DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 115 DAEWOO V–121 BL4 5. Install the rear mounting bracket bolts and the bracket. Tighten Tighten the rear mounting bracket bolts to 60 NSm (44 Ib–ft). 6. Insta

Page 1706 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 116IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 15. Connect the fluid cooler inlet and outlet pipe and hose into the transaxle. Refer to ”Fluid Cooler Inlet or Outlet Pipe and Hoses” in

Page 1707 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 117 DAEWOO V–121 BL4 UNIT REPAIR MAJOR COMPONENT DISASSEMBLY Tools Required DW240–020 Brake/Clutch Spring Compressor DW240–050 Overdrive Brake Adapter DW240–

Page 1708 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 118IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 8. Remove the screw plug from the transaxle case. 9. Remove the O–ring from the screw plug. 10. Remove the bolt and the input shaft speed

Page 1709 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 119 DAEWOO V–121 BL4 17. Remove the three bolts and oil strainer. 18. Remove the gasket from the oil strainer. 19. Remove the bolt and transmission fluid temper

Page 1710 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 120IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 22. Disconnect the manual valve control rod from the manual valve lever, then remove the valve body assembly. 23. Remove the check valve and

Page 1711 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 121 DAEWOO V–121 BL4 WARNING : USE CAUTION WHEN REMOVING COM- PONENTS WITH COMPRESSED AIR OR PERSONAL INJURY MAY RESULT. Notice : Blowing off the air may cause the

Page 1712 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 122IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 WARNING : USE CAUTION WHEN REMOVING COM- PONENTS WITH COMPRESSED AIR OR PERSONAL INJURY MAY RESULT. Notice : Blowing off the air may cause the
