ENGINE ± 1NZ-FXE ENGINE
ECM
EFI MAIN RELAY BATTERY+B BATT, BM
HTE
ETH
SPHV
ESTP
GO HV ECU
(Hybrid Vehicle Control ECU)
VACUUM SENSOR
(for TOYOTA HCAC SYSTEM)ACCELERATOR PEDAL
POSITION SENSORHCLS
VAPOR PRESSURE SENSORPTNK VPA 1, 2
DATA LINK CONNECTOR 3SIL
TC
AIR CONDITIONING ECU AIR CONDITIONING CUT-
OFF CONTROL
ACT
COOLING FAN RELAYCOOLING FAN
CONTROLFA N
VSV (for EVAP) EVAP CONTROLEVP1
VSV (for CANISTER
CLOSED VALVE) CCV
VSV (for PURGE FLOW
SWITCHING VALVE)TBP
METER ECU
AIR CONDITIONING ECU
DISPLAY ECU
BODY ECU
VSV
(for TOYOTA HCAC SYSTEM)
EFI MAIN RELAY
MALFUNCTION INDICATOR
LAMP MPX1
NEO
MPX2
HCC
MREL
W
64
Page 306 of 1943
ENGINE ± 1NZ-FXE ENGINE
182EG22
Circuit
Opening
Relay
VSV
(for
EVAP)
Intake
Air Temp.
SensorThrottle
Position
Sensor
ECMHV
ECU
Accelera-
tor Pedal
Position
Sensor
Cooling
Fan Relay
Throttle
Control
Motor
Igniter
Camshaft Position Sensor
Knock
Sensor
Mass Air
Flow Meter
VSV
(for Toyota
HCAC
System)Vacuum
Sensor
(for Toyota
HCAC
System)
Crankshaft
Position Sensor Injector
Camshaft
Timing
Oil Con-
trol Valve
Engine
Coolant
Te m p .
Sensor
TWC
Heated Oxygen
Sensor (Bank 1,
Sensor 1)
Heated Oxygen
Sensor (Bank 1,
Sensor 2)
Actuator (for HC
Adsorber)
TWC (with HC
Adsorber)
VSV (for Purge Flow
Switching Valve)
Vapor Pressure Sensor
VSV (for Canister Closed Valve)
Charcoal
Canister
Fuel Pump65
3. Engine Control System Diagram
Page 307 of 1943
ENGINE ± 1NZ-FXE ENGINE
182EG23
VSV (for TOYOTA
HCAC System)VSV (for EVAP)Oil Control Valve
ECMIgnition Coil
with IgniterVSV (for Purge Flow Switching Valve)
Charcoal Canister
Vapor
Pressure
Sensor
Trap Filter
VSV (for Canister
Closed Valve) DLC 3
Heated Oxygen Sensor
(Bank 1, Sensor 2)
Heated Oxygen Sensor
(Bank 1, Sensor 1) Engien Coolant
Temp. Sensor Camshaft
Position
Sensor
Injector Crankshaft
Position
Sensor Knock
Sensor Throttle
Control
Motor Mass Air
Flow Meter 66
4. Layout of Components
Page 308 of 1943

ENGINE ± 1NZ-FXE ENGINE
182EG24
VVT-i Controller
ECM
Camshaft Position
Sensor
Camshaft Timing
Oil Control Valve Crankshaft
Position
Sensor67
5. Main Components of Engine Control System
The main components of the 1NZ-FXE engine control system are as follows:
Components
OutlineQuantity
Mass Air Flow MeterHot-Wire Type1
Crankshaft Position Sensor (Rotor's Teeth)Pick-Up Coil Type (36-2)1
Camshaft Position Sensor (Rotor's Teeth)Pick-Up Coil Type (3)1
Throttle Position SensorLinear Type (Double)1
Knock SensorBuilt-In Piezoelectric Element Type1
Oxygen Sensor
Heated Oxygen Sensor
(Bank 1, Sensor 1)
(Bank 1, Sensor 2)
2
Injector12-Hole Type4
6. VVT-i (Variable Valve Timing-intelligent) System
General
The VVT-i system is designed to control the intake camshaft within a wide range of 43 (of crankshaft
angle) to provide a valve timing that is optimally suited to the engine condition, thus realizing improved
torque in all the speed ranges and fuel economy, and reduce exhaust emissions.
Page 309 of 1943
ENGINE ± 1NZ-FXE ENGINE
182EG40
Vane (Fixed on Intake Camshaft)
Intake
Camshaft
Housing
165EG34
To VVT-i Controller
(Advanced Side) (Retard Side)
SleeveSpool Valve
Spring
Drain
Oil
PressureDrain
CoilPlunger 68
Construction
1) VVT-i Controller
This controller consists of the housing driven from the timing chain and the vane coupled with the intake
camshaft.
The oil pressure sent from the advance or retard side path at the intake camshaft causes rotation in the
VVT-i controller vane circumferential direction to vary the intake valve timing continuously.
2) Camshaft Timing Oil Control Valve
The camshaft timing oil control valve controls
the spool valve position in accordance with
the duty control from the ECM thus allocating
the hydraulic pressure that is applied to the
VVT-i controller to the advance and the retard
side. When the engine is stopped, the cam-
shaft timing oil control valve is in the most re-
tarded state.
Page 310 of 1943
ENGINE ± 1NZ-FXE ENGINE
185EG18
VVT-i Controller Housing
Vane
Rotating DirectionECM
Oil Pressure
185EG19
Rotating Direction
Oil PressureECM69
Operation
The camshaft timing oil control valve selects the path to the VVT-i controller according to the advance, re-
tard or hold signal from the ECM. The VVT-i controller rotates the intake camshaft in the timing advance
or retard position or holds it according to the position where the oil pressure is applied.
1) Advance
When the camshaft timing oil control valve is positioned as illustrated below by the advance signal from
the ECM, the resultant oil pressure is applied to the timing advance side vane chamber to rotate the cam-
shaft in the timing advance direction.
2) Retard
When the camshaft timing oil control valve is positioned as illustrated below by the retard signal from
the ECM, the resultant oil pressure is applied to the timing retard side vane chamber to rotate the camshaft
in the timing retard direction.
Page 311 of 1943
ENGINE ± 1NZ-FXE ENGINE
185EG10
ECM
Oil Pressure 70
3) Hold
The ECM calculates the target timing angle according to the traveling state to perform control as de-
scribed in the previous page. After setting at the target timing, the valve timing is held by keeping the
camshaft timing oil control valve in the neutral position unless the traveling state changes.
This adjusts the valve timing at the desired target position and prevents the engine oil from running out
when it is unnecessary.
Page 312 of 1943

ENGINE ± 1NZ-FXE ENGINE
182EG25
Engine Load
Full Load Performance
Range 4Range 5
Range 3
Range 2
Range 1Engine Speed
TDC
EXIN
BDCLatest
timing
To retard
side
IN
EX
To advance
side
EX IN71
In proportion to the engine speed, intake air volume, throttle position and water temperature, the ECM cal-
culates an optimal valve timing under each driving condition and control the camshaft timing oil control
valve. In addition, ECM uses signal from the camshaft position sensor and the crankshaft position sensor
to detect the actual valve timing, thus performing feedback control to achieve the target valve timing.
Operation During Various Driving Condition (Conceptual Diagram)
Operation StateRangeValve TimingObjectiveEffect
During Idling1
182EG26
Eliminating overlap to
reduce blow back to the
intake sideStabilized
idling rpm
Better fuel
economy
At Light Load2
182EG27
Decreasing overlap to
eliminate blow back to
the intake sideEnsured
engine
stability
At Medium
load3
182EG28
Increasing overlap to
increase internal EGR for
pumping loss elimination
Better fuel
economy
Improved
emission
control
