2001 TOYOTA PRIUS Service Repair Manual

BE±4
± BODY ELECTRICALTROUBLESHOOTING
1671 Author: Date:
2001 PRIUS (RM778U) Headlight flickers.
1. Bulb
2. Wire Harness±
±
Headlight is dark.1. Bulb
2. Wire Harness±
±
Taillight does not come on with light control switch in TAIL.1. Taillight Control Relay
2. Wire HarnessBE±20
±
Taillight does not go out with light control switch in OFF.1. Taillight Control Relay
2. Wire HarnessBE±20
±
Headlight does not come on with engine running and light control
switch in OFF.
1. ECU±B Fuse
2. GAUGE Fuse
3. Daytime Running Light Main Relay
4. Daytime Running Light Relay
5. Alternator L Terminal
6. Body ECU
7. Parking Brake Switch
8. Wire HarnessBE±12
BE±12
BE±20
BE±20
±
DI±678
BE±42
±
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. GAUGE Fuse
2. TURN HAZ Fuse
3. Ignition Switch
4. Turn Signal Flasher Relay
5. Wire HarnessBE±12
BE±12
BE±17
BE±25
±
Hazard warning light does not light up.
(Turn is normal)1. Hazard Warning Switch
2. Wire HarnessBE±25
±
Turn signal does not light up.
(Hazard is normal)1. Turn Signal Switch
2. Wire HarnessBE±25
±
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE±25
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±
INTERIOR LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the lights do not come ON.DOME FuseBE±12
The driver door courtesy light does not come ON when the
driver's door is opened.1. Driver's Door Courtesy Switch
2. Wire Harness
3. Body ECUBE±27
±
±
The passenger door courtesy light does not come ON when the
passenger's door is opened.1. Passenger's Door Courtesy Switch
2. Wire Harness
3. Body ECUBE±27
±
DI±678
The room light does not come on when the rear±right door is
opened.
1. Rear±Right Door Courtesy Switch
2. Wire Harness
3. Body ECU
4. Room LightBE±27
±
DI±678
±
The room light does not come on when the rear±left door is
opened.
1. Rear±Left Door Courtesy Switch
2. Wire Harness
3. Body ECU
4. Room LightBE±27
±
DI±678
±
Only one of the bulbs comes ON.Bulb±

± BODY ELECTRICALTROUBLESHOOTING
BE±5
1672 Author: Date:
2001 PRIUS (RM778U) The illumination does not fade out when all the doors are closed.
1. Courtesy Switch
2. Wire Harness
3. Body ECUBE±27
±
DI±678
The illumination does not fade out immediately when the ignition
switch is turned to ACC or ON within 15 seconds after all the
doors are closed.
1. Ignition Switch
2. ECU±B Fuse
3. GAUGE Fuse
4. Wire Harness
5. Body ECUBE±17
BE±12
BE±12
±
DI±678
The illumination does not fade out immediately when all the doors
are locked within 15 seconds after they are closed.1. Door Unlock Detection Switch
2. Wire Harness
3. Body ECUBE±62
±
DI±678
Interior light does not light up.
(in front personal light)1. Bulb
2. Personal Light
3. Wire Harness±
BE±27
±
Front personal light does not light up.
1. Bulb
2. Personal Light
3. Wire Harness±
BE±27
±
Rear personal light does not light up.
1. Bulb
2. Interior Light
3. Wire Harness±
BE±27
±
Luggage compartment light does not light up.
1. Bulb
2. Luggage Compartment Door Courtesy Switch
3. Wire Harness±
BE±27
±
Courtesy light does not light up.
1. Bulb
2. Door Courtesy Switch
3. Wire Harness
4. Body ECU±
BE±27
±
DI±678
BACK±UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back±Up Light does not light up.
1. GAUGE Fuse
2. Ignition Switch
3. Back±up Light Relay
4. Wire Harness
5. BulbBE±12
BE±17
BE±30
±
±
Back±Up Light remains always on.1. Bulb
2. Wire Harness±
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not light up.
1. STOP Fuse
2. Stop Light Switch
3. Wire HarnessBE±12
BE±32
±
Stop light always lights up.1. Stop Light Switch
2. Wire HarnessBE±32
±
Only one light always lights up.Wire Harness±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
