DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 203 DAEWOO V–121 BL4 Upper Valve Body Key MarkRetainerHeight/Width/Thickness mm (in.) ACheck valve11.5 (0.453) / 5.0 (0.197) / 3.2 (0.126) BSecondary regulator va

Page 1794 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 204IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Upper Valve Body Check Ball Check ball mm(in).5.535 (0.21791)

Page 1795 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 205 DAEWOO V–121 BL4 Lower Valve Body 1. Key 2. Spring 3. 4–3 Shift Timing Valve 4. Key 5. Plug 6. 2–3 Shift Valve 7. Spring 8. Key 9. Plug 10. 1–2 Shift

Page 1796 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 206IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Lower Valve Body Spring MarkName (Color)Free length/Outer diameter mm (in.)Total number of coils A4–3 shift timing valve No.1 (None)33.95 (1.

Page 1797 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 207 DAEWOO V–121 BL4 Lower Valve Body Key MarkRetainerHeight/Width/Thickness mm (in.) A4–3 shift timing valve No.136.0 (1.417) / 5.0 (0.197) / 3.2 (0.126) BLow

Page 1798 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 208IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 DIFFERENTIAL CASE 1. Differential Pinion Thrust Washer 2. Differential Pinion Gear 3. Differential Side Gear Thrust Washer 4. Differential

Page 1799 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 209 DAEWOO V–121 BL4 Tools Required DW260–031–01 Transaxle Housing Oil Seal Installer DW260–031–02 Transaxle Case Oil Seal Installer DW240–150 Transaxle

Page 1800 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 210IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 5. Using a suitable puller, remove the tapered roller bearing of transaxle case side. 6. Using a pin punch and hammer, drive out the pin from
