Page 1185 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT-152 < SERVICE INFORMATION >[RE0F08B] TROUBLE DIAGNOSIS FOR SYMPTOMS Perform self-diagnosis check. Refer to CVT-48, "CONSULT-III Function (TRANSMISSION)" . Is any malfunction detec ted by self-dia

Page 1186 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT SHIFT LOCK SYSTEMCVT-153 < SERVICE INFORMATION > [RE0F08B] D E F G H I J K L M A B CVT N O P CVT SHIFT LOCK SYSTEM DescriptionINFOID:0000000005397994 WITH INTELLIGENT KEY • The mechanical key in

Page 1187 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT-154 < SERVICE INFORMATION >[RE0F08B] CVT SHIFT LOCK SYSTEM Shift Lock System Electrical Parts Location INFOID:0000000005397995 1. Key interlock cable (Without Intelli- gent Key) 2. Key cylinder (W

Page 1188 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT SHIFT LOCK SYSTEMCVT-155 < SERVICE INFORMATION > [RE0F08B] D E F G H I J K L M A B CVT N O P Wiring Diagram - CVT - SHIFTINFOID:0000000005397996 Diagnosis ProcedureINFOID:0000000005397997 SYMPTOM

Page 1189 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT-156 < SERVICE INFORMATION >[RE0F08B] CVT SHIFT LOCK SYSTEM • Selector lever can be moved from “P” position with ignition key in ON position and brake pedal released. • Selector lever can

Page 1190 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT SHIFT LOCK SYSTEMCVT-157 < SERVICE INFORMATION > [RE0F08B] D E F G H I J K L M A B CVT N O P 2. Check voltage between CVT shift selector harness connector terminal 5 and ground. OK or NG OK >> GO

Page 1191 of 3745

NISSAN LATIO 2010 Service Repair Manual CVT-158 < SERVICE INFORMATION >[RE0F08B] CVT SHIFT LOCK SYSTEM 3. Check continuity between CVT shift selector harness connector terminal 6 and ground. 4. Connect CVT shift selector harness connector.

Page 1192 of 3745

NISSAN LATIO 2010 Service Repair Manual TCM CVT-159 < SERVICE INFORMATION > [RE0F08B] D E F G H I J K L M A B CVT N O P TCM Removal and InstallationINFOID:0000000005397998 COMPONENTS REMOVAL CAUTION: When replacing TCM and transaxle assembl
