Perform diagnostic procedure for the mode door moto r. Refer to "DIAGNOSTIC PROCEDURE FOR MODE
DOOR MOTOR".
OK or NG
OK >> GO TO 7.
NG >> Repair PBR circuit or replace motor.
7.RECHECK FOR CODES
Perform self-diagnosis. Refer to ATC-48, "
A/C System Self-Diagnosis Function" .
Are any self-diagnostic codes present?
YES >> Refer to ATC-48, "A/C System Self-Diagnosis Function" .
NO >> GO TO 8.
8.RECHECK FOR SYMPTOMS
Perform a complete operational check and check for any symptoms. Refer to ATC-50, "
Operational Check
(Front)" .
Does another symptom exist?
YES >> Repair as necessary.
NO >> Replace front air control. Refer to ATC-123, "
Removal and Installation" .
SYSTEM DESCRIPTION
Component Parts
Mode door control system components are:• Front air control
• Mode door motor
• PBR (built into mode door motor)
• In-vehicle sensor
• Ambient sensor
• Optical sensor
• Intake sensor
System Operation
The mode door position (vent, B/L, foot, and defrost) is se t by the front air control by means of the mode door
motor. When a mode door position is selected on the front air control, voltage is applied to one circuit of the
mode door motor while ground is applied to the other circui t, causing the mode door motor to rotate. The direc-
tion of rotation is determined by which circuit has voltage applied to it, and which one has ground applied to it.
The front air control monitors the mode door positi on by measuring the voltage signal on the PBR circuit.
In AUTO mode the mode door position is set by the fr ont air control which determines the proper position
based on inputs from the in-vehicle sens or, ambient sensor, optical sensor, intake sensor, and the temperature
selected by the driver or passenger.
WJIA1240E
Page 426 of 3061

ATC-56
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Mode Door Control Specification
COMPONENT DESCRIPTION
Mode Door Motor
The mode door motor is attached to the heater & cooling unit. It
rotates so that air is discharged from the outlet as indicated by the
front air control. Motor rotation is conveyed to a link which activates
the mode door.
DIAGNOSTIC PROCEDURE FOR MODE DOOR MOTOR
1.CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Press the mode switch to the B/L ( ) mode.
3. Check voltage between front air control harness connector M49 terminal 5 and terminal 6 while pressing the mode switch to the
floor ( ) mode.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2.CHECK MODE DOOR MOTOR CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 5, 6 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-123, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
3.CHECK FRONT AIR CONTROL FOR GROUND AND POWER
WJIA0434E
WJIA0587E
Connector Te r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 6 5 Press
mode
switch Battery
voltage
WJIA1727E
5 - Ground : Continuity should not exist.
6 - Ground : Continuity should not exist.
WJIA1734E
Page 427 of 3061

TROUBLE DIAGNOSISATC-57
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
1. Press the mode switch to the D/F ( ) mode.
2. Check voltage between front air control harness connector M49 terminal 5 and terminal 6 while pressing the mode switch to the
vent ( ) mode.
OK or NG
OK >> GO TO 4.
NG >> Replace front air control. Refer to ATC-123, "
Removal and Installation" .
4.CHECK MODE DOOR MOTOR AND CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector
M49 terminal 5 and terminal 6.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.CHECK MODE DOOR MOTOR CIRCUITS FOR OPEN
1. Disconnect the mode door motor harness connector.
2. Check continuity between front air control harness connector
M49 terminal 5, 6 and the mode door motor harness connector
terminal 5, 6.
OK or NG
OK >> Replace mode door motor. Refer to ATC-140, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
6.CHECK FRONT AIR CONTROL FOR PBR POWER AND GROUND
1. Reconnect front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 8.
NG >> GO TO 7.
7.CHECK PBR REFERENCE VOLTAGE CIRCUIT FOR SHORT TO GROUND
ConnectorTe r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 5 6 Press
mode
switch Battery
voltage
WJIA1742E
Continuity should exist.
WJIA1728E
5 - 5 : Continuity should exist.
6 - 6 : Continuity should exist.
LJIA0027E
Connector Te r m i n a l s
Voltage (Ap-
prox.)
(+) (-)
Front air control: M49 2 15 5V
WJIA1729E
Page 428 of 3061

ATC-58
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connectorM49 terminal 2 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-123, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
8.CHECK PBR REFERENCE VOLTAGE AND GROUND CIRCUITS
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9.CHECK PBR REFERENCE VO LTAGE CIRCUIT FOR OPEN
1. Disconnect the mode door motor harness connector.
2. Check continuity between mode door motor harness connector M142 (B) terminal 3, 1 and front air control harness connector
M49 (A) terminal 2, 15.
OK or NG
OK >> Replace mode door motor. Refer to ATC-140, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
10.CHECK PBR FEEDBACK VOLTAGE
1. Reconnect the front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M49 terminal 16 and ground while cycling mode switch through all
modes.
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 .CHECK PBR FEEDBACK SIGNAL CIRCUIT FOR SHORT TO GROUND Continuity should not exist.
WJIA1730E
Continuity should exist.
WJIA1731E
2 - 3 : Continuity should exist.
15 - 1 : Continuity should exist.
WJIA1732E
Voltage : Approx. 1V - 4.5V
LJIA0032E
Page 429 of 3061

TROUBLE DIAGNOSISATC-59
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
1. Turn ignition switch OFF.
2. Disconnect front air control harness connector.
3. Check continuity between front air control harness connector
M49 terminal 16 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-123, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
12.CHECK PBR FEEDBACK CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the mode door motor harness connector and front air control harness connector.
3. Check continuity between mode door motor harness connector M142 terminal 2 and front air control harness connector M49 ter-
minal 16.
OK or NG
OK >> Replace mode door motor. Refer to ATC-140, "Removal
and Installation".
NG >> Repair or replace harness as necessary.
Air Mix Door Motor CircuitINFOID:0000000003533253
SYMPTOM:• Discharge air temperature does not change.
• Air mix door motor does not operate.
INSPECTION FLOW
1.CONFIRM SYMPTOM BY PERFORMING OPERAT IONAL CHECK - TEMPERATURE INCREASE
1. Turn the temperature control dial (driver) clockwise until 32 °C (90 °F) is displayed.
2. Check for hot air at discharge air outlets.
>> GO TO 2.
2.CONFIRM SYMPTOM BY PERFORMING OPERAT IONAL CHECK - TEMPERATURE DECREASE
1. Turn the temperature control dial (driver) counterclockwise until 16 °C (60 °F) is displayed.
2. Check for cold air at discharge air outlets.
Can a symptom be duplicated?
YES >> GO TO 4.
NO >> GO TO 3.
3.PERFORM COMPLETE OPERATIONAL CHECK
Perform a complete operational check and check for any symptoms. Refer to ATC-50, "
Operational Check
(Front)" .
Can a symptom be duplicated?
YES >> Refer to ATC-32, "How to Perform Trouble Diagnosis for Quick and Accurate Repair" .
NO >> System OK.
4.CHECK FOR SERVICE BULLETINS
Check for any service bulletins.
>> GO TO 5.
Continuity should not exist.
WJIA1733E
Continuity should exist.
LJIA0034E
Page 430 of 3061

ATC-60
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
5.CHECK AIR MIX DOOR OPERATION
Check and verify air mix door mechanism for smooth operation from 16 °C (60 °F) to 32 °C (90 °F) in each
mode.
OK or NG
OK >> GO TO 6.
NG >> Repair as necessary.
6.PERFORM SELF-DIAGNOSIS
Perform self-diagnosis to check for any codes. Refer to ATC-48, "
A/C System Self-Diagnosis Function" .
Are any self-diagnosis codes present?
YES >> Refer to ATC-48, "A/C System Self-Diagnosis Function" .
NO >> GO TO 7.
7.CHECK THE AIR MIX DOOR MOTOR PBR CIRCUIT
Perform diagnostic procedure for the air mix door motors. Refer to "Air Mix Door Motor Circuit" .
OK or NG
OK >> GO TO 8.
NG >> Repair PBR circuit or replace air mix door motor. Refer to ATC-141
.
8.RECHECK FOR CODES
Perform self-diagnosis. Refer to ATC-48, "
A/C System Self-Diagnosis Function" .
Are any self-diagnostic codes present?
YES >> Refer to ATC-48, "A/C System Self-Diagnosis Function" .
NO >> GO TO 9.
9.RECHECK FOR ANY SYMPTOMS
Perform a complete operational check for any symptoms. Refer to ATC-50, "
Operational Check (Front)".
Does another symptom exist?
YES >> Refer to ATC-32, "How to Perform Trouble Diagnosis for Quick and Accurate Repair" .
NO >> Replace front air control. Refer to ATC-123, "
Removal and Installation".
SYSTEM DESCRIPTION
Component Parts
Air mix door control system components are:
• Front air control.
• Air mix door motors (Driver, Passenger, and rear)
• PBR (built-into air mix door motors)
• In-vehicle sensor
• Ambient sensor
• Optical sensor
• Intake sensor
System Operation
The front air control receives data from the temperatur e selected by the driver side, passenger side, and rear.
The front air control then applies a voltage to one circuit of the appropriate air mix door motor, while ground is
applied to the other circuit, causing the appropriate air mix door motor to rotate. The direction of rotation is
determined by which circuit has voltage applied to it, and which one has ground applied to it. The front air con-
trol monitors the air mix door positions by measur ing the voltage signal on the PBR circuits of each door.
In AUTO mode the air mix, intake, mode door, and defrost door positions are set by the front air control which
determines the proper position based on inputs from the in-vehicle sensor, ambient sensor, optical sensor,
intake sensor, and the temperature selected by the driver and front and rear passengers.
Page 431 of 3061
TROUBLE DIAGNOSISATC-61
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
Subsequently, HOT/COLD or DEFROST/VENT or FR ESH/RECIRCULATION operation is selected. The new
door position data is returned to the front air control.
Air Mix Door Control Specification
COMPONENT DESCRIPTION
Air Mix Door Motors
The driver (1) and front passenger (2) air mix door motors are
attached to the front heater & cooling unit assembly. The rear air mix
door motor is attached to the rear heater & cooling unit. These
motors rotate so that the air mix door is opened or closed to a posi-
tion set by the front (or rear) air control. Motor rotation is then con-
veyed through a shaft and the air mix door position is then fed back
to the front air control by the PBR built into the air mix door motors.
DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR MOTOR (DRIVER)
1.CHECK FRONT AIR CONTROL FOR POWER AND GROUND
WJIA1244E
WJIA0435E
WJIA2309E
WJIA1245E
Page 432 of 3061

ATC-62
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
1. Turn ignition switch ON.
2. Rotate temperature control dial (driver) to 32°C (90 °F).
3. Check voltage between front air control harness connector M49
terminal 3 and terminal 4 while rotating temperature control dial
(driver) to 16 °C (60 °F).
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2.CHECK AIR MIX DOOR MOTOR (DRIVE R) CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 3, 4 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-123, "Removal
and Installation" .
NG >> Repair or replace harness as necessary.
3.CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (driver) to 32 °C (90 °F).
3. Check voltage between front air control harness connector M49
terminal 3 and terminal 4 while rotating temperature control dial
(driver) to 16 °C (60 °F).
OK or NG
OK >> GO TO 4.
NG >> Replace front air control. Refer to ATC-123, "
Removal and Installation" .
4.CHECK AIR MIX DOOR MOTOR (DRIVER) CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 3 and terminal 4.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.CHECK AIR MIX DOOR MOTOR ( DRIVER) CIRCUITS FOR OPEN
ConnectorTe r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 3 4 Rotate temp
control dial Battery
voltage
WJIA1735E
3 - Ground : Continuity should not exist.
4 - Ground : Continuity should not exist.
WJIA1736E
Connector Te r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 4 3
Rotate temp
control dial Battery
voltage
WJIA1737E
Continuity should exist.
WJIA1738E
