DTC P1349 VVT System Malfunction
CIRCUIT DESCRIPTION
VVT system controls the intake valve timing to proper timing in response to driving condition.
ECM controls OCV (Oil Control Valve) to make the intake valve timing properly, and, oil pressure controlled
with OCV is supplied to the VVT controller, and then, VVT controller changes relative position between the
camshaft and the crankshaft.
DTC No.DTC Detecting ConditionTrouble Area
P1349
Condition (a) or (b) continues for after the engine is
warmed up and engine speed at 400 ± 4,000 rpm :
(a) Valve timing does not change from of current valve timing
(b) Current valve timing is fixed.Valve timing
Oil control valve
VVT controller assembly
ECM
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected, when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel ratio lean or rich, etc.
at the time of the malfunction.
TOYOTA hand±held tester
1 Check valve timing (See page EM±21).
NG Repair valve timing.
OK
DI6VL±02
Page 722 of 1943

A02397
OCV Signal Waveform
1 m sec./Division5 V/
Division
GND
(A) (A) (A)
DI±122
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
2 Check operation of OCV.
PREPARATION:
(a) Start the engine and warmed it up.
(b) Connect the TOYOTA hand±held tester and select VVT from ACTIVE TEST menu.
CHECK:
Check the engine speed when operate the OCV by the TOYOTA hand±held tester.
OK:
VVT system OFF to ON (OCV OFF to ON):
Engine speed increases.
VVT system ON to OFF (OCV ON to OFF):
Engine is stalled.
HINT:
The change of engine speed lasts only few seconds.
OK VVT system is OK.*
*: DTC P1349 is also output after the foreign object is caught
in some part of the system in the engine oil and the system re-
turns to normal in a short time. As ECM controls so that foreign
objects are ejected, there is no problem about VVT. There is
also no problem since the oil filter should get the foreign object
in the engine oil.
NG
3 Check voltage between terminals OCV+ and OCV± of ECM connector.
Reference: INSPECTION USING OSCILLOSCOPE
Turn the ignition switch ON, check waveform between terminals
OCV+ and OCV± of the ECM connector.
HINT:
The correct waveform is as shown.
The waveform frequency (A) is lengthened as the engine
speed becomes higher.
NG Check and replace ECM (See page IN±41).
OK
Page 723 of 1943
± DIAGNOSTICSENGINE
DI±123
2001 PRIUS (RM778U)
4 Check VVT controller assembly (See page EM±33).
NG Replace VVT controller assembly, and then go
to step 5.
OK
5 Check oil control valve (See page SF±35).
NG Replace oil control valve, and then go to step 6.
OK
6 Check blockage of oil control valve, oil check valve and oil pipe No.1.
NG Repair or replace.
OK
7 Check whether or not DTC P1349 is stored.
PREPARATION:
(a) Clear the DTC (See page DI±3).
(b) Perform simulation test.
CHECK:
Check whether or not DTC P1349 is stored (See page DI±3).
OK:
DTC P1349 is not stored
OK VVT system is OK.*
*: DTC P1349 is also output after the foreign object is caught
in some part of the system in the engine oil and the system re-
turns to normal in a short time. As ECM controls so that foreign
objects are ejected, there is no problem about VVT. There is
also no problem since the oil filter should get the foreign object
in the engine oil.
Page 724 of 1943
A14061A14062A14465
OCV Connector
(a)
(b)
DI±124
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
NG
Replace ECM.
OBD II scan tool (excluding TOYOTA hand±held tester)
1 Check valve timing (See page EM±21).
NG Repair valve timing.
OK
2 Check operation of OCV.
PREPARATION:
Start the engine.
CHECK:
(a) Check the engine speed when disconnect the OCV con-
nector.
(b) Check the engine speed when apply battery positive volt-
age between terminals of OCV.
RESULT:
ResultCheck (a)Check (b)
1Normal engine speedRough idle or engine stall
2Except 1
2 Go to step 4.
1
Page 725 of 1943

A02397
OCV Signal Waveform
1 m sec./Division5 V/
Division
GND
(A) (A) (A)
± DIAGNOSTICSENGINE
DI±125
2001 PRIUS (RM778U)
3 Check voltage between terminals OCV+ and OCV± of ECM connector.
Reference: INSPECTION USING OSCILLOSCOPE
Turn the ignition switch ON, check waveform between terminals
OCV+ and OCV± of the ECM connector.
HINT:
The correct waveform is as shown.
The waveform frequency (A) is lengthened as the engine
speed becomes higher.
OK VVT system is OK.*
*: DTC P1349 is also output after the foreign object is caught
in some part of the system in the engine oil and the system re-
turns to normal in a short time. As ECM controls so that foreign
objects are ejected, there is no problem about VVT. There is
also no problem since the oil filter should get the foreign object
in the engine oil.
NG
Check and replace ECM (See page IN±41).
4 Check VVT controller assembly (See page EM±33).
NG Replace VVT controller assembly, and then go
to step 5.
OK
5 Check oil control valve (See page SF±35).
NG Replace oil control valve, and then go to step 6.
OK
Page 726 of 1943
DI±126
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
6 Check blockage of oil control valve, oil check valve and oil pipe No.1.
NG Repair or replace.
OK
7 Check whether or not DTC P1349 is stored.
PREPARATION:
(a) Clear the DTC (See page DI±3).
(b) Perform simulation test.
CHECK:
Check whether or not DTC P1349 is stored (See page DI±3).
OK:
DTC P1349 is not stored
OK VVT system is OK.*
*: DTC P1349 is also output after the foreign object is caught
in some part of the system in the engine oil and the system re-
turns to normal in a short time. As ECM controls so that foreign
objects are ejected, there is no problem about VVT. There is
also no problem since the oil filter should get the foreign object
in the engine oil.
NG
Replace ECM.
Page 727 of 1943

A14056
V1
Vacuum SensorECM
3
BR 2
1V±W Y±R
E9
E82
14
18VC
HCLS
E2 E8 Y±RJ/C
C
J8 B
J9
V±W9
I01
± DIAGNOSTICSENGINE
DI±127
2001 PRIUS (RM778U)
DTC P1430 Vacuum Sensor for HC Adsorber and Cata-
lyst System Circuit Malfunction
CIRCUIT DESCRIPTION
DTC No.DTC Detecting ConditionTrouble Area
P1430Open or short in vacuum sensor circuit
Open or short in vacuum sensor circuit
Vacuum sensor for HC adsorber and catalyst system
ECM
HINT:
After confirming DTC P1430, use the hand±held tester to confirm the manifold absolute pressure from the
CURRENT DATA.
Manifold Absolute Pressure (kPa)Malfunction
Approx. 0HCLS circuit short
130 or more
VC circuit open or short
HCLS circuit open
E2 circuit open
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
If DTCs P1430,P1431, P0110, P0115, P0120 and P0121 are output simultaneously, E2 (sensor
ground) may be open.
Read freeze frame data using hand±held tester. Because freeze frame records the engine conditions
when the malfunction is detected. When troubleshooting it is useful for determining whether the vehicle
was running or stopped, the engine was warmed up or not, the air±fuel ratio was lean or rich, etc. at
the time of the malfunction.
DI7SY±01
Page 728 of 1943
A13624
E2 VC ON
(+)
(±)
DI±128
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
When using hand±held tester:
1 Connect hand±held tester, and read value.
PREPARATION:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON and push the hand±held tester main switch ON.
CHECK:
Read the value of the manifold absolute pressure on the hand±held tester.
OK:
Same as atmospheric pressure.
OK Check for intermittent problems
(See page DI±3).
NG
2 Check voltage between terminals VC and E2 of engine ECU Connector.
PREPARATION:
(a) Remove the ECM with connector still connected (See
page SF±62).
(b) Turn the ignition switch ON.
CHECK:
Measure the voltage between terminals VC and E2 of the en-
gine ECU connector.
OK:
Voltage: 4.5 ± 5.5 V
NG Check and replace engine ECU
(See page IN±41).
OK
