SECTION : 9K
SQUEAKS AND RATTLES
TABLE OF CONTENTS
DIAGNOSIS9K–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Squeak and Rattle Diagnosis 9K–1. . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9K–3 . . . . . . . . . . . . . . . ON–VEHICLE SERVICE 9K–3. . . . . . . . . . . . . . . . . . . . .
Squeak and Rattle Repair 9K–3. . . . . . . . . . . . . . . . . . .
DIAGNOSIS
SQUEAK AND RATTLE DIAGNOSIS
Rattle Coming From the Side Rail
ChecksAction
Check the brake lines.S Tap lightly on the brake lines and listen for a rattle.
S Install plastic tie straps to secure the brake lines
tightly together.
Rattle Under Vehicle at Higher RPM
ChecksAction
Check for heat shield contact with the underbody.S Raise the vehicle and perform a visual inspection.
S Bend the heat shield slightly to gain clearance from
the underbody.
Squeak From the Front of the Vehicle in Cold Weather
ChecksAction
Check the front stabilizer shaft insulators.S While the vehicle is cold, perform a test drive and
achieve full front suspension travel by driving through
a dip in the road.
S Remove the insulators and wrap teflon tape around
the stabilizer shaft. Reinstall the insulators over the
tape.
Thump From Rear of Vehicle on Bumps
ChecksAction
Check for a properly secured spare tire in the rear
compartment.S Open the rear compartment and perform a visual
inspection of the spare tire and the tools.
S Tightly secure the spare tire and all tools.
S Perform a road test to verify that the noise is elimi-
nated.
Page 2378 of 2643

9K – 2ISQUEAKS AND RATTLES
DAEWOO V–121 BL4
Glass Knock Coming From the Rear of the Vehicle When Driving
Over Bumps
ChecksAction
Check for an out–of–adjustment hatchback latch.S Test drive the vehicle in order to verify this condition.
S Loosen the latch nuts and adjust the latch downward.
Rattle Coming From Door
Checks Action
Check the door lock solenoid.S Remove the door trim panel and check if the sole-
noid is loose.
S Tighten the solenoid bolts.
Check for rattling electrical connectors inside the door trim
panel.S Tap on the trim panel and listen for a rattle.
S Remove the trim panel and wrap foam padding
around the connectors as required.
Squeak When Operating Doors
ChecksAction
Check for a lack of lubrication of the door hinge pins.S Operate the doors and listen for squeaks.
S Lubricate the door hinge pins with light oil and coat
with lithium grease.
Squeak Coming From Console When Shifting Manual Transaxle
(Condition Occurs In Cold Weather with a Cold Engine)
Checks Action
Check the manual transaxle control lever lower boot.S Move the control lever between gears and listen for
squeaks.
S Remove the floor console and replace the lower shift
boot or apply talcum powder to the lower shift boot.
Buzz From the Left Side of Instrument Panel
ChecksAction
Check for vibration of the fuse box cover against the instru-
ment panel side trim.S Tap on the cover with a finger and listen for a buzz.
S Apply 6.35 mm (0.250 inch) by 25.4 mm (1.00 inch)
felt pads to the side trim where the cover makes con-
tact.
Squeak Coming From Instrument Cluster Trim Plate
Checks Action
Check for rubbing of the cluster trim plate on the instru-
ment panel.S Test drive the vehicle in order to verify this condition.
S Remove the instrument cluster trim plate and install
felt tape to the edges.
Page 2379 of 2643
SQUEAKS AND RATTLES 9K – 3
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
SQUEAK AND RATTLE REPAIR
Squeaks and rattles are caused by the unwanted move-
ment between parts of a vehicle. There are three means
to prevent squeaks or rattles.
S Attach the parts securely so that there is no relative
motion during the operation of the vehicle.
S Separate the parts so that there is no contact dur-
ing operation.
S Insulate the parts so that no squeaks or rattles oc-
cur with the movement of the parts. Low uniform
friction surfaces can be used to eliminate ”stick–
slip” motion.
Page 2380 of 2643

SECTION : 9L
GLASS AND MIRRORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9L–2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9L–2. . . . . . . . . . . .
SPECIAL TOOLS9L–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools Table 9L–2. . . . . . . . . . . . . . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9L–3 . . . . . .
Defogger System 9L–3. . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric Control OSRV (Outside Rear View)
Mirror System 9L–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS9L–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Testing Rear Window Defogger Grid Line 9L–5. . . . . .
Outside Rearview Mirror Defoggers 9L–5. . . . . . . . . . .
Electric Control Outside Rearview Mirrors 9L–6. . . . . .
Folding Mirror Unit 9L–8. . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9L–10 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9L–10. . . . . . . . . . . . . . . . . . . . .
Windshield 9L–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Rear Window Glass 9L–11. . . . . . . . . . . . . . . . . . . . . . . .
Rear Window Defogger Grid Line Repair 9L–13. . . . . .
Rear Window Defogger Braided Lead Wire
Repair 9L–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Door Glass 9L–15. . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Glass 9L–16. . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Quarter Glass 9L–16. . . . . . . . . . . . . . . . . . .
Inside Rearview Mirror 9L–17. . . . . . . . . . . . . . . . . . . . .
Outside Rearview Mirrors 9L–18. . . . . . . . . . . . . . . . . . .
Folding Mirrors Unit 9L–18. . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9L–19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stationary Glass 9L–19. . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric Control Heated Outside Rearview
Mirror 9L–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Rearview Mirror 9L–19. . . . . . . . . . . . . . . . . . . . .
Folding Mirror Unit 9L–19. . . . . . . . . . . . . . . . . . . . . . . . .
Page 2381 of 2643
9L – 2IGLASS AND MIRRORS
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Glass Screws7–62
Guide Rail Bolts7–62
Guide Rail Screw4–35
Outside Rearview Mirror Assembly Bolts Screws4.5–40
Rearview Mirror Mounting Bolt1.2–11
Folding Mirror Unit Bolt10–89
SPECIAL TOOLS
SPECIAL TOOLS TABLE
J–24402
Glass Sealant
Remover
Page 2382 of 2643
GLASS AND MIRRORS 9L – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
DEFOGGER SYSTEM
Page 2383 of 2643
9L – 4IGLASS AND MIRRORS
DAEWOO V–121 BL4
ELECTRIC CONTROL OSRV (OUTSIDE REAR VIEW)
MIRROR SYSTEM
Page 2384 of 2643

GLASS AND MIRRORS 9L – 5
DAEWOO V–121 BL4
DIAGNOSIS
TESTING REAR WINDOW
DEFOGGER GRID LINE
If it has been observed during use that a grid line is inop-
erative, the following procedure can be used to find the
break. If none of the grid lines is operating, a full system
diagnosis should be completed before attempting to repair
the grid lines.
1. Turn the ignition ON.
2. Turn the rear window defogger on.
3. From the inside of the vehicle, connect a voltmeter
to each end of a grid line. The voltmeter will indi-
cate battery voltage if the grid line is open.
Notice : Use care when touching the voltmeter leads to a
grid line. If the leads are roughly applied, the grid line may
be scratched, resulting in an open circuit.4. If a grid line is found to be open, move a voltmeter
lead from one side of the grid line and retest at a
point nearer to the other side of the window. Contin-
ue to retest, each time bringing one of the voltmeter
leads closer to the opposite side of the window
from where it was originally placed. The break in
the grid line is at the point where the voltmeter be-
gins reading 0 volts instead of battery voltage.
5. Use a marking crayon to lightly mark the break
point on the rear window. Mark the glass instead of
marking directly on the grid line, and make the
mark far enough from the grid line so that it can
easily be removed without disturbing the repair.
6. Use a grid line repair kit to fix the break in the grid
line. Refer to ”Rear Window Defogger Grid Line
Repair” in this section.
OUTSIDE REARVIEW MIRROR DEFOGGERS
StepActionValue(s)YesNo
1Check the rear window defogger.
Does the rear window defogger work?–Go to Step 4 Go to Step 2
2Repair the rear window defogger before proceeding
with the outside rearview mirror diagnosis.
Is the repair complete?–Go to Step 3–
3Test the outside rearview mirror defoggers.
Does the repair of the rear window defogger system
also fix the problem with the outside rearview mirror
defoggers?–System OKGo to Step 4
4Check fuse Ef25.
Is fuse Ef25 blown?–Go to Step 5 Go to Step 6
51. Check for a short circuit and repair it, if neces-
sary.
2. Replace the fuse.
Is the repair complete?–System OK–
61. On the side of the vehicle which has the mal-
functioning outside rearview mirror defogger,
remove the black plastic escutcheon from the
trim panel side of the door.
2. Disconnect the outside rearview mirror electri-
cal connector.
3. Turn the ignition ON.
4. Turn on the defogger.
5. Use a voltmeter to backprobe terminal 3 (ORN)
at the outside rearview mirror electrical connec-
tor.
Does the voltmeter indicate the specified value?11–14 v Go to Step 8 Go to Step 7
7Repair the open circuit between fuse Ef25 and the
outside rearview mirror connector.
Is the repair complete?–System OK–
