INFINITI QX56 2007 Factory Service Manual TROUBLE DIAGNOSIS
TF-35
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
• Heavy tight-corner braking symptom occurs when vehicle is driven in the following conditions: 4WD shift
switch is "4

TROUBLE DIAGNOSIS
TF-35
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
• Heavy tight-corner braking symptom occurs when vehicle is driven in the following conditions: 4WD shift
switch is "4H" or "4LO", steering wheel is turned fully to either side.
Transfer Control Unit Input/Output Signal Reference ValueINFOID:0000000003532526
TRANSFER CONTROL UNIT INSPECTION TABLE
Specifications with CONSULT-II
Monitored item [Unit] Content Condition Display value
VHCL/S SEN·FR [km/h]
or [mph]Front wheel speedVehicle stopped 0 km/h (0 MPH)
Vehicle running
CAUTION:
Check air pressure of tire under standard condition.Approximately
equal to the indica-
tion on speedome-
ter (Inside of
±10%)
VHCL/S SEN·RR [km/h]
or [mph]Rear wheel speedVehicle stopped 0 km/h (0 MPH)
Vehicle running
CAUTION:
Check air pressure of tire under standard condition.Approximately
equal to the indica-
tion on speedome-
ter (Inside of
±10%)
ENGINE SPEED [rpm] Engine speedEngine stopped
(Engine speed: Less than 400 rpm)0 rpm
Engine running
(Engine speed: 400 rpm or more)Approximately
equal to the indica-
tion on tachometer
THRTL POS SEN [V]Accelerator pedal posi-
tion (APP) sensor signal
voltageAccelerator pedal: Release Approx. 0.5V
Accelerator pedal: Fully depressed Approx. 4.0V
FLUID TEMP SE [V]Transfer fluid tempera-
ture signal voltageTransfer fluid temperature approx. 20 - 80°C (68 - 176°F) Approx. 1.1 - 0.3V
BATTERY VOLT [V]Power supply voltage for
transfer control unitIgnition switch: ON Battery voltage
2WD SWITCH [ON/OFF]Input condition from 4WD
shift switch4WD shift switch: 2WD ON
4WD shift switch: AUTO, 4H or 4LO OFF
AUTO SWITCH [ON/
OFF]Input condition from 4WD
shift switch4WD shift switch: AUTO ON
4WD shift switch: 2WD, 4H or 4LO OFF
LOCK SWITCH [ON/
OFF]Input condition from 4WD
shift switch4WD shift switch: 4H ON
4WD shift switch: 2WD, AUTO or 4LO OFF
4L SWITCH [ON/OFF]Input condition from 4WD
shift switch4WD shift switch: 4LO ON
4WD shift switch: 2WD, AUTO or 4H OFF
N POSI SW TF [ON/
OFF]Condition of neutral-4LO
switch• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD,
AUTO or 4HOFF
4WD shift switch: 4H to
4LO (While actuator mo-
tor is operating.)OFF → ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.)ON → OFF
4WD shift switch: 4LO ON

Page 2858 of 3061

INFINITI QX56 2007 Factory Service Manual TF-36
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
ATP SWITCH [ON/OFF] Condition of ATP switch• Vehicle stopped
• Engine running
• A/T selector lever “N”
• Brake pedal depressed4WD shift swit

TF-36
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
ATP SWITCH [ON/OFF] Condition of ATP switch• Vehicle stopped
• Engine running
• A/T selector lever “N”
• Brake pedal depressed4WD shift switch
: 4H to 4LO or 4LO to 4H
(While actuator motor is
operating.) ON
Except the above OFF
WAIT DETCT SW [ON/
OFF]Condition of wait detec-
tion switch• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD,
AUTO or 4HOFF
4WD shift switch: 4H to
4LO (While actuator mo-
tor is operating.)OFF → ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.)ON → OFF
4WD shift switch: 4LO ON
LINE PRES SW [ON/
OFF]Condition of line pres-
sure switch• A/T selector lever “D” position
• 4WD shift switch: 2WD, AUTO or 4HON
• Except the above
• The vehicle has been left at
room temperature for 5
minutes and more with ig-
nition switch in “OFF” posi-
tion.• Ignition switch: ON
• A/T selector lever: “P”
or "N" position
• 4WD shift switch: other
than AUTOOFF
CL PRES SW [ON / OFF]Condition of clutch pres-
sure switch• Vehicle stopped
• Engine running
• A/T selector lever “D” position
• 4WD shift switch: AUTO or 4H (“Wait” function is not op-
erating.)ON
• Vehicle stopped
• Engine running
• 4WD shift switch: 2WD (“Wait” function is not operat-
ing.)OFF
N POSI SW AT [ON/
OFF]Input condition from A/T
PNP switch• Vehicle stopped
• Engine running
• Brake pedal depressedA/T selector lever posi-
tion: NON
Except the above OFF
R POSI SW AT [ON/
OFF]Input condition from A/T
PNP switch• Vehicle stopped
• Engine running
• Brake pedal depressedA/T selector lever posi-
tion: RON
Except the above OFF
P POSI SW AT [ON/OFF]Input condition from A/T
PNP switch• Vehicle stopped
• Engine running
• Brake pedal depressedA/T selector lever posi-
tion: PON
Except the above OFF
ABS OPER SW [ON/
OFF]Condition of ABS operat-
ingABS is operating. ON
ABS is not operating. OFF
VDC OPER SW [ON/
OFF]Condition of VDC operat-
ingVDC is operating. ON
VDC is not operating. OFF
TCS OPER SW [ON/
OFF]Condition of TCS operat-
ingTCS is operating. ON
TCS is not operating. OFF
THROTTLE POSI [0.0/8]Condition of throttle
openingWhen depressing accelerator pedal
(Value rises gradually in response to throttle position.)0.0/8 - 8.0/8
4WD MODE [AUTO/
LOCK/2WD/4L]Control status of 4WD
(Output condition of 4WD
shift indicator lamp and
4LO indicator lamp)• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD 2WD
4WD shift switch: AUTO AUTO
4WD shift switch: 4H LOCK
4WD shift switch: 4LO 4L Monitored item [Unit] Content Condition Display value

Page 2859 of 3061

INFINITI QX56 2007 Factory Service Manual TROUBLE DIAGNOSIS
TF-37
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
VHCL/S COMP [km/h] or
[mph]Vehicle speedVehicle stopped 0 km/h (0 MPH)
Vehicle running
CAUTION:
Check air pressure of t

TROUBLE DIAGNOSIS
TF-37
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
VHCL/S COMP [km/h] or
[mph]Vehicle speedVehicle stopped 0 km/h (0 MPH)
Vehicle running
CAUTION:
Check air pressure of tire under standard condition.Approximately
equal to the indica-
tion on speedome-
ter (Inside of
±10%)
COMP CL TORQ [kgm]Condition of control
torque• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD 0 kg-m
4WD shift switch: AUTO39 - 1,353 N·m
(4 - 138 kg-m, 29 -
998 ft-lb)
4WD shift switch: 4H or
4LO1,353 N·m
(138 kg-m, 998 ft-
lb)
DUTY SOLENOID [%]Condition of clutch pres-
sure solenoid• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD 4%
4WD shift switch: AUTO 96 - 4%
4WD shift switch: 4H or
4LO4%
2-4WD SOL [ON/OFF]Condition of 2-4WD shift
solenoid valve• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H
(“Wait” function is operat-
ing.)OFF
2-4WD SOL MON [ON/
OFF]Check signal for transfer
control unit signal output• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H
(“Wait” function is operat-
ing.)OFF
MOTOR RELAY [ON/
OFF]Condition of transfer mo-
tor relay• Accelerator pedal de-
pressed
• Vehicle stopped
• Engine running
• Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
or 4LO (A/T selector lever
“P” or “N” position)OFF
("ON" for approx. 2
sec. after shifting
to “P” and “N”.)
4WD shift switch: AUTO
or 4LO (Except for A/T se-
lector lever “P” or “N” po-
sition)ON
4WD shift switch: 4H (A/T
selector lever “P” posi-
tion)OFF
("ON" for approx. 2
sec. after shifting
to “P”.)
4WD shift switch: 4H (Ex-
cept for A/T selector lever
“P” position)ON Monitored item [Unit] Content Condition Display value

Page 2860 of 3061

INFINITI QX56 2007 Factory Service Manual TF-38
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
MOTOR RELAY MON
[ON/OFF]Check signal for transfer
control unit signal output• Accelerator pedal de-
pressed
• Vehicle stopped
• Engine running
�

TF-38
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
MOTOR RELAY MON
[ON/OFF]Check signal for transfer
control unit signal output• Accelerator pedal de-
pressed
• Vehicle stopped
• Engine running
• Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
or 4LO (A/T selector lever
“P” or “N” position)OFF
("ON" for approx. 2
sec. after shifting
to “P” and “N”.)
4WD shift switch: AUTO
or 4LO (Except for A/T se-
lector lever “P” or “N” po-
sition)ON
4WD shift switch: 4H (A/T
selector lever “P” posi-
tion)OFF
("ON" for approx. 2
sec. after shifting
to “P”.)
4WD shift switch: 4H (Ex-
cept for A/T selector lever
“P” position)ON
4WD FAIL LAMP [ON/
OFF]Condition of 4WD warn-
ing lamp4WD warning lamp: ON ON
4WD warning lamp: OFF OFF
2WD IND [ON/OFF]Condition of 4WD shift in-
dicator lamp (2WD indi-
cator lamp)2WD indicator lamp of 4WD shift indicator lamp: OFF OFF
2WD indicator lamp of 4WD shift indicator lamp: ON ON
AUTO IND [ON/OFF]Condition of 4WD shift in-
dicator lamp (AUTO indi-
cator lamp)AUTO indicator lamp of 4WD shift indicator lamp: OFF OFF
AUTO indicator lamp of 4WD shift indicator lamp: ON ON
LOCK IND [ON/OFF]Condition of 4WD shift in-
dicator lamp (Lock indi-
cator lamp)Lock indicator lamp of 4WD shift indicator lamp: OFF OFF
Lock indicator lamp of 4WD shift indicator lamp: ON ON
4L IND [ON/OFF]Condition of 4LO indica-
tor lamp condition4LO indicator lamp: OFF OFF
4LO indicator lamp: ON ON
ATP IND [ON/OFF]Condition of ATP indica-
tor lamp ATP indicator lamp: ON ON
AT P i n d i c a t o r l a m p : O F F O F F
SHIFT POS SW1 [ON/
OFF]Condition of actuator po-
sition switch 1
(Low)• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 4LO ON
4WD shift switch: 2WD,
AUTO or 4HOFF
SHIFT POS SW2 [ON/
OFF]Condition of actuator po-
sition switch 2
(High)• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 4H,
AUTO or 2WDON
4WD shift switch: 4LO OFF
SHIFT ACT1 [ON/OFF]Output condition to actu-
ator motor (High)• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 4H to
4LO (“Wait” function is
operating.)ON
Except the above OFF
SHIFT AC MON1 [ON/
OFF]Check signal for transfer
control unit signal output• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 4H to
4LO (“Wait” function is
operating.)ON
Except the above OFF
SHIFT ACT2 [ON/OFF]Output condition to actu-
ator motor (Low)• Vehicle stopped
• Engine running
• A/T selector lever “N” posi-
tion
• Brake pedal depressed4WD shift switch: 4LO to
4H (“Wait” function is op-
erating.)ON
Except the above OFF Monitored item [Unit] Content Condition Display value

Page 2861 of 3061

INFINITI QX56 2007 Factory Service Manual TROUBLE DIAGNOSIS
TF-39
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P Specifications Between Transfer Control Unit Terminals
TRANSFER CONTROL UNIT TERMINAL CONNECTOR LAYOUT
NOTE:
Data are re

Page 2862 of 3061

INFINITI QX56 2007 Factory Service Manual TF-40
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
10 L/W Transfer dropping resistor• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift sw

TF-40
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
10 L/W Transfer dropping resistor• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: AUTO 4 - 14V
4WD shift switch: 2WD, 4H or 4LO Less than 1V
11 L4WD shift indicator lamp
(Lock indicator lamp)Lock indicator lamp of 4WD shift indicator lamp: OFF Battery voltage
Lock indicator lamp of 4WD shift indicator lamp: ON 0V
12 W/G 4LO indicator lamp4LO indicator lamp: OFF Battery voltage
4LO indicator lamp: ON 0V
13 G/B Transfer shift low relay• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 4LO to 4H (“Wait” func-
tion is operating.)Battery voltage
Except the above 0V
14 LG Transfer motor relay• Accelerator pedal
depressed
• Vehicle stopped
• Engine running
• Brake pedal de-
pressed4WD shift switch: 2WD Battery voltage
4WD shift switch: AUTO or 4LO (A/T selec-
tor lever “P” or “N” position)Battery voltage
(0V for approx.
2 sec. after
shifting to “P”
and “N”.)
4WD shift switch: AUTO or 4LO (Except for
A/T selector lever “P” or “N” position)0V
4WD shift switch: 4H (A/T selector lever
“P” position)Battery voltage
(0V for approx.
2 sec. after
shifting to “P”.)
4WD shift switch: 4H (Except for A/T selec-
tor lever “P” position)0V
15 L/B ATP warning lampATP indicator lamp: ON 0V
ATP indicatorlamp: OFF Battery voltage
16 Y/R Power supplyIgnition switch: ON Battery voltage
Ignition switch: OFF 0V
18 O4WD shift switch
(4H)Ignition switch: ON4WD shift switch: 4H Battery voltage
4WD shift switch: 2WD, AUTO or 4LO 0V
19 LClutch pressure solenoid
valve• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: AUTO 1.5 - 3V
4WD shift switch: 2WD, 4H or 4LO Less than 1V
21 BR4WD shift indicator lamp
(AUTO indicator lamp)• AUTO indicator lamp of 4WD shift indicator lamp: OFF Battery voltage
AUTO indicator lamp of 4WD shift indicator lamp: ON 0V
22 Y/R Power supplyIgnition switch: ON Battery voltage
Ignition switch: OFF 0V
23 R4WD shift switch
(4LO)Ignition switch: ON4WD shift switch: 4LO Battery voltage
4WD shift switch: 2WD, AUTO or 4H 0V
24 LG/R4WD shift switch
(AUTO)Ignition switch: ON4WD shift switch: AUTO Battery voltage
4WD shift switch: 2WD, 4H or 4LO 0V Te r m i n a lWire
colorItem Condition Data (Approx.)

Page 2863 of 3061

INFINITI QX56 2007 Factory Service Manual TROUBLE DIAGNOSIS
TF-41
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
25 V Neutral-4LO switch• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal d

TROUBLE DIAGNOSIS
TF-41
< SERVICE INFORMATION >
C
E
F
G
H
I
J
K
L
MA
B
TF
N
O
P
25 V Neutral-4LO switch• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 2WD, AUTO or 4H Battery voltage
4WD shift switch: 4H to 4LO (While actua-
tor motor is operating.)Battery voltage
→ 0V
4WD shift switch: 4LO to 4H (While actua-
tor motor is operating.)0V → Battery
voltage
4WD shift switch: 4LO 0V
27 W/LActuator position switch 2
(High)• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 4H, AUTO or 2WD 0V
4WD shift switch: 4LO Battery voltage
28 B/G Sensor ground Always 0V
29 L/W Ignition switch monitorIgnition switch: ON Battery voltage
Ignition switch: OFF 0V
30 SB Shut off relayIgnition switch: ON 0V
Ignition switch: OFF Battery voltage
31 GTransfer fluid temperature
sensorIgnition switch: ONTransfer fluid temperature approx. 20°C
(68°F)1.1V
Transfer fluid temperature approx. 80°C
(176°F)0.3V
33 R/LTransfer shift high relay
monitor• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 4H to 4LO (“Wait” func-
tion is operating.)Battery voltage
Except the above 0V
34 BR Clutch pressure switch• Vehicle stopped
• Engine running
• A/T selector lever
“D” position4WD shift switch: AUTO or 4H (“Wait” func-
tion is not operating.)0V
• Vehicle stopped
• Engine running4WD shift switch: 2WD (“Wait” function is
not operating.)Battery voltage
35BR/
WLine pressure switch• Ignition switch: ON
• A/T selector lever “D” position
• 4WD shift switch: AUTO0V
• After the vehicle
has been left at
room temperature
for 5 minutes and
more with ignition
switch in “OFF” po-
sition.• Ignition switch: ON
• A/T selector lever: “P” or "N" position
• 4WD shift switch: other than AUTOBattery voltage
40 L ATP switch• Vehicle stopped
• Engine running
• A/T selector lever
“N”
• Brake pedal de-
pressed4WD shift switch: 4H to 4LO or 4LO to 4H
(While actuator motor is operating.)0V
Except the above Battery voltage Te r m i n a lWire
colorItem Condition Data (Approx.)

Page 2864 of 3061

INFINITI QX56 2007 Factory Service Manual TF-42
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
CONSULT-II Function (ALL

TF-42
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
CONSULT-II Function (ALL MODE AWD/4WD)INFOID:0000000003532527
FUNCTION
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
41 RTransfer motor relay moni-
tor• Accelerator pedal
depressed
• Vehicle stopped
• Engine running
• Brake pedal de-
pressed4WD shift switch: 2WD 0V
4WD shift switch: AUTO or 4LO (A/T selec-
tor lever “P” or “N” position)0V
(Battery volt-
age for approx.
2 sec. after
shifting to “P”
and “N”.)
4WD shift switch: AUTO or 4LO (Except for
A/T selector lever “P” or “N” position)Battery voltage
4WD shift switch: 4H (A/T selector lever
“P” position)0V
(Battery volt-
age for approx.
2 sec. after
shifting to “P”.)
4WD shift switch: 4H (Except for A/T selec-
tor lever “P” position)Battery voltage
42 P/GTransfer shift low relay
monitor• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 4LO to 4H (“Wait” func-
tion is operating.)Battery voltage
Except the above 0V
43 G/Y Wait detection switch• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 2WD, AUTO or 4H Battery voltage
4WD shift switch: 4H to 4LO (While actua-
tor motor is operating.)Battery voltage
→ 0V
4WD shift switch: 4LO to 4H (While actua-
tor motor is operating.)0V → Battery
voltage
4WD shift switch: 4LO 0V
44 LG/BActuator position switch 1
(Low)• Vehicle stopped
• Engine running
• A/T selector lever
“N” position
• Brake pedal de-
pressed4WD shift switch: 4LO 0V
4WD shift switch: 2WD, AUTO or 4H Battery voltage
45 B Ground Always 0V
47 WPower supply
(Memory back-up)Ignition switch: ON Battery voltage
Ignition switch: OFF Battery voltage Te r m i n a lWire
colorItem Condition Data (Approx.)
ALL MODE AWD/4WD diag-
nostic modeDescription
SELF-DIAG RESULTS Displays transfer control unit self-diagnosis results.
DATA MONITOR Displays transfer control unit input/output data in real time.
WORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the transfer control unit for set-
ting the status suitable for required operation, input/output signals are received from the transfer control
unit and received data is displayed.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER Transfer control unit part number can be read.

Load next 8 pages

Page: < prev 1-10 ... 2825-2832 2833-2840 2841-2848 2849-2856 2857-2864 2865-2872 2873-2880 2881-2888 2889-2896 ... 3064 next >

lock keyless entry length mirror controls fuel tank capacity jacking
