2001 TOYOTA PRIUS Service Repair Manual

F00042
1 34
6 Open
(+)(±)1 2 3
4
4 5 6
1 2
3
2 5 6
5 Continuity
ContinuityContinuity
Open
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM WITH EBD & RBS
DI±383
2001 PRIUS (RM778U)
3 Check ABS solenoid relay.
CHECK:
Check continuity between each terminal of ABS solenoid relay.
OK:
Terminals 4 and 6Continuity
(Reference value 80 W)
Terminals 2 and 3Continuity
Terminals 1 and 3Open
CHECK:
(a) Apply battery positive voltage between terminals 4 and 6.
(b) Check continuity between each terminal of ABS solenoid
relay.
OK:
Terminals 2 and 3Open
Terminals 1 and 3Continuity
NG Replace ABS solenoid relay.
OK

F12443
ABS Solenoid
RelayEngine Room R/B
No. 3
Brake
Actuator
Brake ECU
ASTBS3
ASTAST
DI±384
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM WITH EBD & RBS
2001 PRIUS (RM778U)
4 Check continuity between terminals 3 of engine room R/B No. 3 (for ABS sole-
noid relay) and terminal AST of brake ECU.
CHECK:
Check continuity between terminal 3 of engine room R/B No. 3
(for ABS solenoid relay) and terminal AST of brake ECU.
OK:
Continuity
HINT:
There is a resistance of approx. 33 W between terminals BS and
AST of the brake actuator.
NG Repair or replace harness or brake actuator.
OK
5 Check for open and short circuit in harness and connector between ABS sole-
noid relay and brake ECU (See page IN±41).
NG Repair or replace harness or connector.
OK
If the same code is still output after the DTC is deleted, check the contact condition of each con-
nection. If the connections are normal, the ECU may be defective.

F12673
B±G
F111
L4 Instrument
Panel J/B
DC/DC FL Block No. 1
3
Brake
Combination Meter
W±B
Brake Fluid
Level Warning
Switch7Brake ECU
LBL
C11
J7
J/C AM1162K
IE 2A
ID22B11
WR±Y
MAINLG±R
12
14
A W±G B±Y
IG1
RelayBRL
B12
C11
C10
C105 Body ECU
B8 B8
15
BR2
2 W±B
A A
J1
J/C AW±BInstrument
Panel J/B
Battery FL
Block
No. 21
F13
Ignition Switch
24
2H 2B 2D
2K2A 5 1
3 6
5 1
3
27
8GAUGE
LMultiplex Communication Circuit
IH 2B 6 1
J11
J/CGR±B GR
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM WITH EBD & RBS
DI±385
2001 PRIUS (RM778U)
DTC C1202/58 Brake Fluid Warning Switch Circuit
CIRCUIT DESCRIPTION
The brake fluid level warning switch sends the appropriate signal to the ECU when the brake fluid level drops.
HINT:
Depressing the parking brake pedal also turns on the brake warning light but does not diagnose DTC No.
C1202/58.
DTC No.DTC Detecting ConditionTrouble Area
C1202/58
When any of the following 1. 2. or 3. is detected:
1. When the ignition switch is ON, an open condition in the
reservoir level switch circuit continues for 2 sec. or
more.
2. While a vehicle is driven at a speed of 3 km/h (5 mph) or
more, decrease in the reservoir level continues for 10
sec. or more.
3. While a vehicle is stopped, decrease in the reservoir
level continues for 5 sec. or more.

Brake fluid level

Brake fluid level warning switch

Brake fluid level warning switch circuit
WIRING DIAGRAM
DI1GZ±10

DI±386
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM WITH EBD & RBS
2001 PRIUS (RM778U)
INSPECTION PROCEDURE
1 Check brake fluid level.
CHECK:
Check the amount of fluid in the brake reservoir.
NG Check and repair brake fluid leakage and add
fluid.
OK
2 Check brake fluid level warning switch (See page BE±2).
NG Replace brake fluid level warning switch.
OK
3 Check for open circuit in all the harness and components connected to brake
fluid level warning light (See page IN±41).
NG Repair or replace harness or connector.
OK
Check and replace brake ECU.
