28. Install parking actuator support to rear extension (2WD models)
or adapter case (4WD models).
29. Install needle bearing to rear extension (2WD models) or
adapter case (4WD models).
CAUTION:
Apply petroleum jelly to needle bearing.
30. Install new seal rings to output shaft.
CAUTION:
• Do not reuse seal rings.
• Apply petroleum jelly to seal rings.
31. Install parking gear to output shaft.
32. Install output shaft in transmission case.
CAUTION:
Be careful not to mistake front for rear because both sides
looks similar. (Thinner end is front side.)
SCIA3423E
SCIA5221E
SCIA5209E
SCIA5247E
SCIA5030E
Page 354 of 3061
AT-284
< SERVICE INFORMATION >
ASSEMBLY
33. Install bearing race in output shaft.
34. Install rear extension assembly (2WD models) or adapter case assembly (4WD models) according to the
following procedures.
a.2WD models
i. Apply recommended sealant (Genuine Anaerobic Liquid Gasket
or equivalent) to rear extension assembly as shown. Refer to GI-
45, "Recommended Chemical Product and Sealant".
CAUTION:
Completely remove all moisture, oil and old sealant from
the transmission case and rear extension assembly mating
surfaces.
ii. Install rear extension assembly to transmission case.
iii. Install brackets (1).
iv. Tighten rear extension assembly bolts to specified torque.
CAUTION:
Do not reuse self-sealing bolts (2).
SCIA5245E
SCIA5212E
SCIA5029E
Rear extension assembly bolts : 52 N·m (5.3 kg-m,
38 ft-lb)
Self-sealing bolts : 61 N·m (6.2 kg-m,
45 ft-lb)
WCIA0562E
Page 355 of 3061
ASSEMBLY
AT-285
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
b.4WD models
i. Install new gasket to transmission case.
CAUTION:
• Do not reuse gasket.
• Completely remove all moisture, oil and old gasket from
the transmission case and adapter case assembly mating
surfaces.
ii. Install adapter case assembly to transmission case.
iii. Install brackets (1).
iv. Tighten adapter case assembly bolts to specified torque.
CAUTION:
Do not reuse self-sealing bolts (2).
35. Install needle bearing in drum support edge surface.
CAUTION:
Apply petroleum jelly to needle bearing.
SCIA5231E
SCIA5205E
Adapter case assembly bolts : 52 N·m (5.3 kg-m, 38
ft-lb)
Self-sealing bolt : 61 N·m (6.2 kg-m, 45
ft-lb)
WCIA0563E
SCIA5198E
Page 356 of 3061
AT-286
< SERVICE INFORMATION >
ASSEMBLY
36. Install direct clutch assembly in reverse brake.
37. Install high and low reverse clutch assembly in direct clutch
assembly.
38. Align the drive plate using suitable tool.
39. Install high and low reverse clutch hub, mid sun gear assembly
and rear sun gear assembly as a unit.
CAUTION:
SCIA5019E
SCIA2306E
SCIA3169E
SCIA5018E
Page 357 of 3061
ASSEMBLY
AT-287
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
Check that portion A of high and low reverse clutch drum
protrudes approximately 2 mm (0.08 in) beyond portion B of
rear sun gear.
40. Install needle bearing in rear carrier assembly.
CAUTION:
Apply petroleum jelly to needle bearing.
41. Install bearing race in rear carrier assembly.
CAUTION:
Apply petroleum jelly to bearing race.
42. Install rear carrier assembly in direct clutch drum.
43. Install needle bearing (rear side) in mid carrier assembly.
CAUTION:
Apply petroleum jelly to needle bearing.
SCIA3130E
SCIA5179E
SCIA5178E
SCIA2462E
SCIA5177E
Page 358 of 3061
AT-288
< SERVICE INFORMATION >
ASSEMBLY
44. Install needle bearing (front side) in mid carrier assembly.
CAUTION:
Apply petroleum jelly to needle bearing.
45. Install mid carrier assembly in rear carrier assembly.
46. Install front carrier assembly, input clutch assembly and rear
internal gear as a unit.
47. Install new seal rings in input clutch assembly.
CAUTION:
• Do not reuse seal rings.
• Apply petroleum jelly to seal rings.
48. Install new band servo anchor end pin and lock nut in transmis-
sion case.
CAUTION:
Do not reuse band servo anchor end pin.
SCIA5176E
SCIA5344E
SCIA5173E
SCIA5269E
SCIA5016E
Page 359 of 3061
ASSEMBLY
AT-289
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
49. Install brake band in transmission case.
CAUTION:
Assemble it so that identification to avoid incorrect installa-
tion faces servo side.
50. Install front sun gear assembly to front carrier assembly.
CAUTION:
Apply ATF to front sun gear radial bearing and 3rd one-way
clutch end bearing.
51. Install needle bearing in front sun gear assembly.
CAUTION:
Apply petroleum jelly to needle bearing.
52. Adjust brake band tilting using clips so that brake band contacts
front sun gear drum evenly.
53. Adjust brake band.
a. Loosen lock nut.
b. Tighten band servo anchor end pin to specified torque.
c. Back off band servo anchor end pin three turns.
d. Holding band servo anchor end pin, tighten lock nut to specified
torque. Refer to AT-228, "
Component".
SCIA5498E
SCIA5014E
SCIA2808E
SCIA5033E
Band servo anchor end pin : 5.0 N·m (0.51 kg-m,
44 in-lb)
SCIA5498E
Page 360 of 3061
AT-290
< SERVICE INFORMATION >
ASSEMBLY
Adjustment
INFOID:0000000003532494
TOTAL END PLAY
• Measure clearance between front sun gear and bearing race for oil
pump cover.
• Select proper thickness of bearing race so that end play is within
specifications.
1. Measure dimensions “K” and “L” and then calculate dimension
“J”.
a. Measure dimension “K”.
b. Measure dimension “L”.
c. Calculate dimension “J”.
SCIA2810E
SCIA5350E
SCIA5351E
“J”: Distance between oil pump fitting surface of
transmission case and needle bearing mating surface
of front sun gear.
J = K – L
SCIA5352E
