Page 121 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
C8 CIGARETTE LIGHTER
2±GROUND : Approx. 12 volts with the ignition SW at ACC or ON position
1±GROUND : Always continuity
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
C

Page 122 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
HORN
10A
HORN FROM POWER SOURCE SYSTEM (
SEE PAGE 50)
23 15
1J 21F9
1
IA2 8
D D
6HORN
RELAY
B±R
B±W B±R B±R
HORN SW
[COMB. SW] C14 JUNCTION
CONNECTOR J20HORN H 4

Page 123 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
HORN RELAY
5±3 : Closed with the horn SW on
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
C1436H434J2037
�� : JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee Pag

Page 124 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
POWER WINDOW
15A
DOMEFROM POWER SOURCE SYSTEM (
SEE PAGE 50)
1J 720A
PWR1
2J 1110A
GAUGE
2K 1030A
POWER
23 15
2I 32K72K 1
B CBC
A AAA 2G 2
2D 4
IG1 1IC13IC18IC12
34
MIC1 7
11B F
A

Page 125 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
IN1 5 IN1 7 IQ1 3
EU D PCT SU SDBB1 4 3 BB1 BB1 5
EU D PCT SU SD5 BA1 BA13 4 BA1
EU D PCT SU SD 2J 10 2K52L22L1
M 21
M 21
M 12
BA1 1 BB1 1 IQ1 1
IGBI 14 1 5 10
35 2 532352 46 1 46

Page 126 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
POWER WINDOW
Communication between power window master SW and body ECU is controlled and body ECU recognizes the conditions of
each SW to control the operation of windows.
1. MANU

2001 PRIUS (EWD414U)
POWER WINDOW
Communication between power window master SW and body ECU is controlled and body ECU recognizes the conditions of
each SW to control the operation of windows.
1. MANUAL UP OR DOWN OPERATION (DRIVER'S WINDOW, PASSENGER'S WINDOW)
During you are pushing power window master SW (Driver side) halfway down, the motor operates and the window on the
driver's side opens. During you are pulling power window master SW (Driver side) halfway up, the motor operates and the
windows on the driver's side closes. The window on the passenger's side opens or closes by pushing down or pulling up
power window master SW (Front passenger, rear passenger) or power window SW front RH, rear LH, RH.
2. AUTO UP OR DOWN OPERATION (DRIVER'S WINDOW)
When the power window master SW (Driver side) is fully pushed down, the motor operates and the window on the driver's
side automatically opens. When the power window master SW (Driver side) is fully pulled up, the motor operates and the
window on the driver's side automatically closes.
3. STOPPING AUTOMATIC WINDOW OPERATION
If you push the power window master SW (Driver side) halfway down during the window on the driver's side is raising
automatically, the motor's operation stops. And if you pull the power window master SW (Driver side) halfway up during the
window on the driver's side is lowering automatically, the motor's operation stops.
4. KEY OFF POWER WINDOW OPERATION
After the Ignition SW is turned off, the windows can be operated for about 43 seconds. However, the window operation stops
when either front doors opens.
5. JAM PROTECTION FUNCTION (DRIVER'S WINDOW)
When any foreign object gets caught during power window UP operation, the motor rotates in the opposite direction to open
the window.
P9 POWER WINDOW MASTER SW
1±GROUND : Always approx. 12 volts
4±GROUND : Approx. 12 volts with the ignition SW at ON position
9±GROUND : Always continuity
B8 (A), B9 (B) BODY ECU
15±GROUND : Approx. 12 volts with the ignition SW at ON position
(B)9±GROUND : Always approx. 12 volts
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
B8A36J15B37P739
B9B36J1637P839
D436J1737P939
D638J2037P1039
D738J24A37P1139
J12A37J25B37P1239
J13B37J2737P1339
J14A37P639
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee PageJunction Block and Wire Harness (Connector Location)
1J27Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2C30Instrument Panel Wire and Instrument Panel J/B (Cowl Side Panel LH)2D30Instrument Panel Wire and Instrument Panel J/B (Cowl Side Panel LH)
2G31Engine Room Main Wire and Instrument Panel J/B (Cowl Side Panel LH)
2I
2J31Cowl Wire and Instrument Panel J/B (Cowl Side Panel LH)
2K
()
2L31Floor Wire and Instrument Panel J/B (Cowl Side Panel LH)
SYSTEM OUTLINE
SERVICE HINTS

Page 127 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
IB142Floor Wire and Cowl Wire (Cowl Side Panel LH)
IC142Fr

Page 128 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
REMOTE CONTROL MIRROR
43 52 6 78
MV MH
VR HR VL HL M+ EB
SELECT SW OPERATION SW
REMOTE CONTROL MIRROR SW R 5
UP
DOWN
LEFT
RIGHT
LEFT/
UP
RIGHT/
DOWN
10A
ACC FROM POWER SOURCE SYST
