Page 2337 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-36 < ON-VEHICLE REPAIR > DOOR FINISHER Removal 1. Open rear door and rear door window. 2. Release the rear door inside handle escutcheon pawls, thenslide the escutcheon rearward to re move from rea

Page 2338 of 3745

NISSAN LATIO 2010 Service Repair Manual DOOR FINISHEREI-37 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P 6. Release the clips, then lift rear door finisher upward to remove it from door body panel. Installation Installation is in th

Page 2339 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-38 < ON-VEHICLE REPAIR > BACK DOOR TRIM BACK DOOR TRIM Removal and InstallationINFOID:0000000005396838 REMOVAL CAUTION: • Insert a suitable tool between panel on vehicle and clips (asindicated wi

Page 2340 of 3745

NISSAN LATIO 2010 Service Repair Manual BODY SIDE TRIMEI-39 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P BODY SIDE TRIM ComponentINFOID:0000000005396839 Hatchback Models LIIA2574E 1. Front pillar garnish 2. Front body side welt 3.

Page 2341 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-40 < ON-VEHICLE REPAIR > BODY SIDE TRIM Sedan Models Removal and InstallationINFOID:0000000005396840 WARNING: Do not reuse center pillar upper garnish if removed. CAUTION: • Insert a suitable too

Page 2342 of 3745

NISSAN LATIO 2010 Service Repair Manual BODY SIDE TRIMEI-41 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P • When releasing molded-in pawls or resin clips, follow the steps below to prevent garnish or clip damage. FRONT PILLAR GAR

Page 2343 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-42 < ON-VEHICLE REPAIR > BODY SIDE TRIM Release the clips, then remove front kicking plate outer. Installation Installation is in the reverse order of removal. REAR KICKING PLATE INNER Removal Rele

Page 2344 of 3745

NISSAN LATIO 2010 Service Repair Manual BODY SIDE TRIMEI-43 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P 4. Release the clips, then remove center pillar lower garnish. Installation Installation is in the reverse order of removal. C
