Page 2321 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-20 < ON-VEHICLE REPAIR > REAR BUMPER 7. Release rear bumper upper retainer (1), then pull rear bumperfascia outward away from rear of vehicle. 8. Release the clips and remove the rear bumper corner

Page 2322 of 3745

NISSAN LATIO 2010 Service Repair Manual FRONT GRILLEEI-21 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P FRONT GRILLE Removal and InstallationINFOID:0000000005396826 REMOVAL 1. Open hood assembly. 2. Remove the clips, then remove upp

Page 2323 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-22 < ON-VEHICLE REPAIR > COWL TOP COWL TOP Removal and InstallationINFOID:0000000005396827 REMOVAL 1. Remove front wiper arm RH/LH from vehicle. Refer to WW-20, "Removal and Installation of Front W

Page 2324 of 3745

NISSAN LATIO 2010 Service Repair Manual COWL TOPEI-23 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P 5. Release the cowl extension clip (1) by prying the center pawls apart and pulling clip outward. Remove remaining clips, then remov

Page 2325 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-24 < ON-VEHICLE REPAIR > FENDER PROTECTOR FENDER PROTECTOR ComponentINFOID:0000000005396828 Removal and InstallationINFOID:0000000005396829 FRONT FENDER PROTECTOR Removal 1. Remove front fender pro

Page 2326 of 3745

NISSAN LATIO 2010 Service Repair Manual ROOF SIDE MOLDINGEI-25 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P ROOF SIDE MOLDING ComponentINFOID:0000000005396830 Hatchback Models Sedan Models Removal and InstallationINFOID:00000000053

Page 2327 of 3745

NISSAN LATIO 2010 Service Repair Manual EI-26 < ON-VEHICLE REPAIR > ROOF SIDE MOLDING Make sure front edge of roof side molding contacts windshield mold- ing with no gap. • For setting a new clip A or B, use Epoxy Adhesive DP-100C madeby

Page 2328 of 3745

NISSAN LATIO 2010 Service Repair Manual DOOR OUTSIDE MOLDINGEI-27 < ON-VEHICLE REPAIR > C DE F G H J K L M A B EI N O P DOOR OUTSIDE MOLDING ComponentINFOID:0000000005396832 Hatchback Models WIIA1410E 1. Front door outside molding 2. Rear d
