± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2001 PRIUS (RM778U)
(2) Using 3 wire harness, wind the wire harness at least
2 times each around the bolts installed on the left
and right sides of the steering wheel pad.
CAUTION:

Tightly wind the wire harness around the bolts so that
there is no slack.

If there is slackness in the wire harness, the steering
wheel pad may come loose due to the shock when the
airbag is deployed. This is highly dangerous.
(3) Face the upper surface of the steering wheel pad
upward. Separately tie the left and right sides of the
steering wheel pad to the disc wheel through the
hub nut holes. Position the steering wheel pad con-
nector so that it hangs downward through a hub
hole in the disc wheel.
CAUTION:

Make sure that the wire harness is tight. It is very dan-
gerous when looseness in the wire harness results in
the steering wheel pad coming free due to the shock
from the airbag deploying.

Always tie down the steering wheel pad with the pad
side facing upward. It is very dangerous if the steer-
ing wheel pad is tied down with the metal surface fac-
ing upward as the wire harness will be cut by the
shock from the airbag deploying and the steering
wheel pad will be thrown into the air.
NOTICE:
The disc wheel will be marked by airbag deployment, so
when disposing of the airbag use a redundant disc wheel.
(c) Check functioning of the SST (See step 1±(a)).
SST 09082±00700

H16246
SST
H03207
10 m (33 ft) or more
H03205Weight
X Y
Y
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±21
2001 PRIUS (RM778U)
(d) Install the SST.
CAUTION:
Place the disc wheel on the level ground.
(1) Connect the connectors of the 2 SST to the steering
wheel pad connector.
SST 09082±00700, 09082±00760
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the disc
wheel.
(2) Move the SST to at least 10 m (33 ft) away from the
steering wheel pad tied down on the disc wheel.
(e) Cover the steering wheel pad with a cardboard box or
tires.

Covering method using a cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
X = 460 mm (18.11 in.)
Y = 650 mm (25.59 in.)
NOTICE:

When dimension Y of the cardboard box exceeds the
diameter of the disc wheel with tire to which the steer-
ing wheel pad is tied, X should be the following size.
X = 460 mm (18.11 in.) + width of tire

If a cardboard box smaller than the specified size is
used, the cardboard box will be broken by the shock
from the airbag deployment.

H03206
Inner Diam.
Tires
(3 or More)Width
H03207
10 m (33 ft) or more
H03208
RS±22
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2001 PRIUS (RM778U)

Covering method using tires:
Place at least 3 tires without disc wheel on top of the
disc wheel with tire to which the steering wheel pad
is tied.
Tire size: Must exceed the following dimensions±
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(f) Deploy the airbag.
(1) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(±) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
(g) Dispose of the steering wheel pad (with airbag).
CAUTION:

The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.

Use gloves and safety glasses when handling a steer-
ing wheel pad with the deployed airbag.

Always wash your hands with water after completing
the operation.

Do not apply water, etc. to a steering wheel pad with
the deployed airbag.
(1) Remove the steering wheel pad from the disc
wheel.
(2) Place the steering wheel pad in a vinyl bag, tie the
end tightly and dispose of it in the same way as oth-
er general parts disposal.

H03208
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±23
2001 PRIUS (RM778U)
3. DEPLOYMENT WHEN DISPOSING OF STEERING
WHEEL PAD WITH AIRBAG DEPLOYED IN COLLI-
SION
Dispose of the steering wheel pad (with airbag).
CAUTION:

The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.

When moving a vehicle for scrapping which has a
steering wheel pad with the deployed airbag, use
gloves and safety glasses.

Use gloves and safety glasses when handling a steer-
ing wheel pad with deployed airbag.

Always wash your hands with water after completing
the operation.

Do not apply water, etc. to a steering wheel pad with
deployed airbag.
(1) Remove the steering wheel pad from the steering
wheel (See page SR±6).
(2) Place the steering wheel pad in a vinyl bag, tie the
end tightly and dispose of it in the same way as oth-
er general parts disposal.
