Page 2753 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-36 < SERVICE INFORMATION > POWER WINDOW SYSTEM 1. Disconnect main power window and door lock/unlock switch. 2. Check continuity between main power window and door lock/ unlock switch connector and

Page 2754 of 3745

NISSAN LATIO 2010 Service Repair Manual POWER WINDOW SYSTEMGW-37 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P OK or NG OK >> Replace main power window and door lock/unlock switch. Refer to EI-34, "Removal and Installa- tion" . N

Page 2755 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-38 < SERVICE INFORMATION > POWER WINDOW SYSTEM Check the signal between main power window and door lock/unlock switch connector and ground with oscilloscope. OK or NG OK >> Replace main power windo

Page 2756 of 3745

NISSAN LATIO 2010 Service Repair Manual POWER WINDOW SYSTEMGW-39 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P Without CONSULT-III Check voltage between BCM connector and ground. OK or NG OK >> Front door switch is OK. NG >> GO TO

Page 2757 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-40 < SERVICE INFORMATION > POWER WINDOW SYSTEM 1. Turn ignition switch ON. 2. Check voltage between rear power window switch LH connectorD203 terminal 1 and ground. OK or NG OK >> Replace rear powe

Page 2758 of 3745

NISSAN LATIO 2010 Service Repair Manual POWER WINDOW SYSTEMGW-41 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P 1. Turn ignition switch OFF. 2. Disconnect rear power window switch LH. 3. Check continuity between rear power window s

Page 2759 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-42 < SERVICE INFORMATION > POWER WINDOW SYSTEM NG >> Repair or replace harness. Rear Power Window Motor RH Circuit InspectionINFOID:0000000005396761 1.CHECK REAR POWER WINDOW SWITCH RH OUTPUT SIGN

Page 2760 of 3745

NISSAN LATIO 2010 Service Repair Manual POWER WINDOW SYSTEMGW-43 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P 4.CHECK REAR POWER WINDOW SWITCH RH CIRCUIT 1. Disconnect main power window and door lock/unlock switch. 2. Check conti
