Page 865 of 3745

NISSAN LATIO 2010 Service Repair Manual BRAKE MASTER CYLINDERBR-17 < SERVICE INFORMATION > C DE G H I J K L M A B BR N O P DISASSEMBLY CAUTION: While working, cover primary piston rod wi th cloth to prevent it from being damaged. 1. Secure

Page 866 of 3745

NISSAN LATIO 2010 Service Repair Manual BR-18 < SERVICE INFORMATION > BRAKE MASTER CYLINDER 9. Tap flange using a soft block such as wood, and carefully pullsecondary piston assembly straight out to prevent cylinder inner wall from being da

Page 867 of 3745

NISSAN LATIO 2010 Service Repair Manual BRAKE MASTER CYLINDERBR-19 < SERVICE INFORMATION > C DE G H I J K L M A B BR N O P 5. Be careful not to damage rod of primary piston with the cloth. Then insert snap ring to cylinder body while pushin

Page 868 of 3745

NISSAN LATIO 2010 Service Repair Manual BR-20 < SERVICE INFORMATION > BRAKE BOOSTER BRAKE BOOSTER On Board InspectionINFOID:0000000005396992 OPERATING CHECK • With the engine stopped, change the vacuum to the atmospheric pressure by depre

Page 869 of 3745

NISSAN LATIO 2010 Service Repair Manual BRAKE BOOSTERBR-21 < SERVICE INFORMATION > C DE G H I J K L M A B BR N O P Removal and InstallationINFOID:0000000005396993 REMOVAL CAUTION: • Be careful not to splash brake fluid on painted areas su

Page 870 of 3745

NISSAN LATIO 2010 Service Repair Manual BR-22 < SERVICE INFORMATION > BRAKE BOOSTER 4. Remove snap pin and clevis pin on the clevis of the brakebooster, and disconnect the input rod from the brake pedal. 5. Remove brake pedal nuts on pedal

Page 871 of 3745

NISSAN LATIO 2010 Service Repair Manual VACUUM LINESBR-23 < SERVICE INFORMATION > C DE G H I J K L M A B BR N O P VACUUM LINES ComponentINFOID:0000000005396994 Removal and InstallationINFOID:0000000005396995 REMOVAL 1. Disconnect the vacuum

Page 872 of 3745

NISSAN LATIO 2010 Service Repair Manual BR-24 < SERVICE INFORMATION > VACUUM LINES Use a hand vacuum pump to check the built-in valve. Replace the vacuum hose with the built-in check valve as an assem- bly if the vacuum hose is out of speci
