DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 219 DAEWOO V–121 BL4 Timing Solenoid Timing solenoid is installed directly in the valve body. The solenoid operates of ON/OFF by the control signal from TCM. The s

Page 1810 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 220IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Output Shaft Speed (ISS) Sensor OSS sensor is located on the upper position of the trans- axle and detects the vehicle speed from the rotation

Page 1811 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 221 DAEWOO V–121 BL4 HYDRAULIC CONTROL SYSTEM Based on the hydraulic pressure created by the oil pump, TCM sends signals to solenoid and hydraulic control system g

Page 1812 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 222IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 AUTOMATIC TRANSAXLE SYSTEM Function of Components ComponentFunction C1Forward ClutchConnects input shaft and front sun gear. C2Direct ClutchCo

Page 1813 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 223 DAEWOO V–121 BL4 Operations of Clutches and Brakes Clutch & BrakeOperation C1Forward ClutchConnects intermediate shaft and front sun gear. C2Direct ClutchConne

Page 1814 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 224IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 PositionSolenoidClutchBrakeOne–way Clutch Shift 1Shift 2TimingC1C2C3B1B2B3F1F2 PONONOFFOFFOFFOFFOFFOFFOFFOF –FOF –F RV<9 Km/ hONONOFFOFFO

Page 1815 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 225 DAEWOO V–121 BL4 D–1st Gear PositionSolenoidClutchBrake1 way Clutch Shift 1Shift 2TimingC1C2C3B1B2B3F1F2 D1stONONOFFONOFFOFFOFFOFFOFFOF –FON 11stONONOFFONO

Page 1816 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 226IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 6. Ring gear rotates clockwise. 7. Counter drive gear rotates clockwise for ring gear and one. 8. Counter drive gear rotates counterclockwis
