO 2010 Service Repair Manual INTERIOR LAMPLT-93 < SERVICE INFORMATION > C DE F G H I J L M A B LT N O P Removal 1. Remove the lens using a suitable tool. 2. Remove the bulb. Installation Installation is in the reverse order of re
