Page 97 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
MEMO

Page 98 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
STOP LIGHT
15A
STOP FROM POWER SOURCE SYSTEM (
SEE PAGE 50)
2K 9
1 2
IB1 9
A CAC
B ABA
2 1
B CBC
A B
BI BK E E
G±W
G±W W±B W±B W±B
W± B G± WG± W G± W G± W R± B
W±B STO

Page 99 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
S3 STOP LIGHT SW
2±1 : Closed with the brake pedal depressed
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
H1538J31B38R639
J1437J32A38R739
J30A38J33B38S337
�� : J

Page 100 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
BACK±UP LIGHT
10A
GAUGE FROM POWER SOURCE SYSTEM (
SEE PAGE 50)
2C 3
52 31
D 13 D14 C19 C184 1
ID 2D 8
2K 8
BI BKB C
A BB BA BAB IF1 9B BA DAD
IJ1 5
4 16
11A E14
A E
A 4 11 15
MP

Page 101 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
P1 PARK/NEUTRAL POSITION SW
4±1 : Closed with the shift lever at R position
B5 BACK±UP LIGHT RELAY
3±5 : Closed with the shift lever at R position
: PARTS LOCATION
CodeSee Pa

Page 102 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
LIGHT AUTO TURN OFF
120A MAIN
1B 1C1
D 11B 1130A
HEAD
1 2
32 41
1F 823 15
7. 5A
TAI L FROM POWER SOURCE SYSTEM (
SEE PAGE 50)
2K 62H 1
B 2B11ID2 2 IA2 6
ID2 3
B 17 B18
IG ID2 5ID2

Page 103 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
With the ignition SW turned on, the current flows to TERMINAL 15 of the body ECU through GAUGE fuse.
Voltage is applied at all times to TERMINAL (A) 11 of the body ECU through the

2001 PRIUS (EWD414U)
With the ignition SW turned on, the current flows to TERMINAL 15 of the body ECU through GAUGE fuse.
Voltage is applied at all times to TERMINAL (A) 11 of the body ECU through the TAIL relay. Coil side, and to TERMINAL (A)
2 through the HEAD relay coil side (w/o daytime running light) or through the daytime running light relay (w/ daytime running
light).
1. NORMAL LIGHTING OPERATION

With the light control SW turned to TAIL position, a signal is input into TERMINAL (A) 18 of the body ECU. Due to this signal,
the current flowing to TERMINAL (A) 11 of the body ECU flows to TERMINAL (A) 18 to TERMINAL 14 of the light control SW
to TERMINAL 16 to GROUND, and taillight relay causes taillights to turn on.

With the light control SW turned to HEAD position, a signal is input into TERMINALS (A) 17 and (A) 18 of the body ECU. Due
to this signal, the current flowing to TERMINAL (A) 2 of the body ECU flows to TERMINAL (A) 17 to TERMINAL 13 of the
light control SW to TERMINAL 16 to GROUND in the headlight circuit, and causes taillight and HEAD relay to turn the lights
on. The taillight circuit is same as above.
2. LIGHT AUTO TURN OFF OPERATION
With light on and ignition SW turned off (Input signal goes to TERMINAL 15 of the body ECU), when the driver's door is
opened (Input signal goes to TERMINAL 3 of the body ECU), the ECU operates and the current is cut off which flows from
TERMINAL (A) 11 of the body ECU to TERMINAL (A) 18 in taillight circuit and from TERMINAL (A) 2 to TERMINAL (A) 17 in
headlight circuit.
As a result, all lights are turned off automatically.
HEAD RELAY
2±1 : Closed with the light control SW at HEAD position or the dimmer SW at FLASH position
Closed with the engine running and the parking brake lever released (Parking brake SW off) [w/ daytime running light]
TAIL RELAY
3±5 : Closed with the light control SW at TAIL or HEAD position
D6 DOOR COURTESY SW LH
1±GROUND : Continuity with the front LH door open
B8 (A), B9 (B) BODY ECU
15±GROUND : Approx. 12 volts with the ignition SW at ON position
3±GROUND : Continuity with the front LH door open
(B) 9±GROUND : Always approx. 12 volts
(A) 1±GROUND : Always continuity
(A) 2±GROUND : Continuity with the light control SW at HEAD position
(A)11±GROUND : Continuity with the light control SW at TAIL or HEAD position
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
B9B36F13D34J2037
C1336F1838J24A37
D336J1137J25B37
D638J12A37J2737
F11B34J13B37U137
F12C34J1737
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee PageJunction Block and Wire Harness (Connector Location)
1B27Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)1F27Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2C30Instrument Panel Wire and Instrument Panel J/B (Cowl Side Panel LH)2D30Instrument Panel Wire and Instrument Panel J/B (Cowl Side Panel LH)
2H31Engine Room Main Wire and Instrument Panel J/B (Cowl Side Panel LH)
2K31Cowl Wire and Instrument Panel J/B (Cowl Side Panel LH)
SYSTEM OUTLINE
SERVICE HINTS

Page 104 of 1943

TOYOTA PRIUS 2001 Service Repair Manual 2001 PRIUS (EWD414U)
LIGHT AUTO TURN OFF
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
IA242Engine Room Main Wire and Cowl Wi
