PP3AM±01
± PREPARATIONHYBRID TRANSAXLE
PP±23
84 Author: Date:
2001 PRIUS (RM778U)
HYBRID TRANSAXLE
SST (Special Service Tools)
09308±00010Oil Seal Puller
09350±32014TOYOTA Automatic Transmission
Tool Set
(09351±32130)Handle
(09351±32150)Oil Seal Replacer
09388±40010Input Oil Seal Replacer
09527±10011Rear Axle Shaft Bearing Remover
09564±32011Differential Preload Adaptor
09608±06041Front Hub Inner Bearing Cone
Replacer
09612±30012Steering Worm Bearing Puller
09710±20011Front Suspension Bushing Tool
Set
(09710±06071)Replacer
09710±22021Front Suspension Bushing Tool
Set

PP±24
± PREPARATIONHYBRID TRANSAXLE
85 Author: Date:
2001 PRIUS (RM778U)
(09710±01031)Upper Arm Bushing Replacer
09950±00020Bearing Remover
09950±40011Puller B Set
(09951±04010)Hanger 150
(09952±04010)Slide Arm
(09953±04020)Center Bolt 150
(09954±04010)Arm 25
(09955±04061)Claw No.6
(09958±04011)Holder
09950±60010Replacer Set
(09951±00230)Replacer 23
(09951±00330)Replacer 33
(09951±00370)Replacer 37

± PREPARATIONHYBRID TRANSAXLE
PP±25
86 Author: Date:
2001 PRIUS (RM778U)
(09951±00460)Replacer 46
09950±60020Replacer Set No.2
(09951±00680)Replacer 68
09950±70010Handle Set
(09951±07100)Handle 100
09992±00095Automatic Transmission Oil
Pressure Gauge Set
(09992±00112)Adaptor A
(09992±00271)Gauge Assy

PP3AN±01
PP±26
± PREPARATIONHYBRID TRANSAXLE
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09025±00010Torque Wrench (30 kgf±cm)
09031±00030Pin Punch .
09040±00011Hexagon Wrench Set .
09082±00040TOYOTA Electrical Tester.
09090±04020Engine Sling Device

PP3AO±01
± PREPARATIONHYBRID TRANSAXLE
PP±27
2001 PRIUS (RM778U)
EQUIPMENT
Dial indicator
Pin punch
Straight edge
Torque wrench

PP3AP±01
PP±28
± PREPARATIONHYBRID TRANSAXLE
2001 PRIUS (RM778U)
LUBRICANT
ItemCapacityClassification
Hybrid transaxle oil4.6 liters (4.9 US qts, 4.0 lmp. qts)ATF Type T±IV

PP3AQ±01
± PREPARATIONHYBRID TRANSAXLE
PP±29
2001 PRIUS (RM778U)
SSM (Special Service Materials)
08826±00080Seal Packing Black or equivalent
(FIPG)
08826±00090Seal Packing 1281,
THREE BOND 1281 or equivalent
(FIPG)
08833±00070Adhesive 1324,
THREE BOND 1324 or equivalent
08833±00080Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalent

PP3A9±01
PP±30
± PREPARATIONSUSPENSION AND AXLE
91 Author: Date:
2001 PRIUS (RM778U)
SUSPENSION AND AXLE
SST (Special Service Tools)
09214±76011Crankshaft Pulley ReplacerRear axle
09240±00020Wire Gauge SetFront drive shaft
09520±00031Rear Axle Shaft Puller
(09520±00040)ShockerFront axle
Rear axle
(09521±00010)AttachmentFront axle
(09521±00020)Rod with GripFront axle
Rear axle
09520±01010Drive Shaft Remover AttachmentFront drive shaft
09520±24010Differential Side Gear Shaft
PullerFront drive shaft
(09520±32040)Shocker Set
09521±24010Drive Shaft Boot Clamping ToolFront drive shaft
09527±17011Rear Axle Shaft Bearing RemoverFront axle
09608±16042Front Hub Bearing Adjusting ToolFront drive shaft
