DAEWOO NUBIRA 2004 Service Repair Manual 8–2 BODY DIMENSIONNUBIRA/LACETTI 1. BODY DRAWING 1–1. UNDER BODY NOTCHBACKUnit: mm (in.) Fig. 1

Page 2586 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual NUBIRA/LACETTIBODY DIMENSION 8–3 HATCHBACK Fig. 2

Page 2587 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8–4 BODY DIMENSIONNUBIRA/LACETTI FRONT FRAMEUnit: mm (in.) Fig. 3

Page 2588 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual NUBIRA/LACETTIBODY DIMENSION 8–5 REAR FRAMEUnit: mm (in.) NOTCHBACK Fig. 4

Page 2589 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8–6 BODY DIMENSIONNUBIRA/LACETTI HATCHBACK Fig. 5

Page 2590 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual NUBIRA/LACETTIBODY DIMENSION 8–7 1–2. FRONT PANEL Unit: mm(in.) Fig. 6

Page 2591 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8–8 BODY DIMENSIONNUBIRA/LACETTI 1–3. ENGINE ROOM Unit: mm(in.) Fig. 7

Page 2592 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual NUBIRA/LACETTIBODY DIMENSION 8–9 1–4. BACK PANEL LOWER NOTCHBACKUnit: mm(in.) Fig. 8
