BE±88
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
2. REPLACE DOOR CONTROL RECEIVER AND TRANS-
MITTER
NOTICE:
When replacing the door control receiver and transmitter,
registration of recognition code is necessary because they
are provided as single components.
(a) Select which operation mode should be performed from
the following modes.
Add mode
Rewrite mode
Prohibition mode
Confirmation mode
HINT:
The add mode is used to retain codes already registered
while you register new recognition codes. This mode is
used when adding a transmitter. However, if the number
of registered codes exceeds 4 codes, previously regis-
tered codes are correspondingly erased in order, starting
from the first registered code.
The rewrite mode is used to erase all previously regis-
tered codes and register only new recognition codes.
The prohibition mode is used to erase all registered codes
and cancels the wireless door lock function. Use this
mode when the transmitter is lost.
The confirmation mode is for confirming how many recog-
nition codes are already registered before you register
additional recognition codes.
(b) Follow the chart on the following pages to register the
transmitter recognition code at the wireless door lock con-
trol receiver.
HINT:
When procedure is out of the specified, the operation re-
turns to normal operation.
Maximum 4 recognition codes can be registered.

± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±89
2001 PRIUS (RM778U)
Start registration of recognition code
The vehicle should be in the following conditions.

The key is not inserted in the ignition key cylinder.

Driver's door is OPEN. (Other doors are CLOSED)

Driver's door is UNLOCKED.
Insert the key into the ignition key cylinder, then pull it out. (Rerform this twice within 5 seconds)
Close and open the door (manual operation) 2 times.
1st time 2nd time
OPEN CLOSE
Close the all door and insert the key into the ignition key cylinder.
Within
40 secs.
Within
40 secs.
Insert the key into the ignition key cylinder, then pull it out.
1st time 2nd time
OPEN CLOSE
Again close and open the door (manual operation) 2 times.

BE±90
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
Within
3 secs.
Turn the ignition switch from ON to LOCK at approx. 1 sec. interval 1 to 5 times to select the mode.
Pull out the key from the ignition key cylinder.
When add mode or rewrite mode
is selected.When confirmation
mode is selected.
ON
ONON
LOCK
LOCKLOCK
Approx.
1 sec.Approx.
1 sec. Approx. 1 sec.Approx.
1 sec.Approx.
1 sec.
Add mode
Rewrite modeConfirmation mode
ON ± LOCK change occurs 1 time
ON ± LOCK change occurs 2 timesON ± LOCK change occurs 3 times
Door control relay automatically performs
the LOCK±UNLOCK operation once
or twice at 1 sec. interval to inform the
operator that either the add mode or
rewrite mode has been selected.
LOCK±UNLOCK occurs once
LOCK±UNLOCK occurs twice
Indicates that add mode has been selected.
Indicates that rewrite mode has been
selected.
1 sec.
LOCK
1 sec.1 sec.
LOCK
UNLOCK
UNLOCK
LOCK
2 secs.2 secs.
UNLOCK Door control relay automatically performs
the LOCK±UNLOCK operation 1 to 4 times
at 2 sec. interval to inform the operator of
the number of the registered codes.
HINT:
When the number of the registered code
is 0, the operation is automatically
performed 5 times.
Example:
When the operation is performed twice, it
directs that 2 types of recognition code
have been registered.
1st time 2nd time
Registration of recognition code (Confirmation
mode and prohibition mode) is completed.
ON
LOCK
Approx.
1 sec.Approx.
1 sec.
Prohibition mode
ON ± LOCK change occurs 5 times
When prohibition
mode is selected.

± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±91
2001 PRIUS (RM778U)
Door control relay performs LOCK±UNLOCK operation 5 times at a 1 sec.
interval to inform the operator that prohibition mode has been selected.
Press one of 3 switches on the transmitter.
Door control relay automatically performs LOCK±UNLOCK operation once or
twice at a 1 sec. interval to inform the operator that the receiver has received the
signal from the transmitter.
LOCK±UNLOCK occurs once
LOCK±UNLOCK occurs twice Registration of recognition code is completed
Registration of recognition code has not been completed.

Recognition code received first time and second time did not match.

When selecting add mode, a registered recognition code was received.
Proceed to continue registration
If even one of the following conditions is satisfied, registration of recognition
codes is completed.

40 secs. elapses since the door control relay response.

The driver's door is opened.

The key plate is inserted in the ignition key cylinder.

4 type recognition codes are registration at one time.
Registration of recognition codes (add mode or rewrite mode) is completed.
Within
3 secs. Within
40 secs.
LOCK
Approx.
1 sec.Approx.
1 sec.
When prohibition
mode is selected.
Press the lock and unlock switches on the transmitter switch simultaneously for
more than between 1 sec. or more and 1.5 sec. below.
If LOCK±UNLOCK operation can not be performed at all, the mode returns to the
normal mode, then start with ºStart registration of recognition codeº.
Proceed to finish registration
Within 40 secs.
Within
3 secs.
UNLOCK
