Page 1121 of 1943
H01019H09668H12953
Squib (LH)Airbag
Sensor
Assembly
FL+
(±) (+) FL±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±559
2001 PRIUS (RM778U)
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI±629).
2 Check side squib (LH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the side airbag assembly (LH)
(See page DI±497).
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (LH) and the airbag sensor assembly,
measure the resistance between FL+ and FL±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween side airbag assembly (LH) and airbag
sensor assembly.
OK
Page 1122 of 1943
AB0119H01017H01073H10600H12025
Squib (LH)Airbag
Sensor
Assembly
" u
ON
DTC B0115/47
DLC3
Tc CG
DI±560
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
2001 PRIUS (RM778U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON and wait at least for 20 se-
conds.
(b) Clear the DTC stored in memory (See page DI±497).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch or ON, and wait at least for 20 se-
conds.
(e) Check the DTC (See page DI±497).
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1123 of 1943

H10600 H01018
H01073 AB0119H12026
"uAirbag
Sensor
Assembly Squib (LH)
DTC B0115/47 DLC3
Tc CGON
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±561
2001 PRIUS (RM778U)
4 Check side squib (LH).
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the front side airbag assembly (LH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to LOOK, and wait at least for 20
second.
(b) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(c) Clear the DTC stored in memory (See page DI±497).
(d) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(e) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(f) Check the DTC (See page DI±497).
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1124 of 1943

H01019H09668H12954
Squib (LH)Airbag
Sensor
Assembly
(±) (+)
FL±FL+
DI±562
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
2001 PRIUS (RM778U)
DTC B0116/48 Open in Side Squib (LH) Circuit
CIRCUIT DESCRIPTION
The side squib (LH) circuit consists of the airbag sensor assembly and side airbag assembly (LH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0116/48 is recorded when an open is detected in the side squib (LH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0116/48
Open circuit in FL+ wire harness or FL± wire harness of
squib
Side squib (LH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (LH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI±553.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±629)
2 Check side squib (LH) circuit.
CHECK:
For the connector (on the front side airbag assembly side) be-
tween the front side airbag assembly (LH) and the airbag sen-
sor assembly, measure the resistance between FL+ and FL±.
OK:
Resistance: Below 1 W
NG Repair or replace harness or connector be-
tween side airbag assembly (LH) and airbag
sensor assembly.
OK
DI6PG±01
Page 1125 of 1943

H09671
AB0119H01074 H10600
H01017
H13042
Squib (LH)
Airbag
Sensor
Assembly
FL+
CGDTC B0116/48
" u
DLC3ON
FL±
Tc
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±563
2001 PRIUS (RM778U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect FL+ and FL± of the connec-
tor (on the side airbag assembly side) between the side
airbag assembly (LH) and the airbag sensor assembly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ON and wait at least for 20 se-
conds.
(b) Clear the DTC stored in memory (See page DI±497).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(e) Check the DTC (See page DI±497).
OK:
DTC B0116/48 is not output.
HINT:
Codes other than code B0116/48 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag sensor assembly.
OK
Page 1126 of 1943

H10600H01074 H01018AB0119H12028
"u
Airbag
Sensor
Assembly Squib (LH)
ON
DLC3
DTC B0116/48
Tc CG
DI±564
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
2001 PRIUS (RM778U)
4 Check side squib (LH).
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (LH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(b) Clear the DTC stored in memory (See page DI±497).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(e) Check the DTC (See page DI±497).
OK:
DTC B0116/48 is not output.
HINT:
Codes other than code B0116/48 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1127 of 1943

H01016H09669H12956
Squib (LH)
Airbag
Sensor
Assembly
(±) (+)
FL+
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±565
2001 PRIUS (RM778U)
DTC B0117/45 Short in Side Squib (LH) Circuit
(to Ground)
CIRCUIT DESCRIPTION
The side squib (LH) circuit consists of the airbag sensor assembly and side airbag assembly (LH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0117/45 is recorded when ground short is detected in the side squib (LH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0117/45
Short circuit in side squib (LH) wire harness (to ground)
Side squib (LH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (LH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI±553.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI±629).
2 Check side squib (LH) circuit.
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (LH) and the airbag sensor assembly,
measure the resistance between FL+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween side airbag assembly (LH) and airbag
sensor assembly.
OK
DI6PH±01
Page 1128 of 1943

AB0119H10600 H01017
H01071H09671H13043
Squib (LH)
Airbag
Sensor
Assembly
FL+FL±
" u
DLC3ON
CGTcDTC B0117/45
DI±566
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
2001 PRIUS (RM778U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect FL+ and FL± of the connec-
tor (on the side airbag assembly side) between the side
airbag assembly (LH) and the airbag sensor assembly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON and wait at least for 20 se-
conds.
(b) Clear the DTC stored in memory (See step 5 on page
DI±497).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ON, and wait at least for 20 se-
conds.
(e) Check the DTC (See page DI±497).
OK:
DTC B0117/45 is not output.
HINT:
Codes other than code B0117/45 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
