Page 1 of 3061

INFINITI QX56 2007 Factory Service Manual -1 QUICK REFERENCE INDEX AGENERAL INFORMATIONGIGeneral Information BENGINEEMEngine Mechanical LUEngine Lubrication System COEngine Cooling System ECEngine Control System FLFuel System EXExhaust Syste

Page 2 of 3061

INFINITI QX56 2007 Factory Service Manual -2 This manual contains maintenance and repair procedures for the 2007 INFINITI QX56. In order to assure your safety and the efficient functioning of the vehicle, this manual should be read thorough

Page 3 of 3061

INFINITI QX56 2007 Factory Service Manual PLEASEHELPMAKETHISSERVICEMANUALBETTER! YourcommentsareimportanttoINFINITIandwillhelpustoimproveourServiceManuals. UsethisformtoreportanyissuesorcommentsyoumayhaveregardingourServiceManuals. Pleasepri

Page 4 of 3061

INFINITI QX56 2007 Factory Service Manual QUICK REFERENCE CHART: QX562007 QUICK REFERENCE CHART: QX56PFP:00000 Engine Tune-Up DataELS0028Z Cylinder arrangementV-8 Displacement cm 3 (cu in) 5,552 (338.80) Bore and stroke mm (in) 98 x 92

Page 5 of 3061

INFINITI QX56 2007 Factory Service Manual 2007 QUICK REFERENCE CHART: QX56 Drive Belt Deflection and Tension Spark Plug (Platinum Tipped) Front Wheel Alignment (Unladen*1 )ELS00290 *1: Fuel, radiator coolant and engine oil full. Spare tire

Page 6 of 3061

INFINITI QX56 2007 Factory Service Manual QUICK REFERENCE CHART: QX56 2007 Rear Wheel AlignmentELS00291 BrakeELS00292 Unit: mm (in) Camber Degree minute (decimal degree) Minimum 0 ° 0 ′ (0 °) Nominal - 0 ° 30 ′ (-0.5 °) Maximum - 1

Page 7 of 3061

INFINITI QX56 2007 Factory Service Manual 2007 QUICK REFERENCE CHART: QX56 Disc Brake - Repair LimitsELS00293 Unit: mm (in) Brake PedalELS00294 Unit: mm (in) Front brake model AD41VA Brake pad Standard thickness (new) 12.0 (0.476) Repair l

Page 8 of 3061

INFINITI QX56 2007 Factory Service Manual QUICK REFERENCE CHART: QX56 2007 Refill CapacitiesELS00295 DescriptionCapacity (Approximate) Metric US measure Imp measure Fuel 105.8 28 gal 23 1/4 gal Engine oil (drain and refill) With oil filter
