Page 1089 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 4F – 8IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
31. Turn the ignition switch to LOCK for 10 sec-
onds.
2. Turn the ignition switch to ON and observe the
ABS indicator.
D

Page 1090 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ANTILOCK BRAKE SYSTEM 4F – 9
DAEWOO V–121 BL4
J3B14F04
60A Ef230A Ef5
2
42
C107 C105
2
C110
G106
A19
A13 A1 A14
C110 C202
C202WHT LT GRN
DK
GRN LT GRN/
BLK
BLK
DK BLUDK BLU
PPL/WHT
PPL/WHT ABS
TC

ANTILOCK BRAKE SYSTEM 4F – 9
DAEWOO V–121 BL4
J3B14F04
60A Ef230A Ef5
2
42
C107 C105
2
C110
G106
A19
A13 A1 A14
C110 C202
C202WHT LT GRN
DK
GRN LT GRN/
BLK
BLK
DK BLUDK BLU
PPL/WHT
PPL/WHT ABS
TCS Parking
Brake
Hot at all times
RED REDRED/WHT
Ignition
Switch
RED
RED
I/P Cluster
EBCM8
20
22 2216 41
1211
18 1621
1
C107
10A F410AF11
32 31
43
6 62 C201
C201 C201C201
C110 C202
Hot in Run and Start
30
4
1711
C202
15
B15
DLC
(Data Link
Connector)12
G106
BLK/WHTOil Feeding
Connector
”2” Ter.
BRNBRN BRN
BRN PNK PNK PNK
19J1
59B1
ONStart Lock
Acc
IG1
19
ABS INDICATOR LAMP INOPERATIVE
Circuit Description
Battery voltage is supplied to the ABS warning lamp with
the ignition switch in the ON or START positions. The
warning lamp can be activated only by the ABS control
module internally supplying ground to terminal 20 or by the
shorting bar in the ABS module connector when it is dis-
connected from the module.
Diagnosis
This procedure checks for a problem in the wiring, a faulty
ground, a voltage supply problem, a burned out indicator
lamp, or a contact problem in a connector.
Cause(s)
S A fuse has blown.
S The indicator lamp has burned out.S There is a corroded or broken connector terminal.
S There is a faulty ground connection.
S There is a broken wire in a wiring harness.
S The EBCM is faulty.
Test Description
The number(s) below refer to step(s) on the diagnostic
table.
1. This test checks for any DTCs that may cause the
ABS indicator lamp to be inoperative.
2. This test verifies an inoperative lamp condition.
3. This test checks for voltage on the lamp circuit.
4. This begins a series of tests of the circuit from the
indicator lamp to the EBCM and ground.
19. This begins a series of tests of the voltage supply
circuits that power the indicator lamp.
ABS Indicator Lamp Inoperative
StepActionValue(s)YesNo
1Install the scan tool and check for any DTCs.
Is any DTC set?–Go to the chart
for the DTCGo to Step 2
21. Turn the ignition switch to LOCK.
2. Disconnect the scan tool.
3. Turn the ignition switch to ON.
4. Observe the ABS indicator lamp.
Does the lamp illuminate for about 4 seconds, then
turn off?–Go to ”Intermit-
tents and Poor
Connections”Go to Step 3

Page 1091 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 4F – 10IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
3With the ignition still ON, observe the oil pressure
lamp.
Is the oil pressure lamp illuminated?–Go to Step 4Go to Step

4F – 10IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
3With the ignition still ON, observe the oil pressure
lamp.
Is the oil pressure lamp illuminated?–Go to Step 4Go to Step 19
41. Turn the ignition switch to LOCK.
2. Disconnect connector from the electronic brake
control module (EBCM).
3. Turn the ignition switch to ON.
Does the ABS indicator illuminate?–Go to Step 5Go to Step 8
5S Turn the ignition switch to LOCK.
S Examine terminals 19 and 20 at the EBCM
connector on both the ABS wiring harness and
on the EBCM.
Is there a poor connection at any of these terminals?–Go to Step 6Go to Step 7
6Repair the faulty terminals or replace the ABS unit
as required.
Is the repair complete?–System OK–
7Replace the ABS unit.
Is the repair complete?–System OK–
8S Turn the ignition switch to LOCK.
S Disconnect the wire from the negative battery
terminal.
S Measure the resistance between the negative
battery wire, which is attached to ground, and
the shorting bar in the EBCM connector.
Does the resistance match the specified value?0 WGo to Step 10Go to Step 9
9Repair the open or high resistance in the circuit from
EBCM connector, terminal 19 to ground G106.
Is the repair complete?–System OK–
101. Remove the I/P cluster.
2. Remove and check the ABS indicator bulb.
Is the bulb burned out?–Go to Step 11Go to Step 12
111. Replace the ABS indicator bulb.
2. Install the I/P cluster.
Is the repair complete?–System OK–
12Check the continuity at the I/P cluster connector ter-
minal A13.
Does the ohmmeter show the specified value?0 WGo to Step 14Go to Step 13
13Repair the contact at the I/P cluster connector termi-
nal A13.
Is the repair complete?–System OK–
14Check the wiring harnesses and the connectors in
circuit LT GRN/BLK from the I/P cluster terminal A13
to terminal 20 of the EBCM connector.
Does the ohmmeter show the specified value?Go to Step 15Go to Step 16
15Repair the open or high resistance found.
Is the repair complete?–System OK–
16Check for continuity between terminal 19 of the ABS
connector and ground G106.
Does the ground connection match the specified val-
ue?0 WGo to Step 17Go to Step 18

Page 1092 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ANTILOCK BRAKE SYSTEM 4F – 11
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
17Replace the ABS unit.
Is the repair complete?–System OK–
18Repair the continuity problem between terminal 19
of the

Page 1093 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 4F – 12IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
J3B14F04
60A Ef230A Ef5
2
42
C107 C105
2
C110
G106
A19
A13 A1 A14
C110 C202
C202WHT LT GRN
DK
GRN LT GRN/
BLK
BLK
DK BLUDK BLU
PPL/WHT
PPL/WHT ABS
TC

Page 1094 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ANTILOCK BRAKE SYSTEM 4F – 13
DAEWOO V–121 BL4
Power Supply to Control Module, No DTCs Stored
StepActionValue(s)YesNo
1Check the voltage at the battery.
Is the voltage within the specified value?

Page 1095 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 4F – 14IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
141. Replace fuse F11.
2. Turn the ignition to ON.
Does the fuse blow again?–Go to Step 16Go to Step 15
15Check the AB

4F – 14IANTILOCK BRAKE SYSTEM
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
141. Replace fuse F11.
2. Turn the ignition to ON.
Does the fuse blow again?–Go to Step 16Go to Step 15
15Check the ABS function.
Is the repair complete?–System OK–
161. Turn the ignition to OFF.
2. Remove fuse F11.
3. Disconnect ABS connector from the EBCM.
4. Measure the resistance to ground at terminal
15.
Does the ohmmeter show the specified value?0 WGo to Step 17Go to Step 25
17Repair the short to ground in circuit PNK fuse F11 of
the I/P fuse block and terminal 15 of the ABS har-
ness EBCM connector.
Is the repair complete?–System OK–
181. Disconnect the EBCM connector from the
EBCM.
2. Turn the ignition to ON.
3. Check for the presence of battery voltage be-
tween ground and terminal 17, and between
ground and terminal 18.
Is the voltage within the specified value?11–14 vGo to Step 20Go to Step 19
191. Turn the ignition switch to OFF.
2. Trace the RED wires between terminals 17 and
18 of the EBCM connector to terminal 1 of con-
nector C107 at the engine fuse block.
3. Repair the open in this circuit.
Is the repair complete?–System OK–
20Check the voltage between ground and terminal 15
of the EBCM connector.
Is the voltage within the specified value?11–14 vGo to Step 22Go to Step 21
211. Turn the ignition switch to OFF.
2. Trace circuit PNK between terminal 15 of the
ABS harness EBCM connector to fuse F11 in
the I/P fuse block.
3. Trace circuit PNK from fuse F11 of the I/P fuse
block to terminal 4 (IG1) of the ignition switch.
4. Trace circuit RED from terminal 2 (B1) of the
ignition switch to terminal 4 of connector C105
at the engine fuse block and to fuse EF5.
5. Repair the open in the wiring or possibly bad
connector terminal, defective ignition switch, or
blown fuse EF5.
Is the repair complete?–System OK–
221. Turn the ignition to OFF.
2. Check the resistance between ground and ter-
minals 19 and 16 of the EBCM connector.
Does the ohmmeter show the specified value?0 WGo to Step 23Go to Step 26
23Examine terminals 15, 19, 17, 18, and 16 of the
EBCM connector.
Is there a defective terminal?–Go to Step 24Go to Step 25

Page 1096 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ANTILOCK BRAKE SYSTEM 4F – 15
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
24Repair the defective terminal or replace the connec-
tor or wiring harness as required.
Is the repair complete?–Syste
