Page 961 of 3745

NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS BRC-71 < SERVICE INFORMATION > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P NG >> Repair or replace as necessary. 3.CHECK YAW RATE/SIDE/DECEL G SENSOR PO

Page 962 of 3745

NISSAN LATIO 2010 Service Repair Manual BRC-72 < SERVICE INFORMATION >[VDC/TCS/ABS] TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS 2. Select “YAW RATE SEN”, “SIDE G-SENSOR” in “Data Monitor” and check Yaw rate/side/decel G sensor

Page 963 of 3745

NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS BRC-73 < SERVICE INFORMATION > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P 1. Check voltage between ABS actuator and electric unit (control unit) harnes

Page 964 of 3745

NISSAN LATIO 2010 Service Repair Manual BRC-74 < SERVICE INFORMATION >[VDC/TCS/ABS] TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS 2. Check resistance between ABS actuator and electric unit (con- trol unit) connector E33 and ground. OK or NG

Page 965 of 3745

NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS BRC-75 < SERVICE INFORMATION > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P 1. Disconnect stop lamp switch connector. 2. Check continuity between ABS act

Page 966 of 3745

NISSAN LATIO 2010 Service Repair Manual BRC-76 < SERVICE INFORMATION >[VDC/TCS/ABS] TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS OK or NG OK >> Check the battery for loose terminals, low voltage, etc. Repair as necessary. NG >> Repair the c

Page 967 of 3745

NISSAN LATIO 2010 Service Repair Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS BRC-77 < SERVICE INFORMATION > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P YES >> GO TO 5 NO >> Repair or replace malfunctioning components. 5.CHECK BRA

Page 968 of 3745

NISSAN LATIO 2010 Service Repair Manual BRC-78 < SERVICE INFORMATION >[VDC/TCS/ABS] TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS 1. Turn ignition switch OFF. 2. Disconnect stop lamp switch connector. 3. Check continuity between stop lamp sw
