EC-536
< SERVICE INFORMATION >[MR18DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Without CONSULT-III
1. Remove fuel tank. Refer to
FL-12, "Removal and Installation".
2. Drain fuel from the tank as follows:
a. Remove fuel gauge retainer.
b. Drain fuel from the tank using a handy pump into a fuel container.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows. Blow air into the refueling EVAP vapor cut valv e (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit. Always replace O-ring with new one.
c. Put fuel tank upside down.
d. Apply vacuum pressure to hose end [ −13.3 kPa ( −100 mmHg, − 3.94 inHg)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
1. Filler tube 2. Recirculation line3. EVAP/ORVR line
4. Vacuum/pressure handy pump 5. Fuel tank
BBIA0694E
Revision: January 20102010 Versa
Page 1802 of 3745
ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-537
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
DRAIN FILTER
1. Check visually for insect nests in the drain filter air inlet.
2. Check visually for cracks or flaws in the appearance.
3. Check visually for cracks or flaws in the hose.
4. Blow air into port A and check that it flows freely out of port B.
5. Block port B.
6. Blow air into port A and check that there is no leakage.
7. If NG, replace drain filter.
1. Filler tube
2. Recirculation line3. EVAP/ORVR line
4. Vacuum/pressure handy pump 5. Fuel tank
BBIA0694E
PBIB3641E
Revision: January 20102010 Versa
Page 1803 of 3745
![NISSAN LATIO 2010 Service Repair Manual EC-538
< SERVICE INFORMATION >[MR18DE]
POSITIVE CRANKCASE VENTILATION
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000005532396
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake NISSAN LATIO 2010 Service Repair Manual EC-538
< SERVICE INFORMATION >[MR18DE]
POSITIVE CRANKCASE VENTILATION
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000005532396
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake](/manual-img/5/57358/w960_57358-1802.png)
EC-538
< SERVICE INFORMATION >[MR18DE]
POSITIVE CRANKCASE VENTILATION
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000005532396
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake manifold.
The positive crankcase ventilation (PCV) valve is prov
ided to conduct crankcase blow-by gas to the intake
manifold. During partial throttle operation of the engine, the intake manifold sucks the blow-by gas through the
PCV valve. Normally, the capacity of the valve is suff icient to handle any blow-by and a small amount of venti-
lating air. The ventilating air is then drawn from the air inlet tubes into the crankcase. In this process the air
passes through the hose connecting air inlet tubes to rocker cover.
Under full-throttle condition, the manifold vacuum is in sufficient to draw the blow-by flow through the valve.
The flow goes through the hose connection in the reverse direction.
On vehicles with an excessively high blow-by, the valve does not
meet the requirement. This is because some of the flow will go
through the hose connection to the air inlet tubes under all condi-
tions.
Component InspectionINFOID:0000000005532397
PCV (POSITIVE CRANKCASE VENTILATION) VALVE
With engine running at idle, remove PCV valve from rocker cover. A
properly working valve makes a hissing noise as air passes through
it. A strong vacuum should be felt immediately when a finger is
placed over valve inlet.
JMBIA0686GB
PBIB1588E
PBIB1589E
Revision: January 20102010 Versa
Page 1804 of 3745
POSITIVE CRANKCASE VENTILATIONEC-539
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PCV VALVE VENTILATION HOSE
1. Check hoses and hose connections for leaks.
2. Disconnect all hoses and clean with compressed air. If any hose
cannot be freed of obstructions, replace.
S-ET277
Revision: January 20102010 Versa
Page 1805 of 3745
EC-540
< SERVICE INFORMATION >[MR18DE]
NVIS (NISSAN VEHICLE I
MMOBILIZER SYSTEM-NATS)
NVIS (NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS)
DescriptionINFOID:0000000005532398
•If the security indicator illuminates with the igni tion switch ON or DTC P1610 - P1615 is displayed in
“SELF DIAGNOSTIC RESULT” mode, perform the trouble diagnosis for corresponding to the
detected DTC. Refer to EC-503, "
U0101-U1001".
• Check that no DTC is displayed in “SELF DIAGNOSIS RESULT” mode of “BCM” before erasing the
detected DTC in “ENGINE” mode with CONSULT-III.
• When replacing ECM, refer to EC-579, "
Procedure After Replacing ECM".
Revision: January 20102010 Versa
Page 1806 of 3745
![NISSAN LATIO 2010 Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-541
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON BOARD DIAGNOSTIC (OBD) SYSTEM
IntroductionINFOID:0000000005532399
The ECM has an on board dia NISSAN LATIO 2010 Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-541
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON BOARD DIAGNOSTIC (OBD) SYSTEM
IntroductionINFOID:0000000005532399
The ECM has an on board dia](/manual-img/5/57358/w960_57358-1805.png)
ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-541
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON BOARD DIAGNOSTIC (OBD) SYSTEM
IntroductionINFOID:0000000005532399
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
*: Service $0A is not applied for regions where it is not mandated.
The above information can be checked using procedures listed in the table below.
×
: Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator lamp (MIL) on the instrument panel lights up when the same malfunction is detected
in two consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode.
(Refer to EC-590, "
Fail-Safe Chart".)
Two Trip Detection LogicINFOID:0000000005532400
When a malfunction is detected for the first time, 1st tr ip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MIL will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MIL lights up. The MIL lights up at the same time when the DTC is stored. <2nd
trip> The “trip” in the “Two Trip Detection Logic” m eans a driving mode in which self-diagnosis is performed
during vehicle operation. Specific on board diagnostic item s will cause the ECM to light up or blink the MIL,
and store DTC and Freeze Frame data, even in the 1st trip, as shown below.
× : Applicable —: Not applicable
Emission-related diagnostic information Diagnostic service
Diagnostic Trouble Code (DTC) Service $03 of SAE J1979 /ISO 15031-5
Freeze Frame data Service $02 of SAE J1979/ISO 15031-5
System Readiness Test (SRT) code Service $01 of SAE J1 979/ISO 15031-5
1st Trip Diagnostic Trouble Code (1st Trip DTC) Service $07 of SAE J1979/ISO 15031-5
1st Trip Freeze Frame data —
Test values and Test limits Service $06 of SAE J1979/ISO 15031-5
Calibration ID Service $09 of SAE J1979/ISO 15031-5
Permanent Diagnostic Trouble Code (Permanent DTC) Service $0A* of SAE J1979/ISO 15031-5
DTC 1st trip DTCFreeze
Frame data 1st trip Freeze
Frame data SRT code SRT status Test value Permanent
DTC status
CONSULT-III ×× × × ×× —×
GST ×× × —××××
ECM ××*— — — ×——
Items MIL
DTC1st trip DTC
1st trip 2nd trip
1st trip
displaying 2nd trip
displaying 1st trip
displaying 2nd trip
display-
ing
Blinking Lighting
up Blinking
Lighting
up
Misfire (Possible three way catalyst
damage) — DTC: P0300 - P0304 is
being detected ×
———— — ×—
Misfire (Possible three way catalyst
damage) — DTC: P0300 - P0304 is
being detected ——
×—— ×——
One trip detection diagnoses
(Refer to EC-542, "
Emission-relat-
ed Diagnostic Information".) —
×—— ×———
Except above — — —×— ×× —
Revision: January 20102010 Versa
Page 1807 of 3745
![NISSAN LATIO 2010 Service Repair Manual EC-542
< SERVICE INFORMATION >[MR18DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by MIL lighting up when there is
malfunction on eng NISSAN LATIO 2010 Service Repair Manual EC-542
< SERVICE INFORMATION >[MR18DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by MIL lighting up when there is
malfunction on eng](/manual-img/5/57358/w960_57358-1806.png)
EC-542
< SERVICE INFORMATION >[MR18DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by MIL lighting up when there is
malfunction on engine control system.
Therefore, when electrical controlled throttle and part
of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine cont rol system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected, and demands the
driver to repair the malfunction.
Emission-related Diagnostic InformationINFOID:0000000005532401
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
× : Applicable —: Not applicable
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-III screen terms) DTC*
1
SRT
code Trip MIL Permanent
DTC
group
*4Reference
CONSULT-III
GST*
2ECM*3
LOST COMM (TCM) U0101
0101*5—1 ×BEC-639
LOST COMM (BCM) U0140
0140*5—1 ×BEC-641
CAN COMM CIRCUIT U1001
1001*5—2 — — EC-643
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000
——
Flashing*6— EC-565
INT/V TIM CONT-B1 P0011 0011×2 × BEC-645
A/F SEN1 HTR (B1) P0031 0031 — 2 ×BEC-649
A/F SEN1 HTR (B1) P0032 0032 — 2 ×BEC-649
HO2S2 HTR (B1) P0037 0037 — 2 ×BEC-654
HO2S2 HTR (B1) P0038 0038 — 2 ×BEC-654
INT/V TIM V/CIR-B1 P0075 0075 — 2 ×BEC-659
MAF SEN/CIRCUIT-B1 P0101 0101 — 2 ×BEC-664
MAF SEN/CIRCUIT-B1 P0102 0102 — 1 ×BEC-672
MAF SEN/CIRCUIT-B1 P0103 0103 — 1 ×BEC-672
IAT SEN/CIRCUIT-B1 P0112 0112 — 2 ×BEC-679
IAT SEN/CIRCUIT-B1 P0113 0113 — 2 ×BEC-679
ECT SEN/CIRC P0116 0116 — 2 ×BEC-683
ECT SEN/CIRC P0117 0117 — 1 ×BEC-686
ECT SEN/CIRC P0118 0118 — 1 ×BEC-686
TP SEN 2/CIRC-B1 P0122 0122 — 1 ×BEC-691
TP SEN 2/CIRC-B1 P0123 0123 — 1 ×BEC-691
ECT SENSOR P0125 0125 — 2 ×BEC-696
IAT SENSOR-B1 P0127 0127 — 2 ×BEC-699
THERMSTAT FNCTN P0128 0128 — 2 ×BEC-702
A/F SENSOR1 (B1) P0130 0130 — 2 ×AEC-704
A/F SENSOR1 (B1) P0131 0131 — 2 ×BEC-710
A/F SENSOR1 (B1) P0132 0132 — 2 ×BEC-716
HO2S2 (B1) P0137 0137×2 × AEC-722
HO2S2 (B1) P0138 0138×2 × AEC-731
HO2S2 (B1) P0139 0139×2 × AEC-741
A/F SENSOR1 (B1) P014C 014C — 2 ×AEC-750
Revision: January 20102010 Versa
Page 1808 of 3745
![NISSAN LATIO 2010 Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-543
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OA/F SENSOR1 (B1)
P014D 014D — 2 ×AEC-750
A/F SENSOR1 (B1) P015A 015A — 2 ×AEC-750
A/F SENSO NISSAN LATIO 2010 Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-543
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OA/F SENSOR1 (B1)
P014D 014D — 2 ×AEC-750
A/F SENSOR1 (B1) P015A 015A — 2 ×AEC-750
A/F SENSO](/manual-img/5/57358/w960_57358-1807.png)
ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-543
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OA/F SENSOR1 (B1)
P014D 014D — 2 ×AEC-750
A/F SENSOR1 (B1) P015A 015A — 2 ×AEC-750
A/F SENSOR1 (B1) P015B 015B — 2 ×AEC-750
FUEL SYS-LEAN-B1 P0171 0171 — 2 ×BEC-758
FUEL SYS-RICH-B1 P0172 0172 — 2 ×BEC-764
FTT SENSOR P0181 0181 — 2 ×BEC-770
FTT SEN/CIRCUIT P0182 0182 — 2 ×BEC-774
FTT SEN/CIRCUIT P0183 0183 — 2 ×BEC-774
TP SEN 1/CIRC-B1 P0222 0222 — 1 ×BEC-778
TP SEN 1/CIRC-B1 P0223 0223 — 1 ×BEC-778
MULTI CYL MISFIRE P0300 0300 — 1 or 2 ×BEC-783
CYL 1 MISFIRE P0301 0301 — 1 or 2 ×BEC-783
CYL 2 MISFIRE P0302 0302 — 1 or 2 ×BEC-783
CYL 3 MISFIRE P0303 0303 — 1 or 2 ×BEC-783
CYL 4 MISFIRE P0304 0304 — 1 or 2 ×BEC-783
KNOCK SEN/CIRC-B1 P0327 0327 — 2 — —EC-789
KNOCK SEN/CIRC-B1 P0328 0328 — 2 — —EC-789
CKP SEN/CIRCUIT P0335 0335 — 2 ×BEC-793
CMP SEN/CIRC-B1 P0340 0340 — 2 ×BEC-799
TW CATALYST SYS-B1 P0420 0420× 2 ×AEC-805
EVAP PURG FLOW/MON P0441 0441×2 × AEC-810
EVAP SMALL LEAK P0442 0442×2 × AEC-815
PURG VOLUME CONT/V P0443 0443 — 2 ×AEC-822
PURG VOLUME CONT/V P0444 0444 — 2 ×BEC-830
PURG VOLUME CONT/V P0445 0445 — 2 ×BEC-830
VENT CONTROL VALVE P0447 0447 — 2 ×BEC-836
VENT CONTROL VALVE P0448 0448 — 2 ×BEC-842
EVAP SYS PRES SEN P0451 0451 — 2 ×AEC-848
EVAP SYS PRES SEN P0452 0452 — 2 ×BEC-851
EVAP SYS PRES SEN P0453 0453 — 2 ×BEC-858
EVAP GROSS LEAK P0455 0455 — 2 ×AEC-866
EVAP VERY SML LEAK P0456 0456
×*72 × AEC-873
FUEL LEV SEN SLOSH P0460 0460 — 2 ×AEC-881
FUEL LEVEL SENSOR P0461 0461 — 2 ×BEC-883
FUEL LEVL SEN/CIRC P0462 0462 — 2 ×BEC-885
FUEL LEVL SEN/CIRC P0463 0463 — 2 ×BEC-885
VEH SPEED SEN/CIRC*8P0500 0500 — 2 ×BEC-887
ISC SYSTEM P0506 0506 — 2 ×BEC-889
ISC SYSTEM P0507 0507 — 2 ×BEC-891
ECM P0605 0605 — 1 or 2 — or ×B EC-893
ECM P0607 0607 —1 (CVT)
1 (A/T)
2 (M/T) ×
(CVT)
× (A/T)
— (M/T) B
EC-893
Items
(CONSULT-III screen terms) DTC*
1
SRT
code Trip MIL Permanent
DTC
group
*4Reference
CONSULT-III
GST*
2ECM*3
Revision: January 20102010 Versa
