INFINITI QX56 2007 Factory Service Manual CO-12 < SERVICE INFORMATION > ENGINE COOLANT 1. Drain the water from the engine cooling system. 2. Fill the radiator and the reservoir tank (to the “MAX” line), with water. Reinstall the radiator

Page 1002 of 3061

INFINITI QX56 2007 Factory Service Manual RADIATOR CO-13 < SERVICE INFORMATION > C D E F G H I J K L MA CO N P O RADIATOR Removal and InstallationINFOID:0000000003531571 WARNING: Never remove the radiator cap when the engine is hot. Serious b

Page 1003 of 3061

INFINITI QX56 2007 Factory Service Manual CO-14 < SERVICE INFORMATION > RADIATOR 6. Remove the lower radiator shroud. • Release the tabs, pull lower radiator shroud rearwards and down to remove. 7. Remove the radiator shroud upper bolts and

Page 1004 of 3061

INFINITI QX56 2007 Factory Service Manual RADIATOR CO-15 < SERVICE INFORMATION > C D E F G H I J K L MA CO N P O 10. Lift up and remove the radiator. CAUTION: Do not damage or scratch air conditioner condenser and radiator core when removing.

Page 1005 of 3061

INFINITI QX56 2007 Factory Service Manual CO-16 < SERVICE INFORMATION > ENGINE COOLING FAN ENGINE COOLING FAN Removal and Installation (Crankshaft Driven Type)INFOID:0000000003531573 REMOVAL 1. Remove the air duct and resonator assembly. Refe

Page 1006 of 3061

INFINITI QX56 2007 Factory Service Manual ENGINE COOLING FAN CO-17 < SERVICE INFORMATION > C D E F G H I J K L MA CO N P O • Start and warm up the engine. Visually make sure that there are no leaks of the engine coolant. Removal and Install

Page 1007 of 3061

INFINITI QX56 2007 Factory Service Manual CO-18 < SERVICE INFORMATION > WATER PUMP WATER PUMP Removal and InstallationINFOID:0000000003531575 CAUTION: • When removing water pump, be careful not to get engine coolant on drive belt. • Water

Page 1008 of 3061

INFINITI QX56 2007 Factory Service Manual WATER PUMP CO-19 < SERVICE INFORMATION > C D E F G H I J K L MA CO N P O • Check for leaks of engine coolant. Refer to CO-9, "Inspection". • Start and warm up engine. Visually check for leaks of t
