2001 TOYOTA PRIUS Service Repair Manual

PP2FE±03
± PREPARATIONEMISSION CONTROL
PP±7
68 Author: Date:
2001 PRIUS (RM778U)
EMISSION CONTROL
EQUIPMENT
Torque wrench
Vacuum gauge
Pressure gauge
Hose clipper
MITYVAC (Hand±held vacuum pump)
TOYOTA hand held tester or OBDII scan tool

PP3AX±02
PP±8
± PREPARATIONSFI
69 Author: Date:
2001 PRIUS (RM778U)
SFI
SST (Special Service Tools)
09268±21010Fuel Hose Puller
09268±41047Injection Measuring Tool Set
(95336±08070)Hose
09268±45014EFI Fuel Pressure Gauge
(09268±41200)Gauge
(09268±41220)Hose
(09268±41250)T Joint
09816±30010Oil Pressure Switch Socket
09842±30080EFI Inspection Wire ºHº
09843±18020Diagnosis Check Wire

PP2FQ±02
± PREPARATIONSFI
PP±9
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.
09200±00010Engine Adjust Kit .
09258±00030Hose Plug Set .Plug for the vacumm hose, fuel hose
etc.

PP1WF±02
PP±10
± PREPARATIONSFI
2001 PRIUS (RM778U)
EQUIPMENT
Carburetor cleanerThrottle body
Graduated cylinderInjector
TOYOTA hand held tester or OBD II scan tool
Soft brushThrottle body
Sound scopeInjector
Torque wrench
Vacuum gauge

PP3AY±01
± PREPARATIONCOOLING
PP±11
72 Author: Date:
2001 PRIUS (RM778U)
COOLING
SST (Special Service Tools)
09960±10010Variable Pin Wrench Set
(09962±01000)Variable Pin Wrench Arm Assy
(09963±00600)Pin 6

PP2FG±02
PP±12
± PREPARATIONCOOLING
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.

PP2FH±02
± PREPARATIONCOOLING
PP±13
2001 PRIUS (RM778U)
EQUIPMENT
Belt tension gauge
HeaterThermostat
Radiator cap tester
ThermometerThermostat
Torque wrench
Vernier calipers

PP2FI±03
PP±14
± PREPARATIONCOOLING
2001 PRIUS (RM778U)
COOLANT
ItemCapacityClassification
Engine coolant4.9 liters (5.2 US qts, 4.3 lmp. qts)Ethylene±glycol base
