Page 2417 of 2643
9O – 6IBUMPERS AND FASCIAS
DAEWOO V–121 BL4
4. Install the screws behind the fascia.
5. Install the splash shields with the screws.
6. Install the mud guards with the screws.
7. Install the rear wheels. Refer to Section 2E, Tires
and Wheels.
HATCHBACK REAR BUMPER
FASCIA
Removal Procedure
1. Remove the rear wheels. Refer to Section 2E,
Tires and Wheels.
2. Remove the screws and the splash shields.
3. Remove the screws behind the fascia.
4. Remove the luggage compartment wheelhouse trim
panels. Refer to Section 9G, Interior Trim.
5. Remove the bolts and the nuts in the luggage
compartment.
6. Remove the screws.
7. Remove the rear bumper fascia.
Page 2418 of 2643
BUMPERS AND FASCIAS 9O – 7
DAEWOO V–121 BL4
Installation Procedure
1. Install the rear bumper fascia with the screws.
2. Install the bolts and the nuts in the luggage
compartment.
3. Install the luggage compartment wheelhouse trim
panels. Refer to Section 9G, Interior Trim.
4. Install the screws behind the fascia.
5. Install the splash shields with the screws.
6. Install the rear wheels. Refer to Section 2E, Tires
and Wheels.
REAR BUMPER IMPACT BAR
Removal Procedure
1. Remove the rear bumper fascia. Refer to ”Rear
Bumper Fascia” in this section.
2. Remove the screws and the impact bar.
Page 2419 of 2643
9O – 8IBUMPERS AND FASCIAS
DAEWOO V–121 BL4
Installation Procedure
1. Install the impact bar with the screws.
2. Install the rear bumper fascia. Refer to ”Rear
Bumper Fascia” in this section.
Page 2420 of 2643
BUMPERS AND FASCIAS 9O – 9
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
BUMPERS
The bumper systems are designed to sustain a collision
into a fixed barrier at either 8 km/h (5 mph) or 4 km/h (2.5
mph) without damage. After absorbing the energy of a col-lision, the bumper systems restore themselves to their
original positions. The bumpers feature an internal foam
energy absorber and a polymer fascia cover.
Page 2421 of 2643

SECTION : 9P
DOORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9P–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specification 9P–2. . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9P–3 . . . . .
Power Door Locks Circuit 9P–3. . . . . . . . . . . . . . . . . . . .
Power Windows Circuit (Front Only) 9P–4. . . . . . . . . .
Power Windows Circuit (Front and Rear) 9P–5. . . . . .
DIAGNOSIS9P–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9P–16 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9P–16. . . . . . . . . . . . . . . . . . . .
Outside Channel Molding 9P–16. . . . . . . . . . . . . . . . . . .
Front Door Glass Run 9P–16. . . . . . . . . . . . . . . . . . . . . .
Door Weatherstrip 9P–17. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Glass Run 9P–18. . . . . . . . . . . . . . . . . . . . . .
Front Door Secondary Weatherstrip 9P–18. . . . . . . . . .
Rear Door Secondary Weatherstrip 9P–19. . . . . . . . . .
Front Door Opening Weatherstrip 9P–19. . . . . . . . . . . .
Rear Door Opening Weatherstrip 9P–20. . . . . . . . . . . . Door Seal Trim 9P–20. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–21. . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker Adjustment 9P–22. . . . . . . . . . . . . . .
Front Door Lock 9P–23. . . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–23. . . . . . . . . . . . . . . . . .
Inside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . . .
Outside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . .
Inside Lock Rod 9P–25. . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Cylinder 9P–25. . . . . . . . . . . . . . . . . . . . . . . .
Power Window Regulator 9P–26. . . . . . . . . . . . . . . . . . .
Door Assembly 9P–26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hinge 9P–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hold–Open Link 9P–28. . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9P–29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–29. . . . . . . . . . . . . . . . . .
Power Door Locks 9P–29. . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 2422 of 2643
9P – 2IDOORS
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATION
ApplicationNSmLb–FtLb–In
Door Hinge–to–Body Bolts3627–
Door Hinge–to–Door Bolts2015–
Door Hold–Open Link–to–Body Bolt2518–
Door Hold–Open Link–to–Door Bolts9–80
Door Lock Striker Screws3022–
Door Pull Bracket Screws3–27
Front Door Lock Screws8–71
Inside Door Handle Screw3–27
Outside Channel Molding Screw1.3–12
Outside Door Handle Bolts4.5–40
Rear Door Guide Rail Bolts8–71
Rear Door Guide Rail Screw4–35
Rear Door Lock Screws8–71
Window Regulator Nuts8–71
Page 2423 of 2643
DOORS 9P – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
POWER DOOR LOCKS CIRCUIT
Page 2424 of 2643
9P – 4IDOORS
DAEWOO V–121 BL4
POWER WINDOWS CIRCUIT (FRONT ONLY)
