2001 TOYOTA PRIUS Service Repair Manual

THS (TOYOTA HYBRID SYSTEM)
182TH19
EngineECMHV ECU
Shift Position Sensor
Brake ECU
HV Battery
Accelerator Pedal Position Sensor
Hybrid Transaxle Inverter with Converter
Battery ECU
SMR (System Main Relay)
Service Plug23

FEATURES OF THS
This system controls the following modes in order to achieve the most efficient operations to match the driv-
ing conditions:
1. Supply of electrical power from the HV battery to MG2 provides force to drive the wheels
2. While the tires are driven by the engine via the planetary gears, MG1 is driven via the planetary gears to
supply electricity to MG2 to drive the wheels
3. When the vehicle is decelerating, kinetic energy from the wheels is recovered and converted into electrical
energy and used to recharge the HV battery by means of MG2.
The HV ECU switches between these modes (1, 2, 1 + 2, or 3) according to the driving conditions. However,
when the SOC of the HV battery is low, the HV battery is charged by the engine by turning MG1.
As a result, it achieves far greater the fuel economy compared to conventional gasoline engine vehicles, at
a reduced level of exhaust gas emissions. Furthermore, this revolutionary powertrain has eliminated the
constraints that are associated with electric vehicles (such as their short cruising range or their reliance on
external recharging units).

LAYOUT OF MAIN COMPONENTS

THS (TOYOTA HYBRID SYSTEM) 24

MAIN FUNCTIONS OF COMPONENTS
MG1Generates high-voltage electricity by being powered primarily by the engine.
Also functions as a starter to start the engine.
Hybrid
Trans-
axle
MG2
Primarily provide additional power to the engine in order to increase the
overall drive force. During braking, or when the accelerator pedal is not
depressed, it generates electricity to recharge the HV battery (Regenerative
brake system).
Planetary
Gear UnitDistributes the engine's drive force as appropriate to directly drive the vehicle
as well as the generator.
HV Battery
Supplies electric power to the MG2 during start-off, acceleration, and uphill
driving; recharged during braking or when the accelerator pedal is not
depressed.
InverterA device that converts the high-voltage DC (HV battery) into AC (MG1 and
MG2) and vice versa (Converts AC into DC).
Converter
Drops the high-voltage direct current (DC 273.6 V) into DC12 V in order to
supply electricity to body electrical components, as well as to recharge the
auxiliary battery (12 V).
HV (Hybrid Vehicle
Control) ECU
Information from each sensor as well as from the ECU (ECM, Battery ECU,
ABS ECU) is received, and based on this the required torque and output power
is calculated.
The HV ECU sends the calculated result to the actuators and controllers.
ECMSends a throttle open command to the electronically-controlled throttle in
accordance with the engine output request factor received from the HV ECU.
Battery ECUMonitors the charging condition of the HV battery.
Brake ECU
Controls the regenerative brake that is effected by the MG2 and the hydraulic
brake so that the total braking force equals that of a conventional vehicle that
is equipped only with hydraulic brakes.
Also, the brake ECU performs the ABS control conventionally.
Accelerator PedalConverts the accelerator angle into an electrical signal and outputs it to the HVAccelerator Pedal
Position Sensor
Converts the accelerator angle into an electrical signal and outputs it to the HV
ECU.
Shift Position SensorConverts the shift lever position into an electrical signal and outputs it to the
HV ECU.
SMR (System Main
Relay)Connects and disconnects the high-voltage power circuit through the use of
a signal from the HV ECU.
Service plugShuts off the high-voltage circuit of the HV battery when this plug is removed
for vehicle inspection or maintenance.

THS (TOYOTA HYBRID SYSTEM)
Shift Position
Sensor
182TH05
Accelerator
Pedal Position
Sensor
BRAKE
ECU
Shift Position
(Main and Sub)
Accelerator Angle
(Main and Sub)
Regenerative
Request FactorHV ECUInverter
Voltage
SMR Control
MG2MG1
RPMEngine
Power
RequestCharging
Condition,
Amperage
SMRSMR
Amperage
HV
Battery Engine
Planetary Gear
Unit
Wheel
Wheel
ECM
Battery
ECU
Hydraulic
Brake
Actual
Regenerative
Braking Factor
Auxiliary
Battery
Mechanical Power Path
Electrical Signal Hydraulic
Converter
25

SYSTEM DIAGRAM

THS (TOYOTA HYBRID SYSTEM)
182TH24
ªREADYº LightOutput Control
Warning Light 26
DRIVING CHARACTERISTICS
Because the Prius uses a parallel series hybrid system, some aspects of its operation may differ from those of
existing automobiles, and may require precautions that are unique to this system.
1. Starting the THS
Make sure that the parking brake is engaged and that the shift lever is in the P position.
While depressing the brake pedal, turn the ignition switch to the START position. After this, the ªREADYº
light flashes.
The engine does not start when the shift lever is in the N position; it can only start in the P position. When
the external air temperature is low, the ªREADYº light may flash longer than usual.
As soon as the engine has started, the ªREADYº light illuminates steadily and a beeping sound is heard.
Several seconds after the engine warms up, the engine stops automatically, provided that the air conditioning
compressor does not need to operate and that the HV battery maintains a proper SOC (state of charge).
2. Start-Off
While keeping the brake pedal depressed, release
the parking brake, and move the shift lever to the
D position.
The vehicle has the same creeping movement as
the conventional automatic transmission vehicles.
Gradually release the brake pedal and slowly de-
press the accelerator pedal to start off.
At this time, the vehicle starts off powered only by
the MG2 (Motor Generator No.2)
NOTICE: The vehicle can be started off, provided that the ªREADYº light remains illuminated, even
if the engine remains stopped.
3. Acceleration
Depress the accelerator pedal to accelerate the vehicle.
If the engine remained stopped during start-off, the engine will start automatically during acceleration.
4. Downhill Driving
Move the shift lever to the B position as necessary in order to simultaneously apply the regenerative brake
and the engine friction brake.
5. Deceleration and Stopping
Depress the brake pedal to decelerate and to stop the vehicle.
Depressing the brake pedal causes the regenerative brake to activate automatically in the D or B position. (In
the regenerative brake system, kinetic energy is converted to electrical energy.) If the engine has warmed up,
the air conditioning compressor does not need to operate, and if the HV battery maintains a proper SOC (state
of charge), the engine stops automatically when the vehicle speed drops-even if the vehicle comes to a stop.
6. Parking
Push down the parking brake pedal, move the shift lever to the P position, and pull out the ignition key.
NOTICE: Make sure to pull out the ignition key after parking the vehicle because the vehicle can be
driven as long as the ªREADYº light remains illuminated even if the engine is stopped.
7. Other Characteristics and Precautions

If a drive wheel slips on slippery terrain, causing the front wheels to spin faster than the rear wheels, the
THS effects control to limit the slippage by restraining the drive force. (This also protects the planetary
gear from damage.)

When the HV battery temperature is too high or low, the output control warning light illuminates, alerting
the driver that output power may be limited.
This is not 2 malfunction. This condition may be corrected by avoiding sudden acceleration /decelaration,
after which the light will go out.

When the vehicle is stopped and the shift lever is in the N position, electricity is not generated even if the
engine is running. If the vehicle remains stopped for a long time, make sure to move the shift lever to the
P position. In heavy traffic, keep the shift lever in the D position.
