SENSOR ROTOR
Removal and InstallationINFOID:0000000003532812
NOTE:
The wheel sensor rotors are built into the wheel hubs and are not removable. If damaged, replace wheel hub
and bearing assembly. Refer to FAX-5, "
Removal and Installation" (front), RAX-5, "Removal and Installation"
(rear).
Page 986 of 3061
![INFINITI QX56 2007 Factory Service Manual BRC-58
< SERVICE INFORMATION >[VDC/TCS/ABS]
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
Removal and InstallationINFOID:0000000003532813
REMOVAL
1. Disconnect the negati INFINITI QX56 2007 Factory Service Manual BRC-58
< SERVICE INFORMATION >[VDC/TCS/ABS]
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
Removal and InstallationINFOID:0000000003532813
REMOVAL
1. Disconnect the negati](/manual-img/42/57029/w960_57029-985.png)
BRC-58
< SERVICE INFORMATION >[VDC/TCS/ABS]
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
Removal and InstallationINFOID:0000000003532813
REMOVAL
1. Disconnect the negative battery terminal.
2. Remove the cowl top extension. Refer to EI-17, "
Removal and Installation" .
3. Drain the brake fluid. Refer to BR-8, "
Drain and Refill".
4. Disconnect the actuator harness from the ABS actuator and electric unit (control unit).
CAUTION:
• To remove the brake tubes, use a flare nut wrench to prevent the flare nuts and brake tubes from
being damaged.
• Be careful not to splash brake fluid on painted areas; it may cause paint damage. If brake fluid is
splashed on painted areas, wash it away with water immediately.
5. Disconnect the brake tubes.
6. Remove the three bolts and remove the ABS actuator and electric unit (control unit).
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
To install, use a flare nut wrench (commercial service tool). Tighten brake tubes to specification when install-
ing. Refer to BR-10, "
Hydraulic Circuit" .
1. To left front 2. To rear right 3. To rear left
4. To front right 5. From the master cylinder secondary
side6. From the master cylinder primary
side
7. ABS actuator and electric unit (con-
trol unit)8. Harness connector
WFIA0375E
Page 987 of 3061
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
BRC-59
< SERVICE INFORMATION >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
• After installation of the ABS actuator and electric unit (control unit), refill the brake system with new brake
fluid. Refer to MA-10
. Then bleed the air from the system. Refer to BR-8, "Bleeding Brake System" .
CAUTION:
• Never reuse drained brake fluid.
• Adjust the steering angle sensor. Refer to BRC-54, "
Adjustment of Steering Angle Sensor Neutral
Position" .
• Calibrate the yaw rate/side/decel G sensor. Refer to BRC-54, "
Calibration of Decel G Sensor" .
Page 988 of 3061
BRC-60
< SERVICE INFORMATION >[VDC/TCS/ABS]
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR
Removal and InstallationINFOID:0000000003532814
REMOVAL
1. Remove the spiral cable. Refer to SRS-37, "Removal and Installation".
2. Remove the screws and remove the steering angle sensor.
CAUTION:
In the case that the ABS actuator and electronic unit (control unit) is replaced, make sure to adjust
position of steering angle sensor. Refer to BRC-54, "
Adjustment of Steering Angle Sensor Neutral
Position".
INSTALLATION
1. Installation is in the reverse order of removal.
Page 989 of 3061
G SENSOR
BRC-61
< SERVICE INFORMATION >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
G SENSOR
Removal and InstallationINFOID:0000000003532815
REMOVAL
1. Remove center console. Refer to IP-10, "Removal and Installa-
tion" .
2. Remove yaw rate/side/decel G sensor attaching nuts.
CAUTION:
• Do not use power tools to remove or install yaw rate/side/
decel G sensor.
• Do not drop or strike the yaw rate/side/decel G sensor.
3. Disconnect harness connector and remove the yaw rate/side/
decel G sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, calibrate the yaw rate/side/decel G sensor. Refer to BRC-54, "
Calibration of Decel G
Sensor" .
WFIA0202E
Page 990 of 3061

CO-1
ENGINE
C
D
E
