2001 TOYOTA PRIUS Service Repair Manual

PP16D±04
± PREPARATIONBRAKE
PP±39
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.
09905±00013Snap Ring Pliers .Master cylinder

PP16E±04
PP±40
± PREPARATIONBRAKE
2001 PRIUS (RM778U)
EQUIPMENT
Torque wrench
MicrometerBrake disc
Dial indicatorBrake disc
Vernier calipersBrake disc
Brake drum gauge
Effort gauge

PP16F±02
± PREPARATIONBRAKE
PP±41
2001 PRIUS (RM778U)
LUBRICANT
ItemCapacityClassification
Brake fluid±SAE J1703 or FMVSS No. 116 DOT 3

PP3BA±01
PP±42
± PREPARATIONSTEERING
103 Author: Date:
2001 PRIUS (RM778U)
STEERING
SST (Special Service Tools)
09608±06041Front Hub Inner Bearing Cone
ReplacerTilt steering column
09612±00012Rack & Pinion Steering Rack
Housing StandElectric motor power steering
09922±10010Variable Open WrenchElectric motor power steering
09950±50012Puller C SetTilt steering column
(09951±05010)Hanger 150
(09952±05010)Slide Arm
(09953±05020)Center Bolt 150
(09954±05020)Claw No.2

PP3BB±01
± PREPARATIONSTEERING
PP±43
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09042±00010Torx Socket T30 .Tilt steering column
09904±00010Expander Set .
(09904±00050)No. 4 Claw
09905±00012Snap Ring No.1 Expander .
09905±00013Snap Ring Pliers .

PP0J9±10
PP±44
± PREPARATIONSTEERING
2001 PRIUS (RM778U)
EQUIPMENT
Torque wrench

PP0SY±02
± PREPARATIONSUPPLEMENTAL RESTRAINT SYSTEM
PP±45
106 Author: Date:
2001 PRIUS (RM778U)
SUPPLEMENTAL RESTRAINT SYSTEM
SST (Special Service Tools)
09082±00700SRS Airbag Deployment Tool
09082±00750Airbag Deployment Wire
Sub±harness No.3for Side Airbag Assembly
09082±00760Airbag Deployment Wire
Sub±harness No.4for Driver's and Front Passenger
Airbag Assembly
09843±18040Diagnosis Check Wire No.2

PP2I6±01
PP±46
± PREPARATIONSUPPLEMENTAL RESTRAINT SYSTEM
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.
