12. Remove the C-rings from the mainshaft using suitable tool.
13. Set the center case on the press stand. Remove the mainshaft
from the center case.
14. Remove the snap ring from the mainshaft using suitable tool.
15. Remove the thrust needle bearing from the press flange.
16. Press the press flange until the snap ring is out of place using
Tools.
SDIA2105E
SDIA2108E
SDIA2110E
SDIA2109E
Tool number A: ST22452000 (J-34335)
B: ST30911000 ( — )
C: KV31103300 ( — )
SDIA2111E
Page 2962 of 3061
TF-140
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
17. Remove the snap ring from the mainshaft using suitable tool.
18. Remove the press flange from the mainshaft.
19. Remove the return spring assembly from the clutch hub.
20. Remove each plate from the clutch drum.
21. Remove the snap ring from the mainshaft.
SDIA2112E
SMT910C
SMT911C
SMT912C
SDIA2113E
Page 2963 of 3061
TRANSFER ASSEMBLY
TF-141
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
22. Remove the mainshaft from the clutch drum and clutch hub
using suitable tool.
23. Remove the needle bearing and spacer from the mainshaft.
24. Remove the snap ring from the clutch hub using suitable tool.
25. Remove the oil pressure check plug from the oil pressure check
port.
26. Apply air gradually from the oil pressure check port, and remove
the clutch piston assembly from the center case.
27. Remove the thrust needle bearing race from the clutch piston by
hooking a edge into 3 notches of the thrust needle bearing race
using suitable tool.
CAUTION:
Do not damage clutch piston or thrust needle bearing race.
SMT914C
WDIA0101E
SDIA3188E
SDIA2116E
SDIA2118E
Page 2964 of 3061
TF-142
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
28. Remove the two D-rings from the clutch piston.
29. Remove the mainshaft rear bearing from the center case using
Tool.
30. Remove the two bolts and oil strainer.
31. Remove the two O-rings from the oil strainer.
32. Remove the snap ring. Then push the connector assembly into
the center case to remove the control valve assembly.
SDIA2781E
Tool number : KV38100300 (J-25523)
SDIA2129E
SDIA2119E
SDIA2782E
SDIA2122E
Page 2965 of 3061

TRANSFER ASSEMBLY
TF-143
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
33. Remove the control valve assembly bolts.
34. Remove the control valve assembly.
CAUTION:
• Do not reuse any part that has been dropped or damaged.
• Make sure valve is assembled in the proper direction.
• Do not use a magnet because residual magnetism stays
during disassembly.
35. Remove the lip seals from the center case.
CAUTION:
There are two kinds of lip seals (lip seal of large inner diam-
eter: 5 pieces, lip seal of small inner diameter: 2 pieces).
Confirm the position before disassembly.
36. Disassemble the control valve assembly with the following procedure.
CAUTION:
• Do not reuse any part that has been dropped or damaged.
• Make sure valve is assembled in the proper direction.
• Do not use a magnet because residual magnetism stays during disassembly.
a. Remove all the bolts except for the two shown.
b. Remove the following from the control valve assembly:
• Clutch pressure solenoid valve
• 2-4WD shift solenoid valve
• Clutch pressure switch
• Line pressure switch
• Transfer fluid temperature sensor
c. Remove the O-rings from each solenoid valve, switch and termi-
nal body.
SDIA2121E
SDIA2123E
WDIA0198E
WDIA0199E
Page 2966 of 3061
TF-144
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
d. Place the control valve with the lower body facing up. Remove
the two bolts, and then remove the lower body and separator
plate from the upper body.
CAUTION:
Do not drop relief balls. Detach lower body carefully.
e. Make sure the reverse balls, relief balls, relief springs, accumu-
lator pistons and valve springs are securely installed as shown,
and remove them.
f. Remove the retainer plates.
g. Remove each control valve, spring and plug.
37. Remove the transfer motor bolts and motor from the center
case. Then remove the O-ring from the transfer motor.
SDIA3187E
SDIA2126E
SDIA2127E
SDIA3317E
SDIA2133E
Page 2967 of 3061
TRANSFER ASSEMBLY
TF-145
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
38. Remove the sub oil pump cover bolts.
39. Thread two bolts (M4 x 0.8) into the holes of sub oil pump cover
as shown, and pull out to remove the sub oil pump assembly.
40. Remove the outer gear and inner gear from the sub oil pump
housing.
41. Remove the oil filter bolts and oil filter.
CAUTION:
• Do not damage center case and oil filter.
• Loosen bolts and detach oil filter evenly.
42. Remove the O-rings (1) from the oil filter (2).
SDIA2134E
SMT934C
SDIA2135E
SDIA2136E
WDIA0285E
Page 2968 of 3061
TF-146
< SERVICE INFORMATION >
TRANSFER ASSEMBLY
43. Remove the oil filter stud from the oil filter.
44. Remove the O-ring from the oil filter stud.
INSPECTION AFTER DISASSEMBLY
Shift Rod Components
• Check the working face of the shift rod and fork for wear, partial
wear, bending and other abnormality. If any is found, replace with a
new one.
• Measure the clearance between the shift fork and sleeve. If it is out
of specification, replace it with a new one.
Planetary Carrier
• Measure the end play of each pinion gear. If it is out of specifica-
tion, replace the planetary carrier assembly with a new one.
• Check the working face of each gear and bearing for damage,
burrs, partial wear, dents and other abnormality. If any is found,
replace the planetary carrier assembly with a new one.
Sun Gear
SDIA3180E
SMT009D
Specification : Less than 0.36 mm (0.0142 in)
SMT010D
Pinion gear end play : 0.1 - 0.7 mm (0.004 - 0.028 in)
