Page 185 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual CC(ETC)(diag)-18
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
CRUISE CONTROL SYSTEM (DIAGNOSTICS)
Step Check Yes No
1CHECK NEUTRAL POSITION SWITCH.
1) Connect the Subaru Select Monitor to d

Page 186 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual CC(ETC)(diag)-19
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
CRUISE CONTROL SYSTEM (DIAGNOSTICS)
D: DTC 16 IGNITION SWITCH
TROUBLE SYMPTOM:
Cruise control cannot be set.
WIRING DIAGRAM:
CC

Page 187 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual CC(ETC)(diag)-20
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
CRUISE CONTROL SYSTEM (DIAGNOSTICS)
E: DTC 22 AND 32 VEHICLE SPEED SENSOR
DIAGNOSIS:
Open or short circuit in vehicle speed sen

Page 188 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual ET-2
General Description
ENTERTAINMENT
1. General Description
A: CAUTION
•Before disassembling or reassembling parts, al-
ways disconnect the battery ground cable from bat-
tery.
•When replacing

Page 189 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual ET-3
Audio System
ENTERTAINMENT
2. Audio System
A: WIRING DIAGRAM
<Ref. to WI-109, WIRING DIAGRAM, Audio System.>
B: INSPECTION
Symptom Repair order
No power coming in. (No display and no sound from s

Page 190 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual ET-4
Front Accessory Power Supply Socket System
ENTERTAINMENT
3. Front Accessory Power Sup-
ply Socket System
A: WIRING DIAGRAM
<Ref. to WI-121, WIRING DIAGRAM, Front Acces-
sory Power Supply Socket S

Page 191 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual ET-5
Rear Accessory Power Supply Socket System
ENTERTAINMENT
4. Rear Accessory Power Sup-
ply Socket System
A: WIRING DIAGRAM
<Ref. to WI-122, WIRING DIAGRAM, Rear Acces-
sory Power Supply Socket Syst

Page 192 of 2453

SUBARU TRIBECA 2009 1.G Service Workshop Manual ET-6
Navigation System
ENTERTAINMENT
5. Navigation System
A: WIRING DIAGRAM
<Ref. to WI-112, WIRING DIAGRAM, Navigation
System.>
B: INSPECTION
1. CHECK THE OPERATION OF THE NAVI-
GATION.
Start th

ET-6
Navigation System
ENTERTAINMENT
5. Navigation System
A: WIRING DIAGRAM
System.>
B: INSPECTION
1. CHECK THE OPERATION OF THE NAVI-
GATION.
Start the engine, and then inspect that the opening
screen is displayed.
Standard value: The opening screen should be dis-
played.
OK: Normal
NG: When not displayed, check the signal line con-
nector and the audio connector. If there are no
problems in the connecting lines or the lines were
repaired, check that the opening screen is dis-
played.
At this point, if the display is not viewable, the unit is
defective.
2. CHECK THE DVD-ROM.
An opening screen is displayed, then it switches to
the map screen after a while.
When a screen other than the opening screen is
displayed, press the «MAP» key.
Standard value: The map screen should be dis-
played.
OK: Normal
NG: If the map screen is not displayed, check
whether the DVD-ROM is set in the navigation sys-
tem, whether the correct side is set, type of the
DVD-ROM, the existence of any scratches, etc. If
there are no problems on the DVD-ROM, the main
body is defective.
3. CHECK EACH CONNECTION
If there are no problems in the inspections of 1 and
2 above, use “ GRAM, Navigation System.>” of the navigation de-
vice to perform inspection.
4. SWITCHING TO CONNECTION INSPEC-
TION MODE
1) Press the menu key.
2) Select navigation setup from the menu screen.
3) Select navigation information from the naviga-
tion setup screen.
4) Select the vehicle signal from the navigation in-
formation screen.
5) The display will switch to the vehicle signal (for
connection inspection) screen.
6) Check that the display changes according to
each operation
ON: Normal
NG: Check the circuit when the display does not
change.
5. CHECK THE GPS ANTENNA
NOTE:
When checking the GPS antenna, perform the
check operation outdoors to improve the receiver
sensitivity.
Make sure that a value other than “zero” is dis-
played in the GPS item.
OK: Normal
NG: If “No positioning” is displayed, check the GPS
antenna connection.
If the GPS display is red, the main unit could be
faulty.
6. CHECK THE BACK SENSOR
NOTE:
Before starting inspections, inspect the safety
around the rear end of the vehicle.
1) Turn the ignition switch to ON.
2) Pull the parking brake and depress the brake,
then put the gear in reverse.
3) Make sure that “On” is lit in the back sensor item.
Standard Value: “On” should be lit.
On: Normal
NG: If “On” does not light, check the signal line con-
nection. If there are no problems, the unit could be
faulty.
7. CHECK THE ILLUMINATION
1) Turn the lighting switch to level 1.
NOTE:
Make sure that the bright switch is not turned ON at
this time.
2) Make sure that “On” lights in the illumination
item, then the screen fades out.
Standard Value: “On” should be lit.
OK: Normal
NG: If “On” does not light, check the signal line con-
nection. If there are no problems, the unit could be
faulty.
8. CHECK THE PARKING SIGNAL
NOTE:
The side brake signal is normally “OFF”, so operat-
ing it will produce no change.
