Page 1649 of 1943
HT00J±02
D09790
HT±54
± HYBRID TRANSAXLESHIFT LOCK SYSTEM
2001 PRIUS (RM778U)
INSPECTION
1. INSPECT SHIFT POSITION SENSOR
(a) Remove the steering column upper cover and lower cov-
er.
(b) Disconnect the shift position sensor connector.
(c) Check continuity between terminals shown below when
the shift lever is moved to each position
Shift PositionTerminal No. to continuityTerminal No. to continuity
P1 ± 23 ± 8 ± 9
R1 ± 43 ± 8 ± 9
N1 ± 53 ± 8 ± 9
D1 ± 63 ± 8 ± 9
B1 ± 73 ± 8 ± 9
(d) Connect the shift position sensor connector.
(e) Install the steering column upper cover and lower cover.
Page 1650 of 1943

D09785
SLS+
STPACC IGA
E B
P1
P
P2
SLS±KLS+
D09783
D09784
± HYBRID TRANSAXLESHIFT LOCK SYSTEM
HT±55
2001 PRIUS (RM778U)
2. INSPECT SHIFT LOCK CONTROL ECU
Using a voltmeter, measure the voltage at each terminal.
HINT:
Do not disconnect the ECU connector.
TerminalMeasuring ConditionVoltage (V)
A, 1 ± A, 5 (ACC ± E)Ignition switch ACC10 ± 14
A, 3 ± A, 5 (IG ± E)Ignition switch ON10 ± 14
A, 6 ± A, 5 (STP ± E)Depressing brake pedal10 ± 14
A, 4 ± A, 5 (KLS+ ± E)
5. Ignition switch ACC and P position
6. Ignition switch ACC and except P position
7. Ignition switch ACC and except P position (After approx. 1 second)0
7.5 ± 11
6 ± 9.5
B, 1 ± B, 5 (SLS+ ± SLS±)
1. Ignition switch ON and P position
2. Depress brake pedal
3. Except P position0
8 ± 13.5
0
B, 2 ± B, 4 (P1 ± P)1. Ignition switch ON, P position and depress brake pedal
2. Shift except P position under conditions above0
9 ± 13.5
B, 6 ± B, 4 (P2 ± P)1. Ignition switch ACC, P position
2. Shift except P position under conditions above9 ± 13.5
0
3. INSPECT SHIFT LOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure the resistance between ter-
minals.
Standard resistance: 29 ± 35 W
If the resistance value is not as specified, replace the solenoid.
(c) Apply battery positive voltage between terminals. Check
the operation.
If the solenoid does not operate, replace the solenoid noise can
be heard from the solenoid.
Page 1651 of 1943
I04108
Q07191
D09785
SLS+
STPACC IGA
E B
P1
P
P2
SLS±KLS+
HT±56
± HYBRID TRANSAXLESHIFT LOCK SYSTEM
2001 PRIUS (RM778U)
4. INSPECT KEY INTERLOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure the resistance between ter-
minals 3 and 4.
Standard resistance: 12.5 ± 16.5 W
If the resistance value is not as specified, replace the solenoid.
(c) Apply battery positive voltage between the terminals 3
and 4. Check that an operation sound can be heard from
the solenoid.
If the solenoid does not operate, replace the solenoid.
5. INSPECT SHIFT LOCK CONTROL SWITCH
Check that there is continuity between terminals.
Shift positionTester connectionStandard
P positionA, 5 ± B, 2 (E ± P1)Continuity
P position
(Pull the shift lever toward
you)A, 5 ± B, 2 (E ± P1)
A, 5 ± B, 6 (E ± P2)Continuity
R, N, D, 2, L positionA, 5 ± B, 6 (E ± P2)Continuity
If continuity is not identified, replace the switch.
Page 1652 of 1943

HT00R±02
D09770
AT2799
D09771
D09772
A
B HT±64
± HYBRID TRANSAXLEDIFFERENTIAL CASE
2001 PRIUS (RM778U)
REASSEMBLY
1. ASSEMBLE DIFFERENTIAL CASE
(a) Coat the 2 side gear thrust washers and 2 pinion thrust
washers with ATF.
(b) Install the 2 side gears, 2 pinions and 4 thrust washers to
the case.
(c) Check the side gear backlash.
Measure the side gear backlash while pushing one pinion
gear toward the case.
Standard backlash:
0.05 ± 0.20 mm (0.0020 ± 0.0079 in.)
Referring to the table below, select thrust washers
which backlash is surely within the specified range.
Select washers of the same size for both sides.
Thrust washer thickness
ThicknessThickness
0.95 mm (0.0374 in.)1.10 mm (0.0433 in.)
1.00 mm (0.0394 in.)1.15 mm (0.0453 in.)
1.05 mm (0.0414 in.)1.20 mm (0.0472 in.)
If the backlash is not within the specified range, install a thrust
washer of a different thickness.
(d) Using a pin punch and a hammer, install the straight pin.
(e) Stake the differential case.
2. INSTALL 2 TAPERED ROLLER BEARINGS
CAUTION:
A: The one which has bigger rollers
(The number of rollers is 22.)
B: The one which has smaller rollers
(The number of rollers is 24.)
Page 1653 of 1943
D09773
SST
D09774
SST
± HYBRID TRANSAXLEDIFFERENTIAL CASE
HT±65
2001 PRIUS (RM778U)
(a) Using SST and a press, press in the tapered roller bearing
RH. (Bearing B)
SST 09710±22021 (09710±01031), 09950±70010
(09951±07100)
(b) Using SST and a press, press in the tapered roller bearing
LH. (Bearing A)
SST 09710±22021 (09710±01031), 09950±70010
(09951±07100)
Page 1654 of 1943

SA0CC±10
R03031
R15157
Front
R07928
R14731
Backlash:Deviation: SA±2
± SUSPENSION AND AXLETIRE AND WHEEL
1452 Author: Date:
2001 PRIUS (RM778U)
TIRE AND WHEEL
INSPECTION
1. INSPECT TIRE
(a) Check the tires for wear and proper inflation pressure.
Cold tire inflation pressure:
(Tire size: P175/65R14 84S)
FrontRear
240 kPa (2.4 kgf/cm2, 35 psi)230 kPa (2.3 kgf/cm2, 33 psi)
(b) Using a dial indicator, check the tire runout.
Tire runout: 1.0 mm (0.039 in.) or less
2. ROTATING TIRES
HINT:
See the illustration for where to rotate each tire.
3. INSPECT WHEEL BALANCE
(a) Check and adjust the Off±the±car balance.
(b) If necessary, check and adjust the On±the±car balance.
Imbalance after adjustment: 8.0 g (0.018 lb) or less
4. CHECK WHEEL BEARING LOOSENESS
(a) Using a dial indicator, check the backlash near the center
of the axle hub.
Maximum: 0.05 mm (0.0020 in.)
If the backlash exceeds the maximum, replace the bearing.
(b) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.07 mm (0.0028 in.)
If the deviation exceeds the maximum, replace the axle hub.
Page 1655 of 1943
± SUSPENSION AND AXLETIRE AND WHEEL
SA±3
1453 Author: Date:
2001 PRIUS (RM778U)
5. CHECK FRONT SUSPENSION FOR LOOSENESS
6. CHECK STEERING LINKAGE FOR LOOSENESS
7. CHECK BALL JOINT FOR LOOSENESS
8. CHECK SHOCK ABSORBER WORKS PROPERLY
Check if oil leaks
Check mounting bushings for wear
Bounce front and rear of the vehicle
Page 1656 of 1943

F11573
Front:
Rear:SA1CK±11
Z03382
Alignment
TesterGauge
F07339
SA±4
± SUSPENSION AND AXLEFRONT WHEEL ALIGNMENT
1454 Author: Date:
2001 PRIUS (RM778U)
FRONT WHEEL ALIGNMENT
INSPECTION
1. MEASURE VEHICLE HEIGHT
Vehicle height:
Tire sizeFront*1 mm (in.)Rear*2 mm (in.)
175/65R14191 (7.52)239 (9.41)
*1: Front measuring point
Measure the distance from the ground to the head center of the
front side lower suspension arm mounting bolt.
*
2: Rear measuring point
Measure the distance from the ground to the center of the rear
axle beam mounting bolt.
NOTICE:
Before inspecting the wheel alignment, adjust the vehicle
height to the specified value.
If the vehicle height is not the specified value, try to adjust it by
pushing down on or lifting the body.
2. INSTALL CAMBER±CASTER±KINGPIN GAUGE OR
POSITION VEHICLE ON WHEEL ALIGNMENT TES-
TER
Follow the specific instructions of the equipment manufacturer.
3. INSPECT CAMBER, CASTER AND STEERING AXIS
INCLINATION
Camber, caster and steering axis inclination:
Camber
Right±left error±0°26' ± 45' (±0.43° ± 0.75°)
45' (0.75°) or less
Caster
Right±left error1°02' ± 45' (1.03° ± 0.75°)
45' (0.75°) or less
Steering axis inclination
Right±left error9°52' ± 45' (9.87° ± 0.75°)
45' (0.75°) or less
If the caster and steering axis inclination are not within the spe-
cified values, after the camber has been correctly adjusted, re-
check the suspension parts for damaged and/or worn out parts.
4. ADJUST CAMBER
NOTICE:
After the camber has been adjusted, inspect the toe±in.
(a) Remove the front wheel.
(b) Remove the 2 nuts on the lower side of the shock absorb-
er.
If reusing the bolts and/or nuts, coat the threads of nuts with en-
gine oil.
(c) Clean the installation surfaces of the shock absorber and
the steering knuckle.
(d) Temporarily install the 2 nuts.
