Page 2953 of 3061
TRANSFER ASSEMBLY
TF-131
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
1. Remove the rear case bolts.
2. Remove the rear case from the center case.
3. Remove the dust cover using suitable tool.
4. Remove the rear oil seal using suitable tool.
CAUTION:
Do not damage rear case.
5. Remove the breather tube.
Front Case
1. Remove the rear case assembly. Refer to TF-128, "Disassembly and Assembly".
2. Remove the lock pin nut.
SDIA2092E
SDIA2093E
SDIA2094E
SDIA2095E
Page 2954 of 3061
TF-132
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
3. Remove the lock pin using suitable tool.
4. Remove the shift lever.
5. Remove the side oil seal from the front case using suitable tool.
CAUTION:
Do not damage front case or shift cross.
6. Remove the check plug, check spring and check ball.
7. Remove the wait detection switch.
8. Remove the self-lock nut from the companion flange using Tool.
9. Put a matching mark on top of the front drive shaft thread in line
with the mark on the companion flange.
CAUTION:
Use paint to make the matching mark on the front drive
shaft thread. Never damage the front drive shaft.
SDIA2150E
SDIA3381E
WDIA0196E
Tool number : KV40104000 ( — )
SDIA2841E
SDIA2779E
Page 2955 of 3061
TRANSFER ASSEMBLY
TF-133
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
10. Remove the companion flange using suitable tool.
11. Remove the center case bolts, harness bracket and air breather
hose clamp.
12. Remove the filler plug and gasket.
13. Separate the center case from the front case. Then remove the
center case from the front case by prying it up using suitable
tools.
CAUTION:
Do not damage the mating surfaces.
14. Remove the shift rod components together with the 2-4 sleeve
and L-H sleeve.
15. Remove the shift cross from the front case.
16. Remove the 2-4 sleeve and L-H sleeve from the 2-4 fork and L-
H fork respectively.
WDIA0133E
SDIA2100E
SDIA2101E
SDIA2140E
SMT992C
Page 2956 of 3061
TF-134
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
17. Drive out the retaining pin from the shift rod using suitable tool.
18. Remove the L-H fork, 2-4 fork, shift fork spring and fork guide
from the shift rod.
19. Remove the input oil seal from the front case using suitable tool.
CAUTION:
Do not damage front case or sun gear.
20. Remove the snap ring from the sun gear.
CAUTION:
Do not damage front case or sun gear.
21. Remove the sun gear assembly and planetary carrier assembly
from the front case using Tool.
WDIA0134E
SDIA2142E
SDIA3382E
SDIA2144E
Tool number : ST35300000 ( — )
SDIA2145E
Page 2957 of 3061
TRANSFER ASSEMBLY
TF-135
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
22. Remove the snap ring and internal gear using suitable tool.
23. Remove the front oil seal using suitable tool.
CAUTION:
Do not damage front case.
24. Remove the snap ring from the front case.
25. Remove the input front bearing from the front case using Tool.
26. Remove the snap ring from the planetary carrier assembly using
suitable tool.
SMT004D
SDIA2170E
SDIA2171E
Tool number : ST33200000 (J-26082)
SDIA2178E
SDIA2146E
Page 2958 of 3061
TF-136
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
27. Remove the sun gear assembly from the planetary carrier
assembly.
28. Remove the snap ring from the sun gear assembly using suit-
able tool.
29. Remove the carrier bearing from the sun gear using Tools.
30. Remove the needle bearing from the sun gear using Tool.
31. Remove the metal bushing from the sun gear using Tools.
SDIA2147E
SDIA2148E
Tool number A: ST35300000 ( — )
B: ST30031000 ( — )
SDIA2149E
Tool number : ST33710000 ( — )
SDIA2354E
Tool number A: ST33710000 ( — )
B: ST35325000 ( — )
C: KV381054S0 (J-34286)
SDIA2168E
Page 2959 of 3061
TRANSFER ASSEMBLY
TF-137
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P Center Case
1. Remove the rear case assembly. Refer to TF-128, "Disassembly and Assembly".
2. Remove the front case assembly. Refer to TF-128, "
Disassembly and Assembly".
3. Hold the front drive shaft with one hand and tap to remove the
front drive shaft with the drive chain.
CAUTION:
Do not tap drive chain.
4. Remove the front drive shaft front bearing using Tools.
5. Remove the front drive shaft rear bearing using Tools.
6. Remove the neutral-4LO and ATP switches.
SMT900C
Tool number A: ST33052000 ( — )
B: ST30031000 ( — )
SDIA2106E
Tool number A: ST33052000 ( — )
B: ST30031000 ( — )
SDIA2107E
SDIA2096E
Page 2960 of 3061
TF-138
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
7. Remove the bolts and main oil pump cover.
8. Remove the outer gear, inner gear and main oil pump housing
from the center case.
9. Remove the seal ring from the main oil pump cover.
10. Remove the stem bleeder from the bleed hole.
11. Remove the snap ring and washer holder from the mainshaft.
SDIA2130E
SDIA2131E
SDIA2783E
SDIA2780E
SDIA2104E
