Page 313 of 1943
ENGINE ± 1NZ-FXE ENGINE
TDC
EX IN
To
advance
side
BDC
EX IN
To
retard side
Latest timing
EX IN
EX INLatest timing 72
Operation State
RangeValve TimingObjectiveEffect
In Low to
Medium
Speed Range
with Heavy
Load
4
182EG29
Advancing the intake
valve close timing for
volumetric efficiency
improvement
Improved
torque in
low to
medium
speed
range
In High Speed
Range with
Heavy Load
5
182EG30
Retarding the intake
valve close timing for
volumetric efficiency
improvement
Improved
output
At Low
TemperaturesÐ
182EG26
Eliminating overlap to
prevent blow back to the
intake side for reduction
of fuel increase at low
temperatures, and
stabilizing the idling rpm
for decreasing fast idle
rotation
Stabilized
fast idle
rpm Better
fuel
economy
Upon
Starting /
Stopping the
Engine
Ð
182EG26
Eliminating overlap to
eliminate blow back to
the intake sideImproved
startability
Page 314 of 1943
ENGINE ± 1NZ-FXE ENGINE
182EG39
Front Airbag
Sensors
(RH and LH)Airbag
Sensor
AssemblyHV
ECUCircuit
Opening
Relay
Fuel Pump
Motor ECM73
7. Fuel Pump Control
A fuel cut control is adopted to stop the fuel pump when the SRS airbag is deployed, thus helping reduce fuel
leakage.
In this system, the airbag deployment signal from the airbag sensor assembly is detected by the HV ECU,
send the signal to ECM, which turns OFF the circuit opening relay.
After the fuel cut control has been activated, turning the ignition switch from OFF to ON cancels the fuel cut
control, thus engine can be restarted.
Page 315 of 1943

ENGINE ± 1NZ-FXE ENGINE
182EG31
Accelerator Pedal
Position SensorThrottle Valve
Throttle Position Sensor
Throttle Control
Motor
HV
ECUECM
182EG33 182EG32
Accelerator Pedal
Position Sensor(V)
5.0
4.0
3.0
2.0
1.0
0 10 2030 405060 70 80
125Output Voltage
Accelerator Pedal Depressed AngleVPA2
VPA1 74
8. ETCS-i (Electronic Throttle Control System-intelligent)
General
The ETCS-i, which realizes excellent throttle control in all the operating ranges, has been adopted.
In the conventional throttle body, the throttle valve opening is determined invariably by the amount of
the accelerator pedal effort. In contrast, the ETCS-i used the ECM to calculate the optimal throttle valve
opening that is appropriate for the respective driving condition and uses a throttle control motor to control
the opening.
The ETCS-i controls the ISC (Idle Speed Control) system and the cruise control system.
System Diagram
Construction
1) Accelerator Pedal Position Sensor
The accelerator pedal position sensor is mounted on the accelerator pedal. To detect the pedal opening
angle, 2 separate systems consisting of main and sub sensors are used, and 2 separate return springs are
used to improve reliability. In the detecting portions, Hall elements have been adopted. Due to the charac-
teristics of the Hall elements, different signals are output depending on whether the pedal is pressed all
the way or is released. To correct these signals, a mechanical device has been provided to detect the cor-
rect pedal opening angle. The sensors of the 2 systems output the same signals.
Page 316 of 1943

ENGINE ± 1NZ-FXE ENGINE
150EG39150EG40
Close
Open
VC VTA1 VTA2 E2V
5
0 Close
Output Voltage
Open VTA1 VTA2
Accelerator Pedal Depressed Angle75
2) Throttle Position Sensor
The throttle position sensor is mounted on the throttle body.
The throttle position sensor converts the amount of accelerator pedal effort into two types of electrical
signals with distinct output characteristics. The signals are then input into the ECM.
3) Throttle Control Motor
A DC motor with excellent response and minimal power consumption is used for the throttle control mo-
tor. The ECM performs the duty ratio control of the direction and the amperage of the current that flows
to the throttle control motor in order to regulate the opening angle of the throttle valve.
Operation
The ECM drives the throttle control motor by determining the target throttle valve opening in accordance
with the respective operating condition.
1) Idle Speed Control
The idle speed control is effected entirely by the ETCS-i. The following are the contents of the control:
idle-up control during cold engine operation, intake air volume control to improve the startability of the
engine, and control for when the electrical load changes such as when the air conditioning switch is turned
ON or OFF.
2) Cruise Control
Through the adoption of the ETCS-i, the vehicle speed is now controlled by the throttle control motor,
which controls the throttle valve.
Page 317 of 1943
ENGINE ± 1NZ-FXE ENGINE 76
Fail Safe
If an abnormal condition occurs with the ETCS-i, the check engine warning light in the combination meter
illuminates to alert the driver. The current to the throttle control motor is cut off to prevent the ETCS-i from
operating. This enables the return spring to close the throttle valve.
Diagnosis
If the diagnostic trouble code 89 is being output to the combination meter check engine warning light, it
means that the ECM has detected a malfunction in the ETCS-i, and outputs the diagnostic trouble code of
the ETCS-i.
Also, the diagnostic trouble code can be output to a hand-held tester via the data link connector 3.
For details, refer to the 2001 Prius Repair Manual (Pub. No.RM778U).
Page 318 of 1943

ENGINE ± 1NZ-FXE ENGINE
182EG34
Air CleanerIntake Air Chamber
VSV
(for EVAP)
ECM
Fresh Air Line
Purge Line
EVAP Line
VSV
(for Purge Flow Switching Valve)
Charcoal Canister
Recircle Line
Vapor Pressure
Sensor
VSV (for Canister Closed Valve)77
9. Evaporative Emission Control
General
A vacuum system has been newly adopted to detect leaks in the evaporative emission control system. This
vacuum system detects leaks by forcefully introducing the purge vacuum into the entire system and moni-
toring the changes in the pressure.
In order to detect evaporative emission leaks from the vapor reducing fuel tank, a density method has been
adopted. This system uses an oxygen sensor to measure the HC density in the exhaust gases in order to detect
leaks.
It consists of the following main conponents:
A VSV (for canister closed valve) has been provided between the fresh air line and the fuel tank.
The VSV (for purge flow switching valve) switches the passages from the charcoal canister to the purge
line and from the fuel tank to the purge line.
A vapor pressure sensor has been provided in the fuel tank in order to further ensure the precision of the
vapor pressure sensor.
DTCs (Diagnostic Trouble Codes) have been added. For details on the DTCs (Diagnostic Trouble
Codes), refer to the 2001 Prius Repair Manual (Pub. No.RM778U).
Page 319 of 1943

ENGINE ± 1NZ-FXE ENGINE 78
Operation
Initially, the VSV (for canister closed valve) is closed, and the VSV (for EVAP) is open, enabling the VSV
(for purge flow switching valve) to keep the passage between the charcoal canister and the purge line open.
This causes a vacuum to be applied to the purge line, evaporator line, recirculation line, and the line from
the charcoal canister to the fuel tank.
Next, the VSV (for EVAP) is closed in order to maintain a vacuum from the VSV (for EVAP) to the inside
of the fuel tank. Then, any subsequent changes in the pressure are monitored by the vapor pressure sensor
in order to check for evaporative emission leaks.
Next, the VSV (for canister closed valve) and the VSV (for EVAP) open, enabling the VSV (for purge flow
switching valve) to keep the passage between the fuel tank and the purge line open. Then, the air in the fuel
tank is drawn in by the vacuum of the intake chamber, and the density of HC in the exhaust gases is measured
by the oxygen sensor to detect any leaks.
If a leak is detected, the malfunction indicator lamp (MIL) illuminates to inform the driver. Also, the diag-
nostic trouble code (DTC) can be accessed through the use of a hand-held tester.
For details on the DTCs, refer to the 2001 Prius Repair Manual (Pub. No.RM778U).
10. HV Immobiliser System
The HV immobiliser system has been designed to prevent the vehicle from being stolen. This system uses
a HV ECU that stores the ID code of the authorized ignition key. If an attempt is made to start the HV system
using an unauthorized key, the HV ECU prohibit fuel delivery, ignition, and starting the HD system effective-
ly disabling the engine.
For details see page 184 in the HV Immobiliser System section.
11. Diagnosis System
The diagnostic trouble codes can be output via DLC3 to an OBD-II scan tool or a hand-held tester. For details,
refer to the 2001 Prius Repair Manual (Pub. No.RM778U).
Page 320 of 1943

THS (TOYOTA HYBRID SYSTEM)
THS (TOYOTA HYBRID SYSTEM)
182TH03
Planetary Gear UnitMG1
InverterHV
Battery
MG2
Differential
Gear Unit
Engine
Hybrid Transaxle
Mechanical Power Path
Electrical Path
182TH01
Battery
*
1
Inverter
*
2Engine
Generator Electric Motor
*
1: Direct Current
*2: Alternating Current
182TH02
Battery
Inverter
Engine
Motor / Generator Transmission 22
DESCRIPTION
The hybrid system is a type of powertrain that uses a combination of two types of motive forces, such as an
engine and a motor (MG2). This system is characterized by its skillful use of two types of motive forces ac-
cording to the driving conditions. It maximizes the strengths of each of the motive forces and complements
their weaknesses. Thus, it can achieve a highly responsive, dynamic performance, as well as a dramatic re-
duction in fuel consumption and exhaust gas emissions. The THS can be broadly divided into two systems:
the series hybrid system, and the parallel hybrid system.
± REFERENCE ±
Series Hybrid System
In the series hybrid system, the engine runs a genera-
tor, and the generated electricity enables the electric
motor to drive the wheels. This type of vehicle can be
described as an electric car that is equipped with an
engine-driven generator.
Equipped with a low-output engine, the engine is op-
erated at a practically constant speed in its most ef-
fective range, in order to efficiently recharge the bat-
tery while the vehicle is in motion.
Parallel Hybrid System
This system uses both the engine and the electric mo-
tor to directly drive the wheels is called the parallel
hybrid system. In addition to supplementing the mo-
tive force of the engine, the electric motor in this sys-
tem can also serve as a generator to recharge the bat-
tery while the vehicle is in motion.
