Perform any of the following and the system will go to Disarmed state (B):

Remove the key from the ignition, close the driver's door, then the ignition OFF.
Disarmed state (A)
Perform any of the following and the system
will return to Disarmed state (A):

Push the unlock switch on the wireless
remote.

Put the key in the lock on the driver's or the
passenger door and turn it towards unlock.

Put the key in the ignition.

Reconnect the battery.

Turn the ignition from OFF to ON.Disarmed state (B)Perform any of the following and the system
will go to Arming preparation:

Close all the doors, hood and
luggage compartment door.
Perform any of the following
and the system
will return to Disarmed state
(B):

Open any of the doors, the
hood or the
luggage compartment door.
Arming preparation
Perform any of the following
and the system
will go to Armed state:

Allow 30 seconds to elapse
with all the doors,
hood and luggage compart-
ment door closed.
Perform any of the following and
the system
will return to Disarmed state (A):

Push the unlock switch on the
wireless
remote.

Put the key in the lock on the
driver's or the
passenger door and turn it to-
wards unlock.

Put the key in the ignition.

Reconnect the battery.

Turn the ignition from OFF to
ON.
BE±70
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
2001 PRIUS (RM778U)
3. PASSIVE ARMING MODE
This mode can be switched according to the specified op-
eration.
All initially set modes (when shipped from factory) are ac-
tive mode. (No passive mode)

Perform any of the following
and the system will return to
Armed state:

The alarm sounding
period passes.
Alarm sounding
Perform any of the following
and the system will return to
Disarmed state (A):

Push the unlock switch on
the wireless remote.

Put the key in the lock on
the driver's or the passenger
door and turn it towards
unlock.

Put the key in the ignition
and turn it ON.Perform any of the following
and the system will return to
Disarmed state (B):

Open the luggage
compartment door with the
wireless remote.

Open the luggage
compartment door with the
Key.
Perform any of the following
and the system will return to
Disarmed state (A):

Push the unlock switch on
the wireless remote.

Put the key in the lock on
the driver's or the
passenger door and turn
it towards unlock.

Put the key in the
ignition and turn it ON.
Armed state
Perform any of the following
and the system will go on to
Alarm sounding:

Open any of the doors and
allow the entry delay time
to pass.

Open the hood.

Open the luggage
compartment door with
something other than the
key or wireless remote.

Reconnect the battery.

Ignition switch is connected
directly.Perform any of the following
and the system will return to
Disarmed state (B):

Open the luggage
compartment door with the
wireless remote.

Open the luggage
compartment door with the
Key.
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
BE±71
2001 PRIUS (RM778U)

Door
Indicator
Alarming output
System condition
Armed state Alarm
sounding Entry delay time Close
Open
ON
OFF
ON
OFF BE±72
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
2001 PRIUS (RM778U)
HINT:
In armed state either closed door is opened, entry delay occurs.
(15 secs.)
During this time, the mode transfers to disarmed state when the
condition described above * is met.
When the condition is not met, the system judges theft occurs,
the mode transfers to alarm sounding.

± BODY ELECTRICALTHEFT DETERRENT SYSTEM
BE±73
2001 PRIUS (RM778U)
Indicator light output:
ConditionIndicator light
Disarmed stateOFF
Arming preparationON
Armed state
(Entry delay time)OFF
(ON)
Alarm soundingON
HINT:
Even in disarmed state, the indicator light flash. (Due to the sig-
nal output form immobilizer system). The indicator always
flashes receiving the signal from the immobilizer system at any
time in the arming condition.
Flashing frequency:
0.2 seconds (ON)
1.8 seconds (OFF)
(a) Transfer to active mode:
In each passive mode, when ºdisarmed state of active
mode " arming preparation transfer conditionº is met, the
active mode transfers to each condition. In this case, ac-
tive mode continues till disarmed state.
Passive mode when transfer condition is
met.Active mode transfer condition
Disarmed stateArming preparation condition
Arming preparation conditionArming preparation condition
Armed state
(During entry delay time)Arming condition
(After alarming time has elapsed, arming
condition)
Alarm soundingAfter alarming time has elapsed, arming
condition
(b) Answer back:
The hazard lights flush as answer back under the follow-
ing conditions.
(1) When the system is set.
When arming preparation is set from disarmed state
using the wireless door lock, the hazard lights flush
once.
(2) When the system is released.
When disarmed state is set from either arming prep-
aration, armed state or alarm sounding using the
wireless door lock, the hazard lights flush twice.
