2001 TOYOTA PRIUS Service Repair Manual

PP0T0±01
± PREPARATIONSUPPLEMENTAL RESTRAINT SYSTEM
PP±47
2001 PRIUS (RM778U)
EQUIPMENT
Torque wrench
Bolt: Length: 35 mm (1.38 in.) Pitch: 1.0 mm (0.039 in.)
Diam: 6.0 mm (0.236 in.)Airbag disposal
Tire Width: 185 mm (7.28 in.) Inner diam: 360 mm (14.17 in.)Airbag disposal
Tire with disc wheel Width: 185 mm (7.28 in.)
Inner diam: 360 mm (14.17 in.)Airbag disposal
Vinyl bagAirbag disposal

PP26C±02
PP±48
± PREPARATIONBODY ELECTRICAL
109 Author: Date:
2001 PRIUS (RM778U)
BODY ELECTRICAL
SST (Special Service Tools)
09843±18040Diagnosis Check Wire No.2

PP26D±02
± PREPARATIONBODY ELECTRICAL
PP±49
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.
09041±00030Torx Driver T30 .Steering wheel pad
09042±00010Torx Socket T30 .Steering wheel pad

PP26E±02
PP±50
± PREPARATIONBODY ELECTRICAL
2001 PRIUS (RM778U)
EQUIPMENT
Voltmeter
Ammeter
Ohmmeter
Test lead
SyphonBrake fluid level warning switch
Bulb (3.4W)Fuel sender gauge, Fuel level warning switch
Dry cell batteryWireless door lock transmitter
Torque wrench
Masking tapeRear window defogger wire
Tin foilRear window defogger wire

PP26F±03
± PREPARATIONBODY ELECTRICAL
PP±51
2001 PRIUS (RM778U)
SSM (Special Service Materials)
08888±88888DuPont Paste No. 4817 or
equivalentRear window defogger

PP3B4±01
PP±52
± PREPARATIONBODY
11 3 Author: Date:
2001 PRIUS (RM778U)
BODY
SST (Special Service Tools)
09812±00010Door Hinge Set Bolt Wrench
09804±24010Luggage Compartment Door Torsion
Bar Tool
09082±00700SRS Airbag Deployment Tool
09082±00730Airbag Deployment Wire Sub±Harne
ss No.1
09082±00740Airbag Deployment Wire
Sub±harness No.2

PP3B0±01
± PREPARATIONBODY
PP±53
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09050±20010Air Riveter.
(09050±02010)Dust Cap.
(09050±02020)Nose Piece No.1.
09050±00032Air Drill
(09050±00210)Chuck Set
(09050±00220)Handle
09060±60350Revet Cutter.
09070±20010Moulding Remover .

PP3B1±01
PP±54
± PREPARATIONBODY
2001 PRIUS (RM778U)
EQUIPMENT
Clip remover
Torque wrench
Hexagon wrench (6 mm)
Torx driver
Hog ring pliers
Hand riveter
TapeTo avoid surface damage
Adhesive tapeTo avoid surface damage
Double±stick tape
Adhesive
Cleaner
Shop rag
Knife
Sealer gun
Brush
Putty spatula
Glass plate or similar object
Wooden block or similar object
Heat light
Piano wire
Rope (no projections, difficult to break)Seat belt pretensioner
Tire with disk wheel Width: 185 mm (7.28 in.)
Inner diam: 360 mm (14.17 in.)Seat belt pretensioner
Vinyl bagSeat belt pretensioner
