Diagnostic mode operation confirmation:
Check the taillight lights up soon after the input opera-
tion of self diagnostic mode.
Ignition Switch OFF
0.2 sec. 0.5 sec.
OFF ON Taillight
Taillight light up should be maximum despite the con-
troller.Is the method to input the diagnostic mode
correct?
Is the function of operation confirmation
taillight normal?
Taillight faulty.
No
No
Ye s
Confirmation of diagnostic mode:
Check taillight light up when pressing on each switch of
transmitter.
(1) Received normal wave of LOCK switch.
NoYe s Ye s
No response
(2) Received normal wave of UNLOCK switch.
(3) Received normal wave of PANIC switch.
(4) Compatibility of the recognition code or out from
synchronization of rolling code.*.
OFF ON
OFF ON
OFF ON
OFF ON
0.2 sec. 0.5 sec.
0.2 sec.
0.2 sec.0.5 sec.
0.5 sec. 0.5 sec.
Transmitter faulty or wireless door lock re-
ceiver faulty.
Use another (normal) transmitter and
check with the diagnostic mode and in the
case that the check result shows the trans-
mitter faulty, it can be judged that wireless
door lock receiver is normal.
While receiving
In case of taillight
outputs of (4) In case of taillight
outputs from (1) ± (3)
Not enter in
diagnostic
mode
BE±80
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
Page 1818 of 1943

Transmitter faulty or wireless door lock receiver
faulty.
Check the wave reaching range with another
transmitter (normal). When the range is normal,
transmitter defection is detected, the range is
not normal, wireless door lock receiver defection
is defected.
The wave reaching range check:
Is the wave reaching range normal?
(1 M area around vehicle)
(While the transmitting switch is pressed,
(approx. 20 secs.) the taillight continuously.
After 20 secs., repress the switch again.)
NoOther body control system faulty.
(Transmitter and receiver are normal.)
Ye s
No
Wireless door control receiver check:
Ye sWire harness faulty (short circuit).
Ye s
RDA terminal open circuit.
No
Check RDA terminal circuit.
Check that the voltage of RDA is about 6 ± 7 V
(when the transmitter is ON).
No
When pressing each switch of
the new or normal transmitter
used in the same type vehicle,
check that all taillights chirps
in the same way.
Transmitter faulty.
Ye s
Check that continuity exists between the receiver
terminal 3 (PRG) and body ECU terminal B9
(PRG).
Check that continuity exists between the receiver
terminal 2 (RDA) and body ECU terminal B10
(RDA).
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±81
2001 PRIUS (RM778U)
Page 1819 of 1943
BE±82
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
DOME fuse or wire harness faulty.
Ye s
+B power source check:
Check that there is constantly 10 to 14 V voltage at the
connector terminal 5 (+B) of wireless door control
receiver.
No
Wire harness faulty.
Body ground open and contact error.
Ye s
Body ground check:
Check that continuity exists between the connector
terminal 1 (GND) of the wireless door control receiver
and body ground.
No
Wireless door control receiver faulty.
Page 1820 of 1943

BE0OJ±12
I12019
Dry cell battery (1.5 V x 2)
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±83
2001 PRIUS (RM778U)
INSPECTION
1. INSPECT WIRELESS DOOR LOCK TRANSMITTER
OPERATION
HINT:
Refer to ºWireless door lock control receiver and transmitter re-
placementº on page BE±87.
(a) Using a screwdriver, remove and cover.
(b) Remove the battery (lithium battery).
(c) Install a new or normal battery (lithium battery).
HINT:
When a new or normal battery can not be obtained, connect 2
new 1.5 V batteries in series, connect the battery (+) to the bat-
tery receptacle side terminal and battery (±) to the bottom termi-
nal, then apply 3 V voltage to the transmitter.
(d) In the location where is approx. 1 M away from driver's
outside handle in the right direction, and check the trans-
mitter operation when pressing transmission switch on
the surface of the transmitter body.
Standard:
Remote control of vehicle door lock can be operated.
HINT:
The minimum operation distance differs according to op-
erator, the way of holding, and location.
As weak wave is used, operation distance might be short-
ened when noise is detected in strong wave or used fre-
quency.
(e) Install the battery (lithium battery).
(f) Install a cover so that rubber cover is not distorted or
slipped off.
Page 1821 of 1943

I12020
I12021
BE±84
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
2. CHECK BATTERY CAPACITY
HINT:
Make sure to use the TOYOTA electrical tester.
With the battery unloaded, judge can not be made wheth-
er the battery is available or not on the test.
When the transmitter is faulty, the energy amount left in
the battery might not be checked correctly.
On the lithium battery used for the transmitter, the voltage
more than 2.5 V with the battery unloaded is shown on the
tester until the energy is completely consumed.
Accordingly when inspecting the energy amount left in the
battery, it is necessary to measure the voltage when the
battery is loaded. (1.2 kW).
(a) Remove the cover using a (±) driver.
(b) Remove the battery (lithium battery) from the transmitter.
(c) Connect the lead to the (±) terminal of the transmitter and
install the battery.
(d) Connect the (+) tester to the (+) battery (lithium battery),
and (±) tester to the lead respectively.
(e) Press one of the transmitting switches on the transmitter
for approx. 1 second.
(f) Press the transmitting switch on the transmitter again to
check the voltage.
Standard: 2.1 V or more
Page 1822 of 1943

I12038
Wire harness side:
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±85
2001 PRIUS (RM778U)
HINT:
When the temperature of the battery is low, the judge can
not be made correctly.
When the outcome of the test is less than 2.1 V, conduct
the test again after leaving the battery in the place at 18
°C for more than 30 minutes.
By auto power off function, the voltage becomes no load
voltage (more than 2.5 V) condition after 20 seconds from
the switch was pressed.
Make sure to read the voltage before of it.
High voltage might be shown 1 to 2 times after leaving the
battery, judge should be made with the voltage shown at
the 3rd time or later.
(g) Disconnect the lead.
(h) Set the battery (lithium battery) in the transmitter.
(i) Install the cover, so that the rubber cover is not distorted
or slipped off.
3. INSPECT WIRELESS DOOR LOCK CONTROL RE-
CEIVER CIRCUIT
(a) Disconnect the connector from the receiver and inspect
the connector on the wire harness side, as shown below.
Tester connectionConditionSpecified condition
1 ± GroundConstantContinuity
5 ± GroundConstantBattery voltage
If the circuit is not as specified, inspect the circuit connected to
other parts.
Page 1823 of 1943
I12073
From back side: BE±86
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
(b) Connect the wire harness side connector to the receiver
and inspect the wire harness side connector from the
back side, as shown below.
Tester connectionConditionSpecified condition
3 ± GroundNormal mode10 ± 14 V
2 ± Ground
Ignition switch position OFF
Key removed
Transmitter ON
About 6 ± 7 V
If circuit is as specified, replace the receiver.
If the circuit is not as specified, inspect the circuit connected to
other parts.
Page 1824 of 1943
BE1D9±02
N30017
N13468
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE±87
2001 PRIUS (RM778U)
REPLACEMENT
1. REPLACE TRANSMITTER (LITHIUM) BATTERY
NOTICE:
Special caution should be taken for handling each compo-
nent as they are precision electronic components.
(a) Using a screwdriver, remove the cover.
NOTICE:
Do not pry out the cover forcibly.
HINT:
Push the cover with a finger as shown in the illustration, so that
there becomes clearance, then pry out the cover from that
clearance.
(b) Remove the transmitter.
(c) Remove the battery (lithium battery).
NOTICE:
Do not push the terminals with a finger.
If prying up the battery (lithium battery) forcibly to re-
move, the terminals are deformed.
(d) Install a battery (lithium battery) as shown in the illustra-
tion.
NOTICE:
Face the battery upward. Take care not to deform the termi-
nals.
(e) Check that the rubber is not distorted or slipped off, and
install the cover.
