AUTOMATIC DRIVE POSITIONER
SE-41
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
SE
N
O
P
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (rear).
3. Check continuity between driver seat control unit connector P3
terminals 38, 39 and lifting motor (rear) connector P7 terminals
4, 6.
4. Check continuity between driver seat control unit P3 terminals
38, 39 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4.CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect the driver seat control unit and lifting motor (rear).
2. Check voltage between driver seat control unit connector and
ground.
OK or NG
OK >> Replace lifting motor (rear). Refer to SE-83.
NG >> Replace driver seat control unit. Refer to SE-83
.
Pedal Adjusting Motor Circuit InspectionINFOID:0000000003533177
1.CHECK PEDAL ADJUSTING MECHANISM
Check the following.
• Operation malfunction caused by pedal adjusting mechanism deformation or pinched harness or other for-
eign materials
• Operation malfunction and interference with other parts by poor installation
OK or NG
OK >> GO TO 2.
NG >> Repair or replace the malfunctioning part and check again.
2.CHECK FUNCTION
With CONSULT-II38 - 6 : Continuity should exist.
39 - 4 : Continuity should exist.
38 - Ground : Continuity should not exist.
39 - Ground : Continuity should not exist.
LIIA0699E
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
P338
GroundLifting switch (rear) ON
(UP operation)Battery voltage
Other than above 0
39Lifting switch (rear) ON
(DOWN operation)Battery voltage
Other than above 0
PIIA4804E
Page 2714 of 3061

SE-42
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
Check operation with “ADJ PEDAL MOTOR” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Pedal adjusting motor circuit is OK.
NG >> GO TO 3.
3.CHECK PEDAL ADJUSTING MOTOR CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and pedal
adjusting motor.
3. Check continuity between automatic drive positioner control unit
connector M34 terminals 37, 45 and pedal adjusting motor con-
nector E109 terminals 1, 2.
4. Check continuity between automatic drive positioner control unit
connector M34 terminals 37, 45 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4.CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT OUTPUT SIGNAL
1. Connect the automatic drive positioner control unit and pedal
adjusting motor.
2. Check voltage between automatic drive positioner control unit
connector and ground.
OK or NG
OK >> Replace pedal adjusting motor.
NG >> Replace automatic drive positioner control unit.
Mirror Motor LH Circuit InspectionINFOID:0000000003533178
1.CHECK DOOR MIRROR LH MECHANISM
Check the following items.
Test item Description
ADJ PEDAL MOTORThe pedal adjusting motor is activated by receiving the
drive signal.
PIIA4555E
37 - 1 : Continuity should exist.
45 - 2 : Continuity should exist.
37 - Ground : Continuity should not exist.
45 - Ground : Continuity should not exist.
LIIA1755E
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M3437
GroundPedal adjusting switch
ON
(FORWARD operation)Battery voltage
Other than above 0
45Pedal adjusting switch
ON
(BACKWARD opera-
tion)Battery voltage
Other than above 0
PIIA4806E
Page 2715 of 3061

AUTOMATIC DRIVE POSITIONER
SE-43
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
SE
N
O
P
Operation malfunction caused by a foreign object caught in door mirror face edge.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace the malfunctioning parts, and check the symptom again.
2.CHECK FUNCTION
With CONSULT-II
Check the operation with “MIRROR MOTOR LH” in the ACTIVE
TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Mirror motor LH circuit is OK.
NG >> GO TO 3.
3.CHECK DOOR MIRROR MOTOR LH CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and door mir-
ror LH.
3. Check continuity between automatic drive positioner control unit
connector M33 terminals 16, 31, 32 and door mirror LH connec-
tor D4 terminals 1, 2, 3.
4. Check continuity between automatic drive positioner control unit
connector M41 terminal 16, 31, 32 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4.CHECK MIRROR MOTOR SIGNAL
1. Connect automatic drive positioner control unit and door mirror
LH.
2. Turn ignition switch to ACC.
3. Check voltage between door mirror LH connector and ground.
Test item Description
MIRROR MOTOR LHThe mirror motor LH moves the mirror UP/DOWN and
LEFT/RIGHT by receiving the drive signal.
PIIA4784E
16 - 3 : Continuity should exist.
31 - 1 : Continuity should exist.
32 - 2 : Continuity should exist.
16 - Ground : Continuity should not exist.
31 - Ground : Continuity should not exist.
32 - Ground : Continuity should not exist.
LIIA0999E
LIIA1000E
Page 2716 of 3061

SE-44
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
OK or NG
OK >> Replace door mirror LH. Refer to GW-84, "Door Mirror Assembly".
NG >> Repair or replace harness.
Mirror Motor RH Circuit InspectionINFOID:0000000003533179
1.CHECK DOOR MIRROR RH MECHANISM
Check the following items.
Operation malfunction caused by a foreign object caught in door mirror face edge.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace the malfunctioning parts, and check the symptom again.
2.CHECK FUNCTION
With CONSULT-II
Check the operation with “MIRROR MOTOR RH” in the ACTIVE
TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Mirror motor RH circuit is OK.
NG >> GO TO 3.
3.CHECK DOOR MIRROR RH CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and door mir-
ror RH.
3. Check continuity between automatic drive positioner control unit
connector M33 terminals 14, 15, 30 and door mirror RH connec-
tor D107 terminals 1, 2, 3.
4. Check continuity between automatic drive positioner control unit
connector M33 terminal 14, 15, 30 and ground.
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
D41
GroundWhen motor is
operated UP1.5 - Battery voltage
Other than above 0
2When motor is
operated LEFT1.5 - Battery voltage
Other than above 0
3 When motor is
operated DOWN or RIGHT1.5 - Battery voltage
Other than above 0
Test item Description
MIRROR MOTOR RHThe mirror motor RH moves the mirror UP/DOWN and
LEFT/RIGHT by receiving the drive signal.
PIIA0202E
14 - 1 : Continuity should exist.
15 - 2 : Continuity should exist.
30 - 3 : Continuity should exist.
LIIA1001E
Page 2717 of 3061

AUTOMATIC DRIVE POSITIONER
SE-45
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
SE
N
O
P
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4.CHECK MIRROR MOTOR SIGNAL
1. Connect automatic drive positioner control unit and door mirror
RH.
2. Turn ignition switch to ACC.
3. Check voltage between door mirror RH connector and ground.
OK or NG
OK >> Replace door mirror motor RH. Refer to GW-84, "Door Mirror Assembly".
NG >> Repair or replace harness.
Steering Wheel Tilt Circuit InspectionINFOID:0000000003533180
1.CHECK STEERING WHEEL TILT MECHANISM
Check the following.
• Operation malfunction caused by pedal adjusting mechanism deformation or pinched harness or other for-
eign materials
• Operation malfunction and interference with other parts by poor installation
OK or NG
OK >> GO TO 2.
NG >> Repair or replace the malfunctioning part and check again.
2.CHECK FUNCTION
With CONSULT-II
Check operation with “TILT MOTOR” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Steering wheel tilt motor circuit is OK.
NG >> GO TO 3.
3.CHECK STEERING WHEEL TILT MOTOR HARNESS CONTINUITY 14 - Ground : Continuity should not exist.
15 - Ground : Continuity should not exist.
30 - Ground : Continuity should not exist.
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
D1071
GroundMirror motor is operated
UP1.5 - Battery
voltage
Other than above 0
2Mirror motor is operated
LEFT1.5 - Battery
voltage
Other than above 0
3Mirror motor is operated
DOWN or RIGHT1.5 - Battery
voltage
Other than above 0
LIIA1002E
Test item Description
TILT MOTOR The pedal adjust motor is activated by receiving the drive signal.
PIIA0280E
Page 2718 of 3061

SE-46
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and steering
wheel tilt motor.
3. Check continuity between automatic drive positioner control unit
connector M34 terminals 35, 42 and steering wheel tilt motor
connector M68 terminals 1, 5.
4. Check continuity between automatic drive positioner control unit
connector M34 terminals 35, 42 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4.CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT OUTPUT SIGNAL
1. Connect the automatic drive positioner control unit connector
and steering wheel tilt motor.
2. Check voltage between automatic drive positioner control unit
connector and ground.
OK or NG
OK >> Replace steering wheel tilt motor. Refer to PS-9, "Removal and Installation".
NG >> Replace automatic drive positioner control unit.
Sliding Sensor Circuit InspectionINFOID:0000000003533181
1.CHECK FUNCTION
With CONSULT-II
Check operation with “SLIDE PULSE” on the DATA MONITOR to
make sure the pulse changes.
Without CONSULT-II35 - 1 : Continuity should exist.
42 - 5 : Continuity should exist.
35 - Ground : Continuity should not exist.
42 - Ground : Continuity should not exist.
LIIA1431E
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M3435
GroundTilt switch ON
(UP operation)Battery voltage
Other than above 0
42Tilt switch ON
(DOWN operation)Battery voltage
Other than above 0
LIIA0482E
Monitor item [OPERATION or UNIT] Contents
SLIDE PULSE —The seat sliding position (pulse) judged from
the sliding sensor signal is displayed
PIIA4558E
Page 2719 of 3061

AUTOMATIC DRIVE POSITIONER
SE-47
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
SE
N
O
P
1. Turn ignition switch OFF.
2. Check signal between driver seat control unit connector and
ground, with oscilloscope.
OK or NG
OK >> Sliding sensor circuit is OK.
NG >> GO TO 2.
2.CHECK SLIDING MOTOR SENSOR CIRCUIT HARNESS CONTINUITY
1. Disconnect driver seat control unit connector and sliding motor
LH.
2. Check continuity between driver seat control unit connector P2
terminals 16, 24, 31 and sliding motor P4 terminals 1, 2, 3.
3. Check continuity between driver seat control unit P2 terminals
16, 24, 31 and ground.
OK or NG
OK >> Replace sliding motor. Refer to SE-83.
NG >> Repair or replace harness.
Reclining Sensor Circuit InspectionINFOID:0000000003533182
1.CHECK FUNCTION
With CONSULT-II
Check operation with “RECLN PULSE” on the DATA MONITOR to
make sure the pulse changes.
Without CONSULT-II
ConnectorTe r m i n a l s
Condition Signal
(+) (-)
P2 24 GroundSliding
motor op-
eration
PIIA4556E
PIIA3277E
16 - 3 : Continuity should exist.
24 - 2 : Continuity should exist.
31 - 1 : Continuity should exist.
16 - Ground : Continuity should not exist.
24 - Ground : Continuity should not exist.
31 - Ground : Continuity should not exist.
LIIA0706E
Monitor item [OPERATION or UNIT] Contents
RECLN PULSE —The seat reclining position (pulse) judged
from the reclining sensor is displayed
PIIA4558E
Page 2720 of 3061

SE-48
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
1. Turn ignition switch OFF.
2. Check signal between driver seat control unit connector and
ground, with oscilloscope.
OK or NG
OK >> Reclining sensor circuit is OK.
NG >> GO TO 2.
2.CHECK RECLINING MOTOR SENSOR CIRCUIT HARNESS CONTINUITY
1. Disconnect driver seat control unit and reclining motor LH.
2. Check continuity between driver seat control unit connector P2
terminals 9, 31 and reclining motor LH connector P5 terminals 1,
2.
3. Check continuity between driver seat control unit connector P2
terminals 9, 31 and ground.
OK or NG
OK >> Replace reclining motor. Refer to SE-83.
NG >> Repair or replace harness.
Lifting Sensor (Front) Circuit InspectionINFOID:0000000003533183
1.CHECK FUNCTION
With CONSULT-II
Check operation with “LIFT FR PULSE” on the DATA MONITOR to
make sure the pulse changes.
Without CONSULT-II
ConnectorTe r m i n a l s
Condition Signal
(+) (-)
P2 9 GroundReclining
motor op-
eration
PIIA4559E
PIIA3278E
9 - 1 : Continuity should exist.
31 - 2 : Continuity should exist.
9 - Ground : Continuity should not exist.
31 - Ground : Continuity should not exist.
LIIA0707E
Monitor item [OPERATION or UNIT] Contents
LIFT FR PULSE —The front lifting position (pulse) judged from
the lifting sensor (front) is displayed
PIIA4558E
