Page 89 of 3061

INFINITI QX56 2007 Factory Service Manual A/T CONTROL SYSTEM AT-19 < SERVICE INFORMATION > D E F G H I J K L MA B AT N O P A/T CONTROL SYSTEM Cross-Sectional View (2WD models)INFOID:0000000003532227 1. Front planetary gear 2. Mid planetary ge

Page 90 of 3061

INFINITI QX56 2007 Factory Service Manual AT-20 < SERVICE INFORMATION > A/T CONTROL SYSTEM Cross-Sectional View (4WD models) INFOID:0000000003532228 Shift MechanismINFOID:0000000003532229 The automatic transmission uses compact triple planeta

Page 91 of 3061

INFINITI QX56 2007 Factory Service Manual A/T CONTROL SYSTEM AT-21 < SERVICE INFORMATION > D E F G H I J K L MA B AT N O P FUNCTION OF CLUTCH AND BRAKE CLUTCH AND BAND CHART 1. Front brake 2. Input clutch 3. Direct clutch 4. High and low r

Page 92 of 3061

INFINITI QX56 2007 Factory Service Manual AT-22 < SERVICE INFORMATION > A/T CONTROL SYSTEM • —Operates • —Operates during “progressive” acceleration. • —Operates and effects power transmission while coasting. • —Line press

Page 93 of 3061

INFINITI QX56 2007 Factory Service Manual A/T CONTROL SYSTEM AT-23 < SERVICE INFORMATION > D E F G H I J K L MA B AT N O P Since both the forward brake and the reverse brake are released, torque from the input shaft drive is not trans- mitted

Page 94 of 3061

INFINITI QX56 2007 Factory Service Manual AT-24 < SERVICE INFORMATION > A/T CONTROL SYSTEM “1 ” Position 1st Gear • The front brake fastens the front sun gear. • The forward brake and the forward one-way clutch regulate reverse rotati

Page 95 of 3061

INFINITI QX56 2007 Factory Service Manual A/T CONTROL SYSTEM AT-25 < SERVICE INFORMATION > D E F G H I J K L MA B AT N O P “D”, “4”, “3” Positions 2nd Gear • The forward brake and the forward one-way clutch regulate reverse rota

Page 96 of 3061

INFINITI QX56 2007 Factory Service Manual AT-26 < SERVICE INFORMATION > A/T CONTROL SYSTEM “2”, “1” Positions 2nd Gear • The front brake fastens the front sun gear. • The forward brake and the forward one-way clutch regulate rever
