± DIAGNOSTICSAIR CONDITIONING SYSTEM
2001 PRIUS (RM778U)
INSPECTION PROCEDURE
1 Check voltage between terminals S5TS and TS of A/C amplifier connector.
PREPARATION:
(a) Remove center cluster module control with connectors
still connected.
(b) Turn ignition switch ON.
CHECK:
Measure voltage between terminals S5TS and TS of A/C ampli-
fier connector when the solar sensor is subjected to an electric
light, and when the sensor is covered by a cloth.
OK:
ConditionVoltage
Sensor subjected to electric lightBelow 4.0 V
Sensor covered by a cloth4.0 ± 4.5 V
HINT:
As the inspection light is gradually moved away from the sen-
sor, the voltage increases.
NG Go to step 2.
NG
Proceed to next circuit inspection shown on problem symptoms table (See page DI±874). Howev-
er, if DTC 21 is displayed, check and replace A/C amplifier.
Page 1402 of 1943
I00325
± DIAGNOSTICSAIR CONDITIONING SYSTEM
DI±895
2001 PRIUS (RM778U)
2 Check solar sensor.
PREPARATION:
Remove solar sensor (See page AC±59).
CHECK:
(a) Cover the sensor by a cloth.
(b) Measure resistance between terminals 1 and 2 of solar
sensor connector.
HINT:
Connect positive (+) lead of ohmmeter to terminal 2 and nega-
tive (±) lead to terminal 1 of the solar sensor.
OK:
Resistance : 8W (No continuity)
PREPARATION:
Remove the cloth from the solar sensor and subject the sensor
to electric light.
CHECK:
Measure resistance.
OK:
Resistance : Below 10 kW (Continuity)
HINT:
As the electric light is moved gradually away from the sensor,
the resistance increases.
NG Replace solar sensor.
OK
3 Check harness and connector between A/C amplifier and solar sensor
(See page IN±41).
NG Repair or replace harness or connector.
OK
Check and replace A/C amplifier.
Page 1403 of 1943

I18379
Compressor
Lock SensorA/C Amplifier
4
29
A8LOCK W±L
18
A8SG LOCK IE14
BR±WW±L
W±LIK14
IK15
BR±W BR±W
IE15 DI±896
± DIAGNOSTICSAIR CONDITIONING SYSTEM
2001 PRIUS (RM778U)
DTC 22 Compressor Lock Sensor Circuit
CIRCUIT DESCRIPTION
This sensor sends 1 pulse par engine revolution to the A/C amplifier. If the number ratio of the compressor
speed divided by the engine speed is smaller than a predetermined value, the A/C amplifier turns the com-
pressor off. And, the indicator flashes at about 1 sec. intervals.
DTC No.Detection ItemTrouble Area
All diti b l d t t d f 3CompressorAll conditions below are detected for 3 secs. or more.
( ) E i d 450
Com ressor
Compressor drive belt
22(a) Engine speed : 450 rpm or more.
(b) Ratio between engine and compressor speed deviates
Com ressor drive belt
Compressor lock sensor22(b) Ratio between engine and compressor speed deviates
20 % or more in comparison to normal operation
Com ressor lock sensor
Harness or connector between compressor and A/C amplifier 20 % or more in comparison to normal operation.Harness or connector between com ressor and A/C am lifier
A/C amplifier
WIRING DIAGRAM
DI7SA±01
Page 1404 of 1943
I18005
2
4
N02774
0.2 V/Din.0 V
20 msec/Division (Idling)LCK1 LOCK signal waveform
± DIAGNOSTICSAIR CONDITIONING SYSTEM
DI±897
2001 PRIUS (RM778U)
INSPECTION PROCEDURE
1 Check compressor.
PREPARATION:
(a) Check compressor drive belt tension (See page AC±15).
(b) Check if the compressor does not lock during operation with engine started and blower switch and A/C
switch ON.
NG Adjust drive belt tension or repair compressor.
OK
2 Check compressor lock sensor.
PREPARATION:
Disconnect compressor lock sensor connector.
CHECK:
Measure resistance between terminals 2 and 4 of compressor
lock sensor connector.
OK:
Resistance : at 20 °C (68 °F) : 65 ± 125 W
Reference : Inspection using oscilloscope
During cranking or idling, measure voltage between terminals
LOCK and SGLOCK of A/C amplifier.
HINT:
The correct waveform appears as shown in the illustration on
the left.
NG Replace compressor.
OK
Page 1405 of 1943
DI±898
± DIAGNOSTICSAIR CONDITIONING SYSTEM
2001 PRIUS (RM778U)
3 Check harness and connector between A/C amplifier and compressor lock sen-
sor (See page IN±41).
NG Repair or replace harness or connector.
OK
Proceed to next circuit inspection shown on problem symptoms table (See page DI±874). Howev-
er, if DTC 22 is displayed, check and replace A/C amplifier.
Page 1406 of 1943
I08340
J1
J/CL±Y
A3
A/C Dual Pressure
SwitchA/C amplifier
W±B
IE1
A811
PSW
4
ED 115
A W±B
± DIAGNOSTICSAIR CONDITIONING SYSTEM
DI±899
2001 PRIUS (RM778U)
DTC 23 Pressure Switch Circuit
CIRCUIT DESCRIPTION
This pressure switch sends the appropriate signals to the A/C amplifier when the A/C refrigerant pressure
drops too low or rises too high. When the A/C amplifier receives these signals, if outputs signals via the A/C
amplifier to switch off the compressor relay and turns the magnetic clutch off.
DTC No.Detection ItemTrouble Area
Open inpressure sensor circuitPressure switch
23
Open in pressure sensor circuit.
Abnormal refri
gerant pressure.
Pressure switch
Harness or connector between pressure switch and A/C am-
lifi23Abnormal refrigerant ressure.
below 196 kPa (2.0 kgf/cm2. 28 psi)2
plifier
Refrigerantpipe lineover 3,140 kPa (32.0 kgf/cm2. 455 psi)Refrigerant pipe line
A/C amplifier
WIRING DIAGRAM
DI7SB±01
Page 1407 of 1943
I18170
ON
PSW
(±) (+)
Low Pressure Cut SideReferaence : High Pressure Cut SIde
ON (0 V)
OFF (12V) 196 kPa225 kPaON (0 V)
2,550 kPa
OFF (12V)3,140 kPa
DI±900
± DIAGNOSTICSAIR CONDITIONING SYSTEM
2001 PRIUS (RM778U)
INSPECTION PROCEDURE
1 Check voltage between terminals PSW of A/C amplifier and body ground.
PREPARATION:
(a) Install the manifold gauge set (See page AC±18).
(b) Remove the center cluster module control with connec-
tors still connected.
(c) Turn ignition switch ON.
CHECK:
Check voltage between terminals PSW of A/C amplifier con-
nector and body ground when refrigerant pressure is changed.
OK:
The voltage changes refrigerant pressure, as shown
in the chart below.
OK Proceed to next circuit inspection shown on
problem symptoms table (See page DI±874).
NG
Page 1408 of 1943
I18025
1
2
3
4
Low Pressure Cut Side
196 kPa225 kPa2,550 kPa
3,140 kPaOFF (No continuity) OFF (No continuity)ON (Continuity)
ON (Continuity)
Referaence : High Pressure Cut SIde
± DIAGNOSTICSAIR CONDITIONING SYSTEM
DI±901
2001 PRIUS (RM778U)
2 Check pressure switch.
PREPARATION:
Disconnect pressure switch connector.
CHECK:
Check continuity between terminals 1 and 4 of pressure switch
when refrigerant is changed.
OK:
The continuity changes with refrigerant pressure as
shown in the chart below.
NG Replace pressure switch.
OK
3 Check harness and connector between A/C amplifier and pressure switch, pres-
sure switch and body ground (See page IN±41).
NG Repair or replace harness or connector.
OK
Check and replace A/C amplifier.
